Upgrading The Computer
6
6 - 20 Upgrading the Video Card
6. Secure the card with screws
7. Place the heatsink back on the card, and secure the screws in the order indicated
in Figure 6 - 18 on page 6 -
8. Attach the video card fan and secure with the screws as indicated in
on page 6 - 15.
9. Reinsert the component bay cover, and secure with the screws as indicated in
Figure 6 - 15 on page 6 - 14
screwing down the bay cover).
- (Figure 6 - 18 on page 6 -
19 21
16.
(make sure you reconnect the fan cable before
16).
Figure 6 - 16
