8. Remove the keyboard
9. Gently pull the two release latches (
the direction indicated below.
and keyboard shielding plate
17
18
17
)
19 & 20 on the sides of the memory socket in
19
Upgrading The Computer
.
18
20
Upgrading the System Memory (RAM) 6 - 11
Figure 6 - 11
Bay Cover Removal
Single Memory
Module Installation
If your computer has a sin-
gle memory module, then in-
sert the module into the
Channel 0 (JDIMM1) sock-
Figure 6 -
et as shown in
12
.
Figure 6 - 12
RAM Module
Release Latches
