Interface (Ports & Jacks)
Ports and Jacks
Item
Card Reader
Cable (CATV)
Antenna Jack
Consumer Infrared
Transceiver
DC-In Jack
A
DVI-Out Port
A - 2 Interface (Ports & Jacks)
The card reader allows you to use the following digital storage cards:
MMC (MultiMedia Card)
SD (Secure Digital)
MS (Memory Stick)
MS (Memory Stick Pro)
Use this jack to connect a CATV cable if you have included the optional Mini-PCI TV Tuner in
your purchase.
The consumer infrared transceiver at the front of the computer allows the computer to
communicate with the remote control unit supplied with the optional Mini-PCI TV Tuner.
Plug the supplied AC/DC adapter into this jack to power your computer.
The DVI-Out (Digital Visual Interface) Port is a video connector interface. This allows you to
connect an external monitor, TV or Flat Panel Display etc. as a display device (see
Other Displays" on page B -
monitor you will need to use a converter to convert the signal from DVI to VGA.
Description
RS MMC (requires PC adapter)
Mini SD (requires PC adapter)
MS Duo (requires PC adapter)
6) by means of a DVI cable. If you are using an older type of
"Attaching
