Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 8: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety Warning uninterrupted power supply.
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 15: Table Of Contents
Preface Contents Notice .................I System Map: Right View ..........1-11 FCC Statement .............II System Map: Bottom View ..........1-12 Instructions for Care and Operation ......IV Windows XP Start Menu & Control Panel ....1-13 Power Safety .............. VI Video Features .............1-14 Battery Precautions ...........VII Display Devices &...
Page 16 Preface Power Management Drivers & Utilities Overview ................3-1 What to Install ..............4-1 Advanced Configuration and Power Interface ....3-1 Module Driver Installation ..........4-1 The Power Sources ............3-2 Service Packs ...............4-3 AC/DC Adapter ............3-2 Authorized Driver Message .........4-4 Battery .................3-2 Version Conflict Message ...........4-4 Turning on the Computer ..........3-3 Updating/Reinstalling Individual Drivers ....4-4 Power Schemes ..............3-4...
Page 17 Preface BIOS Utilities I/O Interface Security (Security Menu) .......5-12 TPM Protection (Security Menu) ........5-12 Overview ................5-1 TPM Function (Security Menu) ........5-12 The Power-On Self Test (POST) ........5-2 Power Menu ..............5-13 Failing the POST ............5-3 Power Menu ..............5-13 Fatal Errors ..............5-3 Start Battery Calibration (Power Menu) ......5-14 Non-Fatal Errors ............5-3 Boot Menu ..............5-15...
Page 18 Preface User Enrollment ............7-7 RJ-11 Phone Jack ............A-3 Trusted Platform Module ..........7-10 RJ-45 LAN Jack ............A-3 Initializing TPM ............7-10 Security Lock Slot ............A-3 TPM User Set Up .............7-13 USB 2.0/1.1 Ports ............A-4 Initialize the TPM for use with the Intel Video Driver Controls Protector Suite Software ...........7-15 Intel Video Driver Installation ........
Page 19 Preface PCMCIA ............... C-3 Card Reader ..............C-3 Interface ................ C-3 Communication ............. C-4 Power Management ............C-4 Power ................C-4 Environmental Spec ............C-4 Dimensions & Weight ..........C-4 Optional ................ C-5 XVII...
Page 20 Preface XVIII...
Page 21: Quick Start Guide Overview
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Model Designs
Quick Start Guide Model Designs This notebook series includes two different model designs which vary slightly in color and appearance. However both designs incorporate the same features, ports and jacks etc. Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to Chapter 4 (Drivers),...
Page 23: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows XP) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the Microsoft Win- dows XP (Home &...
Page 24: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 25: System Map: Top View With Lcd Panel Open
Quick Start Guide System Map: Top View with LCD Panel Open WLAN Power Switch TouchPad Power Button Wireless Device Power Button Operation Aboard Keyboard Aircraft TouchPad and Buttons The use of any portable Fingerprint Reader electronic transmission de- LED Indicators vices aboard aircraft is usu- LCD Latch ally prohibited.
Page 26: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Green The Computer is On Green The WLAN Module is Powered On Blinking The Computer is in Stand by Mode Orange The Bluetooth Module is Powered On...
Page 27: Keyboard & Hot Keys
Quick Start Guide Keyboard & Hot Keys The touchpad (button) and WLAN (switch) hot keys give instant access to the functions indicated in the table be- The keyboard has a numerical keypad for easy numeric low. Visual indicators are available when the hot key data input, and features function keys to allow you to driver is installed (see “Hot Key Utility”...
Page 28: Function Keys
Quick Start Guide Function Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available for certain key combinations/hot keys when the hot “Hot Key Utility”...
Page 29: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LED Indicators LCD Latch RJ-11 Phone Jack RJ-45 LAN Jack Battery DC-In Jack 10 Cell Battery Warning Please be careful when us- Battery Information ing the 10 cell battery.
Page 30: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 5 - Left View Vent/Fan Intake/Outlet External Monitor Port 1 * USB 2.0 Port Mini-IEEE 1394 Port 4-in-1 Card Reader PC Card Slot Mini-IEEE 1394 Port The Mini-IEEE 1394 Port only supports SELF POWERED IEEE 1394 devices. Overheating 4-in-1 Card Reader To prevent your computer...
Page 31: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 6 - Right View Headphone-Out/Speaker-Out Jack Microphone-In Jack 2 * USB 2.0 Ports Optical (CD/DVD) Device Drive Security Lock Slot Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives.
Page 32: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Vent/Fan Intake/Outlet Battery Optical (CD/DVD) Device Drive Release Cover Component Bay Cover Hard Disk Drive Bay Cover Speaker The CPU is not a user serviceable part. Open- ing this compartment, or accessing the CPU in any way, may violate your warranty.
Page 33: Windows Xp Start Menu & Control Panel
Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 34: Video Features
Quick Start Guide Video Features Your computer has built-in Intel on-board video. You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel).
Page 35 Quick Start Guide Figure 1 - 9 - Display Properties Desktop Intel Display Mode Description Single Mode One of the connected displays is used as the display device This mode will drive multiple displays with the same content and resolutions, color quality Twin Mode etc.
Page 36: Power Management Features
Quick Start Guide Power Management Features The Power Options control panel icon in Windows (see page 13) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Stand by or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 -...
Page 37: Features & Components Overview
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 4-in-1 Card Reader • PC Card Slot •...
Page 38: Hard Disk Drive
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" or 1.8" parallel (PATA) hard disk drives with a height of 9.5 mm.
Page 39: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (9.5mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 40: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 41: Dvd Regional Codes
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 DVD Regional Region Geographical Location Coding USA, Canada Western Europe, Japan, South Africa, Middle East & Egypt Figure 2 - 3 South-East Asia, Taiwan, South DVD Regions...
Page 42: 4-In-1 Card Reader
Features & Components 4-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 43: Pc Card Slot
Features & Components PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PCMCIA PC Card Slot Cover CardBus PC Card Slot. Make sure you install the PCMCIA/Card Reader driver (see “PCMCIA/CardReader” on page 4 - Make sure you keep the cover in the PC Card Inserting and Removing PC Cards...
Page 44: Touchpad And Buttons/Mouse
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an exter- nal mouse your operat- You can configure the mouse functions from the Mouse Properties control panel.
Page 45: Audio Features
Features & Components Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel, or from the Realtek HD Audio Manager Adjustment icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).
Page 46: Adding A Printer
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Page 47: Power Management Overview
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer uses the ACPI functions will vary slight- power management system. Power management conserves power by controlling in- ly depending on your dividual components of the computer (the monitor and hard disk drive) or the whole operating system.
Page 48: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack at the rear of the computer.
Page 49: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shutdown er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Stand by/Hibernate/ ways shut your comput- er down by choosing the Shutdown hot key button when it is pressed for less than 4 seconds (pressing and...
Page 50: Power Schemes
Power Management Power Schemes You can set your computer to conserve power through individual components by Resuming means of Power Schemes. You can also adjust the settings for each scheme to set Operation the monitor to turn off after a specified time, and the computer's hard disk motor to turn off if the hard disk drive has not been accessed for a specified period of time (if Press a key on the key- the system reads or writes data, the hard disk motor will be turned back on).
Page 51 Power Management Each Windows Power Scheme will also adjust the processor performance of your machine in order to save power. This is worth bearing in mind if you are experienc- ing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the com- puter is powered from an AC power source.
Page 52: System Power Options
Power Management System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Stand by and Hibernate sleep mode levels (Hibernate mode will need to be enabled by clicking the option in the Hibernate tab in the Power Options control panel - Figure 3 - 2 on page 3 - Hibernate Mode vs.
Page 53: Stand By
Power Management Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed.
Page 54: Configuring The Power Button
Power Management Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hiber- nate mode (Figure 3 - 3). In Stand by mode, the LED will blink green. In Hi- bernate mode the LED will be off.
Page 55: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” When the battery is criti- cally low, immediately on page 3 - 12 for instructions on how to do this).
Page 56: Recharging The Battery With The Ac/Dc Adapter
Power Management Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. Conserving Battery Power We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 57: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 58: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t Caution turn off the computer by yourself even when you see a message that indicates the Danger of explosion if battery is critically low, just let the computer use up all of the battery power and shut battery is incorrectly re-...
Page 59: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM contains the drivers and utilities necessary for vantage of some newer hardware components for the proper operation of the computer.
Page 60 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver in- stallation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”. In addition, all file extensions can be seen In this case “D:”...
Page 61: Service Packs
Drivers & Utilities Service Packs Check the warnings on the following pages regarding installation of the appropriate Service Pack for your Windows XP Service Pack 2 Windows OS. Make sure you have installed the appro- priate Service Pack before installing all the drivers. Make sure you install Windows XP Service Pack 2 (or a Windows XP version which includes Service Pack 2) before installing any drivers.
Page 62: Authorized Driver Message
Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Drivers If you receive a message telling you that the driver you If you wish to update/reinstall individual drivers it are installing is not authorized (Digital Signature Not may be necessary to uninstall the original driver.To do Found), just click Yes or Continue Anyway to ignore this go to the Control Panel in the Windows OS and the message and continue the installation procedure.
Page 63: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 6 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install WinXP Drivers (button).
Page 64: Service Pack Installation
Drivers & Utilities Service Pack Installation WinXP SP2 Driver Page # Make sure you install the appropriate service pack for your operating system before installing any drivers Install the appropriate Service Pack for WinXP Page 4 - 3 (see “Windows XP Service Pack 2” on page 4 - Chipset Page 4 - 7 Video...
Page 65: Chipset
Drivers & Utilities Chipset Audio 1. Click 1.Install Chipset Driver > Yes. 1. Click 3. Install Audio Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to D:\Drivers\Chipset\Setup.exe and click OK. D:\Drivers\Audio\Setup.exe and click OK.
Page 66: Lan
Drivers & Utilities Modem Note that you should click Cancel if a Found New 1. Click 5.Install Modem Driver > Yes. Hardware Wizard appears before installing the LAN driver. Click Start (menu) > Run... and navigate (Browse..) to 1. Click 4.Install LAN Driver > Yes. D:\Drivers\Modem\ssetup.exe and click OK.
Page 67: Pcmcia/Cardreader
Drivers & Utilities PCMCIA/CardReader TPM (Trusted Platform Module) 1. Click 6.Install CardReader Driver > Yes. 1. Click 7.Install TPM Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (Browse...) to D:\Drivers\TPM\setup.exe and click OK.
Page 68: Fingerprint Reader
Drivers & Utilities Fingerprint Reader Hot Key Utility 1. Click 8.Install Fingerprint Driver > Yes. 1. Click 9.Install Hotkey Utility > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to D:\Drivers\Fingerprint\autorun.exe and D:\Drivers\Hotkey\Setup.EXE and click OK.
Page 69: Bios Utilities Overview
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The PhoenixBIOS Setup Utility up Defaults with <F9>.
Page 70: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). Note that the POST As the POST proceeds, the computer will tell you if there is anything wrong. If there screen as pictured will is a problem that prevents the system from booting, it will display a system summary not appear if you have...
Page 71: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 72: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter the PhoenixBIOS Setup Utility, turn on the computer and press F2 during the POST.
Page 73: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with six (6) menu headings. When you se- Setup menus lect a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.
Page 74: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 PhoenixBIOS Setup Utility Main Menu Main Main Advanced Security Power Boot Exit Item Specific Help System Overview -------------------------------------------------------- <Tab>, <Shift Tab>, or BIOS Ver:1.00.08C <Enter> selects field. CPU Type: Intel U1400 CPU Speed 1200 MHz System Time: [16:11:05]...
Page 75: System Time & Date (Main Menu)
BIOS Utilities System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 76: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Security Power Boot Exit Advanced Item Specific Help Advanced Settings WARNING: Setting wrong values in below sections may cause system to malfunction. IDE Channel 0 Master [30006MB] IDE Channel 0 Slave [CD-ROM]...
Page 77: Internal Pointing Device (Advanced Menu)
BIOS Utilities Internal Pointing Device (Advanced Menu) Use this item to enable/disable the internal TouchPad (alternatively you can use the TouchPad power button to enable/disable the TouchPad). Onboard LAN Boot ROM (Advanced Menu) This item may be used to enable/disable the network boot option. Wake-Up On LAN (Advanced Menu) Enable/Disable the Wake-Up On LAN option here.
Page 78: Security Menu
BIOS Utilities Security Menu PhoenixBIOS Setup Utility Security Menu Main Advanced Security Security Power Boot Exit changes make here affect the Item Specific Help access to the Setup Supervisor Password Is: Clear utility itself, and also User Password Is: Clear Install HDD Password.
Page 79: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the PhoenixBIOS Setup Utility. This will not affect access to the computer OS, (only the PhoenixBIOS Setup Util- Password Warning ity). Many menu items in the PhoenixBIOS Setup Utility utility cannot be modified If you set a boot pass- in user mode.
Page 80: Set Hdd Password (Security Menu)
BIOS Utilities Set HDD Password (Security Menu) Press Enter to create a password for access to the computer’s hard disk when the computer boots up. Password Protection I/O Interface Security (Security Menu) Note that you should set The submenus here allow you to enable/disable the interface controllers for Blue- a supervisor password in the BIOS to protect tooth, PC Card/Card Reader, USB/Finger Print ID, LAN and Audio/Modem.
Page 81: Power Menu
BIOS Utilities Power Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Power Power Menu Item Specific Help Start Battery Calibration Press Enter to start calibrating a battery. The calibration should charge the battery to full and then discharge it to empty.
Page 82: Start Battery Calibration (Power Menu)
BIOS Utilities Start Battery Calibration (Power Menu) Press Enter to start the battery calibration process. The system will prompt you to plug-in the AC/DC adapter and will begin to charge the battery to full capacity. Once the battery has reached full capacity you will then be prompted to remove the AC/DC adapter with the computer left on.
Page 83: Boot Menu
BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 6 Main Advanced Security Power Boot Exit Boot Menu Item Specific Help Boot Settings ---------------------------------------------------------- Keys used to view or configure devices: Boot priority order: Up and Down arrows USB FDC: USB KEY: select a device.
Page 84: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 7 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Power Boot Exit Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...
Page 85: Upgrading The Computer Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 86: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning • Your system is still under warranty or a service contract Before you undertake •...
Page 87: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons 10 Cell Battery it is best to remove the battery. Your computer may come with a 4 cell battery Warning or a 10 cell battery , depending on your purchase configuration.
Page 88: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" or 1.8" Parallel (PA- HDD System TA) hard disks with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 89 Upgrading The Computer Remove the hard disk bay cover (and foam top cover for 1.8" hard disks). Figure 6 - 3 Hard Disk Bay Cover Removal Carefully lift the hard disk assembly up and disconnect the cable at point Figure 6 - 4 Cable Disconnect Upgrading the Hard Disk Drive 6 - 5...
Page 90 Upgrading The Computer Remove the hard disk from the bay, and then remove the case Reverse the process to install any new hard disk. Figure 6 - 5 Hard Disk Removal 6 - 6 Upgrading the Hard Disk Drive...
Page 91: Upgrading The Optical (Cd/Dvd) Device Drive
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Drive Turn off the computer, and turn it over and remove the battery. Locate the ODD release cover and remove the screw and cover Use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.
Page 92: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has one memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 93 Upgrading The Computer Carefully remove the component bay cover Figure 6 - 8 Component Cover Removal Gently pull the two release latches & on the sides of the memory socket. Figure 6 - 9 RAM Module Release Upgrading the System Memory (RAM) 6 - 9...
Page 94 Upgrading The Computer The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest hands have oils which can attract particles, and degrade the module’s performance.
Page 95: Modules & Options Overview
Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard This chapter contains the information on the Bluetooth, WLAN and Security mod- Aircraft ules which may come with your computer, depending on the configuration pur- The use of any portable chased.
Page 96: Bluetooth Module
Modules & Options Bluetooth Module If you have included a Bluetooth module in your purchase option, make sure that Wireless Device the optional Bluetooth module is on (the LED will be orange) before installing Operation Aboard the Bluetooth driver. Aircraft Use the Fn + F2 key combination (see “Function Keys”...
Page 97 Modules & Options 9. Configure the settings by going to the IVT Corporation BlueSoleil - Main Window control panel (Start > Programs/All Programs > IVT BlueSoleil > BlueSoleil), or click the taskbar icon User Guide View BlueSoleil User Guides from the Help Menu (or press the Send To Bluetooth F1 key) in the IVT Cor-...
Page 98: Intel Pro/Wireless Wlan Module
Modules & Options Intel PRO/Wireless WLAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe Wireless Device WLAN module in your purchase option, make sure that the Wireless LAN module Operation Aboard is on (the LED will be green) before installing the driver. Aircraft Use the hot key (see...
Page 99: Intel Wlan Driver Installation
Modules & Options Intel WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. User Guide 2. Click Install WinXP Drivers (button), and then click 11.Install WLAN You can view the User Driver >...
Page 100: Security Modules (Fingerprint & Tpm)
Modules & Options Security Modules (Fingerprint & TPM) The encrypted channel between the Trusted Platform Module security chip and Password Warning the fingerprint reader with Protector Suite Software provides a high level of se- curity for your computer. A further level of security and control is provided in the If you set passwords for BIOS (see “Security Menu”...
Page 101: Fingerprint Reader
Modules & Options Fingerprint Reader Make sure you have installed the Trusted Platform Module (see page 9) and Help & Manual Fingerprint (see page 10) drivers before configuring the fingerprint and security system. Right-click the taskbar icon to bring up the menu to Make sure you have administrator’s rights to your computer, and have a Windows select Help.
Page 102 Modules & Options Click Next for each window of the tutorial (you can click the button to “skip tutorial” at any time). Click the button above any of the fingers to begin the enrollment process for that Fingerprint finger. Enrollment Swipe the finger three times to enroll that finger.
Page 103 Modules & Options 15. See “Help & Manual” on page 7 - 7 for further details. 16. If you swipe your finger over the reader at any time you can access the Biomenu to lock the computer, register websites, Unlock My Safe, open the Control Control Center Center and access the Help menu.
Page 104: Trusted Platform Module
Modules & Options Trusted Platform Module Before setting up the TPM functions you must initialize the security platform. Backup & Archive Initializing TPM Note that it is very im- Restart the computer. portant to perform rou- Enter the PhoenixBIOS Setup Utility by pressing F2 during the POST (or press tine backup and archive Enter and select Launch System Setup).
Page 105 Modules & Options Click Start > Programs/All Programs > Infineon Security Platform Solution > Manage Security Platform, or double-click the taskbar icon , to bring up the Infineon Security Platform Initialization Wizard. Owner Password Click User Settings (tab), and then click Yes. Click Next and select either Initialize a new Security Platform, or Restore a It is recommended that you Security Platform from a Backup Archive, and click Next.
Page 106 Modules & Options 12. If you have chosen to set an Automatic Backup you will need to browse to a location for the backup, and you can also Schedule any backups required. Recovery & Password Reset Tokens It is strongly recommended that you save your Recov- ery/Password Reset To- kens...
Page 107: Tpm User Set Up
Modules & Options 15. Click Next to confirm the settings. 16. If you want to use the TPM for this account select Start Security Platform User Initialization Wizard and click Finish. Figure 7 - 9 Initialization Screens 17. The Wizard will now continue to take you through setting up a user (or see below). TPM User Set Up To use the TPM you must be set up as a user.
Page 108 Modules & Options Save a location for a Basic User Password reset file, and click Next. Help To learn more about all the features click Start > Programs/All Pro- grams > Infineon Se- curity Platform Solution > Help on Se- curity Platform.
Page 109: Initialize The Tpm For Use With The Protector Suite Software
Modules & Options Initialize the TPM for use with the Protector Suite Software Click Start > Programs/All Programs > Protector Suite QL > Control Center, or select the Control Center from the Biomenu or right click the taskbar icon select Start Control Center. Click Settings >...
Page 110 Modules & Options 7 - 16...
Page 111: Troubleshooting Overview
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 112: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 113: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 114: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 115: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 116 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 117: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 118 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 119 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 120 Troubleshooting Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.
Page 121: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 122: Notebook Ports And Jacks
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Built-In Microphone The built-in microphone allows you to record on your computer Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device.
Page 123: Mini-Ieee 1394 Port
Interface (Ports & Jacks) Item Description Mini-IEEE 1394 Port This port allows a high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. RJ-11 Phone Jack This port connects to the built-in modem.
Page 124: Usb 2.0/1.1 Ports
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).
Page 125: Intel Video Driver Controls
Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Intel Video Driver Installation Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 6.
Page 126: Dynamic Video Memory Technology
Intel Video Driver Controls Dynamic Video Memory Technology ® Intel DVMT 3.0 automatically and dynamically allocates as much (up to 128MB) DVMT Notes system memory (RAM) as needed to the video system (the video driver must be installed - see page 1).
Page 127: Intel Graphics Properties
Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for Mobile. You can also access the Open Display Properties (see “Video Features” on page 1 - 14) and click controller properties...
Page 128 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.
Page 129: Scheme Options
Intel Video Driver Controls Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate Open the Intel(R) GMA Driver for Mobile control panel (see “Intel Graphics the actual application...
Page 130: Attaching Other Displays
Intel Video Driver Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display as Intel Display Note a display device. The following are the display options: Note that the notebook The built-in LCD OR an external monitor/flat panel display connected to the exter- is the default Primary nal monitor port (Single Display).
Page 131: Display Modes
Intel Video Driver Controls Display Modes Single Display Function Key Only one of your attached displays is used. Combination You can use the Fn + F7 Twin key combination to tog- This mode will drive multiple displays with the same content and resolutions, color gle through the display options: quality etc.
Page 132 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Mode OR Twin Mode Attach your external display to the external monitor port and turn it on. Open the Intel(R) GMA Driver for Mobile control panel (see “Intel Graphics Twin Mode Support Properties”...
Page 133 Intel Video Driver Controls To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port and turn it on. Open the Intel(R) GMA Driver for Mobile control panel (see “Intel Graphics Display Settings Properties” on page B - Extended Desktop Click to choose Extended Desktop from Display Devices (tab).
Page 134 Intel Video Driver Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if Display Settings you are in Category View choose Appearance and Themes). Extended Desktop Double-click Display (icon).
Page 135: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly pro- cessor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release schedule.
Page 136: Processor (Cpu On Board
Specifications Feature Specification Processor Intel® Core™ Solo Processor 65nm (65 Nanometer) Process Technology (CPU On Board) FC-PGA6 Package 2MB On-die L2 Cache & 533MHz FSB U1400 1.20 GHz Intel® Celeron® M Processor 65nm (65 Nanometer) Process Technology FC-PGA6 Package 1MB On-die L2 Cache & 533MHz FSB ULV 423 1.06 GHz Core Logic...
Page 137: Video Adapter
Specifications Feature Specification Video Adapter Intel 945GMS Integration Intel® Graphics Media Accelerator 950 (Intel® GMA 950) Dynamic Video Memory Technology DVMT 3.0 - Supports up to 128MB of Video Memory (dynamically allocated from system memory where needed) Supports DualView™ Storage Optional Device Drive Bay Options: One Changeable 9.5mm(h) Optical Device (CD/DVD) Type Drive (see “Optional”...
Page 138: Communication
Specifications Feature Specification Communication AZALIA 56K Fax Modem - V.90 & V.92 Compliant 10/100M Fast Ethernet LAN Intel PRO/Wireless 3945ABG PCIe Interface Wireless LAN Module (Option) USB (2.0) Bluetooth Module (Option) Power Supports ACPI 2.0 and APM v 1.2 Supports Wake On Modem Ring Management Supports Wake On LAN Power...
Page 139: Optional
Specifications Feature Specification Optional Optical Device Module Options: Intel PRO/Wireless 3945ABG PCIe Interface Dummy ODD Wireless LAN Module (Option) DVD-ROM Drive Module 10 Cell Smart Lithium-Ion Battery Pack, DVD/CD-RW Combo Drive Module 13000mAH, 96.2W DVD Dual - Supporting Super MULTI Drive Module USB (2.0) Bluetooth Module (Including Bluetooth Cable)
Page 140 Specifications C - 6...

EUROCOM Notebook User Manual

Quick Start Guide Overview

Features & Components Overview

Power Management Overview

Drivers & Utilities

BIOS Utilities Overview

Upgrading the Computer Overview

Modules & Options Overview

Troubleshooting Overview

Intel Video Driver Controls

Specifications

Interface

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM Notebook

Summary of Contents for EUROCOM Notebook

Table of Contents
