Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 8: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 14: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 15: Table Of Contents
Preface Contents Notice .................I Windows Vista Start Menu & Control Panel ....1-14 FCC Statement .............II Video Features .............1-15 Instructions for Care and Operation ......IV Display Devices & Options ........1-16 Power Safety .............. VI Power Options ..............1-17 Battery Precautions ...........VII Storage Devices, Mouse, Audio &...
Page 16 Preface Parallel Printer ............2-12 Drivers & Utilities RAID & AHCI Setup ..........4-1 Power Management What to Install ..............4-1 Overview ................3-1 Module Driver Installation ..........4-1 The Power Sources ............3-2 Driver Installation ............4-2 AC/DC Adapter ............3-2 Manual Driver Installation .........4-3 Battery .................3-2 Updating/Reinstalling Individual Drivers ....4-4 Turning on the Computer ..........3-3 User Account Control (Win Vista) ......4-4...
Page 17 Preface BIOS Utilities Upgrading The Computer Overview ................5-1 Overview ................6-1 The Power-On Self Test (POST) ........5-2 When Not to Upgrade ..........6-2 Failing the POST ............5-3 Removing the Battery ............6-3 Fatal Errors ..............5-3 Upgrading the Hard Disk Drive(s) .........6-4 Non-Fatal Errors ............5-3 Upgrading the System Memory (RAM) ......6-7 The Setup Program ............5-4 Upgrading the Optical (CD/DVD) Device(s) ....6-10...
Page 18 Preface PC Camera Audio Setup ...........7-18 DVI-Out Port ..............A-2 BisonCap (for 1.3M pixel camera module) ....7-20 External Monitor Port ...........A-2 Eliminating Screen Flicker (BisonCap) ....7-21 Headphone-Out Jack .............A-3 Video View (for 2.0M pixel camera module) ...7-22 Line-In Jack ..............A-3 Mini-PCI TV Tuner Module ........7-25 Microphone-In Jack ............A-3 MPC788/MPC718 Driver &...
Page 19 Preface Specifications Video Features ..............D-7 Display Properties ............D-8 Processor Types ............C-2 Display Devices & Options ...........D-9 Core Logic ..............C-2 SLI Multi GPU Configuration ........D-10 LCD ................C-3 Attaching Other Displays ..........D-12 Security ................. C-3 To Enable Windows Extended Desktop ...... D-14 Memory .................
Page 20 Preface Chipset ................D-28 Video View (for 2.0M pixel camera module)....D-49 Video ................D-28 Eliminating Screen Flicker (Video View) ....D-50 Audio ................D-28 Mini-PCI TV Tuner Module ........D-52 Modem ................D-28 MPC788/MPC718 Driver & Cyberlink LAN ................D-28 PowerCinema Installation ...........D-52 TouchPad ..............D-29 Card Reader/ExpressCard ...........D-29 Ap-Key Utility ............D-29 Module Drivers............
Page 21: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 23: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/ Windows XP etc.) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 24: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, TV Tuner Module you will find the following operating systems are supported: Support Note that the TV Tuner module (factory) options...
Page 25: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 26: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Optional Built-In PC Camera LED Power & Wireless Device Operation Communication Aboard Aircraft Indicators Built-In The use of any portable electronic Microphone transmission devices (e.g. WLAN or LED Status Bluetooth) aboard aircraft is usually prohibited.
Page 27: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The two sets of LED indicators (LED Status Indica- Orange DC Power is Plugged In tors and LED Power & Communication Indicators) on the computer display helpful information about the Green The Computer is On current status of the computer.
Page 28: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard The keyboard has a numerical keypad for easy numer- ic data input, and features Function Keys to allow you These buttons give instant access to the default Inter- to change operational features instantly. net browser and e-mail program, and to a user-defined application, with one quick button press.
Page 29 Quick Start Guide Keys Description Keys Description Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F7 Display Toggle Fn + F1 TouchPad Toggle Fn + F8 Decrease LCD Brightness Fn + 1 Fan Automatic Control / Full Power Fn + F9 Increase LCD Brightness Fn + F3 Mute Toggle...
Page 30: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views LCD Latches Line-In Jack S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Speakers Vent/Fan Intake DC-In Jack DVI-Out Port 10. S-Video-In Jack Enabled with Optional Mini-PCI TV Tuner Only Overheating To prevent your computer from overheating make sure nothing blocks the vent(s)/fan intake(s) while the computer is in use.
Page 31: System Map: Left View
Quick Start Guide System Map: Left View External Monitor Port S-Video-Out Jack Cable (CATV) Antenna Jack RJ-11 Phone Jack RJ-45 LAN Jack Mini-IEEE 1394 Port Mini-IEEE 1394 Port Express Card Slot The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. Optical Device Drive Bay (for ExpressCard Slot...
Page 32 Quick Start Guide Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 33: System Map: Right & Bottom Views
Quick Start Guide System Map: Right & Bottom Views USB Ports Security Lock Slot Battery (Secondary HDD Bay - HDD3) Fan Outlet/Intake Primary HDD Bay (HDD1 & HDD2) Component Bay Cover Battery Information Always completely discharge, then fully charge, a new battery before using it.
Page 34: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 35: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - 1.
Page 36: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display (con- nected to the DVI-Out port) or TV (connected to the S-Video-Out jack) as your display device. Figure 1 - 8 - Display Settings &...
Page 37: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 38 Quick Start Guide 1 - 18...
Page 39: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 40: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 41: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage Options” on page C - Adjustment 4).
Page 42: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 43: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 44: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 45: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 46: Application Hot Key
Storage Devices, Mouse, Audio & Printer Application Hot Key The hot key buttons give instant access to the default Internet browser and e-mail Application.exe program, and to a user-defined application, with one quick button press. To config- ure a program to open when the application hot key is pressed (Windows Media You will need to locate Player is the default program), follow the instructions below (make sure you have...
Page 47: Game Keys
Storage Devices, Mouse, Audio & Printer Game Keys The two game hot keys on the left of the computer allow macros to be configured for common keystrokes used in applications (the keys can assigned macros for any program, not only games). To configure the keys follow the instructions below (make sure you have installed the Ap-Key Utility driver - see “Ap-Key Utility”...
Page 48: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 49: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 50: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 51: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 52: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 53: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate/Shut ways shut your comput- er down by choosing the Down hot key button when it is pressed for less than 4 seconds (pressing and holding...
Page 54: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 55 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 56: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 57: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 58: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 59: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume send the computer to...
Page 60: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 61: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 62: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 63: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 64: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 65 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 66 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 67: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual of the computer’s subsystems. The system takes ad- DVD-ROM contains the drivers and utilities necessary vantage of some newer hardware components for for the proper operation of the computer.
Page 68: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the DVD-ROM and click Install Drivers (button), or click Drivers Installer menu below.
Page 69: Manual Driver Installation
Drivers & Utilities Manual Driver Installation To install the drivers manually click the Browse CD button in the Drivers Installer application and browse to the executable file in the appropriate driver folder. Driver Page Notes Video (VGA) Page 4 - 5 Audio Page 4 - 5 Modem...
Page 70: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 71: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Modem 1. Click 3.Install Modem Driver > Yes. Video (VGA) 2. Click OK. 1. Click 1.Install Video Driver > Yes. 3. The modem is now ready for configuration. 2. Click Next. 3. Click Finish to restart the computer. Modem Country Selection Audio Go to the Phone and Modem Options control panel...
Page 72: Card Reader/Expresscard
Drivers & Utilities Card Reader/ExpressCard Optional Drivers 1. Click 5.Install CardReader Driver > Yes. See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- 2. Click Next. tion. 3. Click the button to accept the license, and then click Next.
Page 73: Intel Matrix
Drivers & Utilities Intel Matrix PC Camera This driver is only required if you have set up your See the camera instructions in “PC Camera Driver hard disks in RAID or AHCI modes (see “Setting Up Application” on page 7 - SATA RAID or AHCI Modes”...
Page 74 Drivers & Utilities 4 - 8...
Page 75: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to PhoenixBIOS Setup Utility malfunction. To correct If your computer has never been set up, or you are making important changes to the mistakes, return to Set- up and restore the Set- system (e.g.
Page 76: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 77: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 78: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter the PhoenixBIOS Setup Utility, turn on the computer and press F2 during when you see the prompt "Press F2 to Enter Setup", which is usually present for a few seconds after you turn on the system.
Page 79: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 80: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Phoenix TrustedCore(tm) Setup Utility Main Menu Main Main Advanced Security Boot Exit Item Specific Help System Time: [08:11:05] System Date: [03/05/2007] <Tab>, <Shift Tab>, or SATA Port 1 [None] <Enter> selects field. SATA Port 2 [60012MB SATA2] SATA Port 3...
Page 81: Sata Port 1/2/3: (Main Menu)
BIOS Utilities SATA Port 1/2/3: (Main Menu) Pressing Enter opens the sub-menu to show the configuration of hard disks on the computer’s SATA ports. Use the Auto (Type:) setting to have the items configured automatically for you. IDE Channel 0 (Main Menu) Pressing Enter here opens the sub-menu to show the configuration of the CD/DVD device(s) on the computer’s IDE Channel.
Page 82: Advanced Menu
BIOS Utilities Advanced Menu Phoenix TrustedCore(tm) Setup Utility RAID/AHCI Main Advanced Advanced Security Boot Exit Enable/Disable Item Specific Help Warning Setup Warning Setting items on this menu to incorrect Normal/RAID/AHCI Mode values may cause your system to malfunction. DO NOT Enable/Dis- able SATA RAID or SATA Mode: [Normal]...
Page 83: Reset Configuration Data: (Advanced Menu)
BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 84: Security Menu
BIOS Utilities Security Menu Phoenix TrustedCore(tm) Setup Utility Security Menu Main Advanced Security Security Boot Exit changes Item Specific Help make here affect the access to the Setup Supervisor Password Is: Clear Supervisor Password utility itself, and also controls access to the Set Supervisor Password [Enter] setup utility.
Page 85: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...
Page 86: Boot Menu
BIOS Utilities Boot Menu Phoenix TrustedCore(tm) Setup Utility Figure 5 - 5 Main Advanced Security Exit Boot Boot Menu Item Specific Help Boot priority order: USB FDC: Keys used to view or USB KEY: configure devices: PCI SCSI: Up and Down arrows IDE HDD: TOSHIBA MK6034GSX-(S2) IDE CD: Optiarc DVD RW AD-7530A-(S select a device.
Page 87: Exit Menu
BIOS Utilities Exit Menu Phoenix TrustedCore(tm) Setup Utility Figure 5 - 6 Exit Menu Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit System Setup and Exit Discarding Changes save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...
Page 88 BIOS Utilities 5 - 14...
Page 89: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 90: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 91: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Loosen screws before undertaking any...
Page 92: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage Options” on page C - Follow your operating system’s installation instructions, and install all necessary New HDD’s are blank.
Page 93 Upgrading The Computer Remove screws and lift the hard disk assembly out of the computer. Remove screws Separate the hard disk(s) from the bracket and connector cable Insert the new hard disk into the computer. Re-Insert the bracket and insert screws. Figure 6 - 3 Primary HDD Removal...
Page 94 Upgrading The Computer Removing the Hard Disk(s) in the Secondary HDD Bay Turn off the computer, and turn it over and remove the battery. The secondary hard disk bay is located under the battery compartment. Remove screw Slide the hard disk assembly in the direction of the arrow Lift the hard disk assembly out of the compartment.
Page 95: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDR II (DDR2) type memory modules (see “Memory” on page C - 3). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 96 Upgrading The Computer Remove screws from the RAM fan. Figure 6 - 6 RAM Fan Screws Remove the RAM fan Figure 6 - 7 RAM Fan Removal 6 - 8 Upgrading the System Memory (RAM)
Page 97 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in the direction indicated by the arrows in Figure 6 - 8 The RAM module will pop-up, and you can remove it. Contact Warning Be careful not to touch the metal pins on the...
Page 98: Upgrading The Optical (Cd/Dvd) Device(S)
Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn the computer off, turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the bay cover Remove screw and use the screwdriver to push the optical device(s) out of the computer at point Figure 6 - 9 Removing the CD/...
Page 99: Upgrading The Video Card
Upgrading The Computer Upgrading the Video Card If you intend to upgrade or add another VGA card follow the procedures outlined Warranty Warning here. However please check with your service representative first to make sure your computer can support more than one video card, and that you are not going to void Please check with your your warranty.
Page 100 Upgrading The Computer Remove screws from the video card fan. Disconnect the fan cable Figure 6 - 11 Video Card Fan Screws Remove the video card fan Figure 6 - 12 Video Card Fan Removal 6 - 12 Upgrading the Video Card...
Page 101 Upgrading The Computer Remove screws from the video card heatsink in the order indicated on the label. Remove screws & Caution Grip the handle and carefully remove the heatsink The heat sink, and video card area in general, contains parts which are subject to high tempera- tures.
Page 102 Upgrading The Computer 10. Remove screw from the video card. 11. Carefully remove the video card Figure 6 - 14 Video Card Removal 6 - 14 Upgrading the Video Card...
Page 103 Upgrading The Computer Installing a New Video Card Prepare to fit the video card into the slot by holding it at about a 30° angle. Contact Warning Be careful not to touch the metal pins on the VGA card’s connecting edge.
Page 104 Upgrading The Computer Fit the connectors firmly into the socket, straight and evenly. DO NOT attempt to push one end of the card in ahead of the other. Figure 6 - 16 Video Card Insertion Procedure The card’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go (none of the gold colored contact should be showing).
Page 105 Upgrading The Computer Secure the card with screw (Figure 6 - 14 on page 6 - 14). Place the heatsink back on the card, and secure the screws in the order indicated Figure 6 - 13 on page 6 - Attach the video card fan and secure with the screws as indicated in Figure 6 - 11 on page 6 -...
Page 106 Upgrading The Computer 6 - 18...
Page 107: Modules
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 108: Setting Up Sata Raid Or Ahci Modes
Modules Setting Up SATA RAID or AHCI Modes AHCI Mode Advanced Host Controller Interface (AHCI) is an interface specification that allows the storage driver to enable advanced serial ATA features such as Native Command Queuing (for maximum hard disk efficiency and performance). AHCI mode can be supported by one, two or three hard disks.
Page 109 Modules RAID Level Description Array Types Identical drives reading and writing data in parallel to increase performance. RAID 0 RAID 0 implements a striped disk array and the data is broken into blocks and each block is Mirrored Array written to a separate disk drive. (RAID 1) provides full Identical drives in a mirrored configuration used to protect data.
Page 110: Sata Raid Or Ahci Setup Procedure (Bios)
Modules SATA RAID or AHCI Setup Procedure (BIOS) Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "SATA Mode" and press Enter. • For RAID Mode: - Set "SATA Mode" (“SATA Mode: (Advanced Menu)” on page 5 - 8) to "RAID".
Page 111: Raid Setup (Intel Matrix)
Modules RAID Setup (Intel Matrix) Press Ctrl + i to enter RAID configuration menu. Intel(R) Matrix Storage Manager option ROM v6.1.0.1002 ICH8R wRAID5 Copyright (C) 2003-06 Intel Corporation. All Rights Reserved. Figure 7 - 1 [ MAIN MENU Create RAID Volume Intel(R) Matrix Delete RAID Volume Reset Disks to Non-RAID...
Page 112 Modules 10. This will now return to the main menu. Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5 Copyright (C) 2003-06 Intel Corporation. All Rights Reserved. Figure 7 - 2 [ MAIN MENU RAID Created Create RAID Volume Delete RAID Volume Reset Disks to Non-RAID Exit [ DISK/VOLUME INFORMATION ]...
Page 113: Intel Matrix
Modules Intel Matrix Make sure you install the Intel matrix driver and application if you have set up your hard disk(s) in AHCI or RAID modes. Intel Matrix Driver Installation 1. Click 1.Install Intel Matrix > Yes. 2. Click Next > Next > Yes > Next. 3.
Page 114: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) or Intel Wireless Device PRO/Wireless 4965AGN (802.11a/g/n) PCIe WLAN module , make sure that the Operation Aboard Wireless LAN module is on before installing the driver. Use the Fn + F11 key com- Aircraft bination (see Table 1 - 5, on page 1 -...
Page 115: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 4 Taskbar Menus Right-click icon Click icon In the Show list, click to choose Wireless from the drop-down menu.
Page 116 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 6 Connecting Move the cursor over the taskbar icon...
Page 117 Modules To disconnect from the wireless network you can click the taskbar wireless icon and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network...
Page 118: Bluetooth Module
Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft Make sure that the Bluetooth module is on.
Page 119 Modules User Guides & Help View BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Cor- poration BlueSoleil - Main Window control panel. Click the Help menu select Contents and Index. Look through Getting Started or select the ap- propriate User Guide from...
Page 120 Modules Bluetooth Local Area Connection You can check the Bluetooth connection status from the Network and Sharing Center: Disconnecting Use the Fn + F12 key combination to turn on the Bluetooth module. In order to have the Local Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu. Area Connection icon dis- play the correct connection Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 121 Modules Do not use the close button or Fn + F12 key combination before clicking File > Exit or the correct status will not be displayed. You can then use the Fn + F12 key combination to turn off the Bluetooth module (check the LED icon for the Bluetooth module power status).
Page 122: Pc Camera Module
Modules PC Camera Module If you have included the PC Camera module in your purchase option, you will have the appropriate application provided on the Device Drivers & Utilities + User’s Manual DVD-ROM . There are 2 camera options available for this computer, de- pending on your purchase configuration.
Page 123: Pc Camera Driver Application
Modules PC Camera Driver Application 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. 2. Click Optional, and then click 4.PC Camera, Web cam > Yes. For the 1.3M Pixel Camera Module: 3.
Page 124: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. PC Camera & TV Tuner Click Start, and click Control Panel (or point to Settings and click Control Panel). If you have the optional Click Sound (Hardware and Sound).
Page 125 Modules Figure 7 - 12 Audio Setup for PC Camera Right-click PC Camera Module 7 - 19...
Page 126: Bisoncap (For 1.3M Pixel Camera Module)
Modules BisonCap (for 1.3M pixel camera module) BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- You may pre-allocate Cam menu (it is recommended that you set the capture file before the capture the file size for the cap-...
Page 127: Eliminating Screen Flicker (Bisoncap)
Modules Eliminating Screen Flicker (BisonCap) If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 128: Video View (For 2.0M Pixel Camera Module)
Modules Video View (for 2.0M pixel camera module) Video View is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the Video View program from the Start > Programs/All Programs > USB2.0 You may pre-allocate the PC Camera menu (it is recommended that you set the capture file before the file size for the capture file...
Page 129 Modules Eliminating Screen Flicker (Video View) If you find that the video screen in the Video View program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the Video View program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Flickering Reduction in Image (tab).
Page 130 Modules Zoom (Video View) If you have enabled digital zoom when installing the 2.0M Pixel Camera driver you may use the Options > Setting menu to zoom the camera in and out. Run the Video View program. Figure 7 - 15 Go to Options and scroll down to select Setting.
Page 131: Mini-Pci Tv Tuner Module
Modules Mini-PCI TV Tuner Module A CD containing drivers, software and a user guide will be supplied if your purchase TV Antenna configuration includes the optional Mini-PCI TV Tuner module. The MPC788 The TV antenna supplied module features both Analog and Hybrid (Analog & Digital) options; the MPC718 with any TV Tuner module is a Hybrid module.
Page 132: Mpc788/Mpc718 Driver & Software
Modules MPC788/MPC718 Driver & Software 1. Insert the MPC788 or MPC718 driver CD-ROM into the CD/DVD drive. 2. Click Vista Driver Setup. TV Tuner Module 3. Click Install > OK. Support Note that the TV Tuner MPC788 Module module options in Win- 1.
Page 133 Modules MPC718 Module 1. This TV Tuner module is fully supported by Windows Media Center in Windows Vista (Home Premium Edition & Ultimate Edition). 2. Run Windows Media Center directly from the Start menu (Start > Pro- grams > Windows Media Center). 3.
Page 134: Digital Tv Broadcast Signal
Modules Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.
Page 135 Modules Mute Teletext Home Power Button DVD/VCD Music Pictures Videos Back 10. Radio 11. Information Figure 7 - 18 12. Cursor Buttons & OK Remote Control Unit 13. SAP (Secondary Audio Programming) (For MPC Modules) 14. Live TV 15. DVD Menu 16.
Page 136 Modules 7 - 30...
Page 137: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 138: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 139: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 140: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 141: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 142 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 143: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 144 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 145 Troubleshooting Problem Possible Cause - Solution Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. The sound cannot be The volume might be set too low.
Page 146 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark. keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 147: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 148: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) Cable (CATV)
Page 149: Headphone-Out Jack
Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. Note that audio input through Line-in will default to the mute setting.
Page 150: Rj-45 Lan Jack
Interface (Ports & Jacks) Item Description RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1”...
Page 151: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card Options NVIDIA Video Driver Installation Note that card types, Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - specifications and driv- ers are subject to contin-...
Page 152: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 16) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 153 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 154 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 155: Sli Multi Gpu Configuration
NVIDIA Video Driver Controls SLI Multi GPU Configuration This computer features an NVIDIA Scalable Link Interface (SLI) that improves SLI Configuration & graphic quality and performance by combining dual NVIDIA GPUs in a single sys- Multiple Displays tem. To enable/disable SLI Configuration: Note that if SLI configu- Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 156: Sli Multi Gpu Configuration & Battery Power
NVIDIA Video Driver Controls SLI Multi GPU Configuration & Battery Power Note that due to the high power and system demands created by enabling SLI Con- figuration, you should not enable SLI configuration if your computer is powered by battery only. If you attempt to run an SLI configuration when the computer is powered by the battery only, then system problems may occur.
Page 157: Display Devices
NVIDIA Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel display or Function Key TV as your display device. The following are the display options: Combination The built-in LCD. You can use the Fn + F7 An external monitor connected to the DVI-Out Port or external monitor port.
Page 158: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Attach your external display to the external monitor port/DVI-Out Port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 159 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. SLI Configuration & Attach your external display to the external monitor port/DVI-Out Port (or TV to the Multiple Displays S-Video-Out jack), and turn it on.
Page 160: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Blu-ray/HD-DVD Only one of your displays is used. Support If your optical device drive Clone Mode option includes a Blu-ray/ Clone Mode simply shows an exact copy of the Primary display desktop on the other HD-DVD device, please display(s).
Page 161 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port/DVI-Out Port (or TV to the S-Video-Out jack), and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 162 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port/DVI-Out Port (or TV to the S-Video-Out jack), and turn it on. Display Settings Click Start, and click Control Panel (or point to Settings and click Control Extended Desktop Panel).
Page 163: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays S-Video cable from the TV to the S-Video-Out jack on the left of the computer. To get a full range of dis- You will need to enable the TV display from the NVIDIA Control Panel as per the play options click...
Page 164: Changing The Tv Signal Format
NVIDIA Video Driver Controls Changing the TV Signal Format When the TV is enabled as a display device, click the sub-menus under Video & Television. Click “Change the signal or HD format” Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 165 Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 166: Processor Types
Specifications Feature Specification Processor Types Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology LGA775 Package (775-pin) 2MB On-die L2 Cache & 1066MHz FSB E6300/ E6400 1.86/ 2.13 GHz Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology LGA775 Package (775-pin) 4MB On-die L2 Cache &...
Page 167: Memory
Specifications Feature Specification 17.1" Glare Type Flat Panel TFT (For One of the Following Options) WXGA (1440 * 900) WSXGA+ (1680 * 1050) WUXGA (1920 * 1200) Security Security (Kensington® Type) Lock Slot BIOS Password Memory Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) 533/667/800 MHz 64-bit Wide DDRII (DDR2) Data Channels Memory Expandable up to 4GB (512/ 1024/ 2048 MB DDRII Modules Supporting HDCP) (Note: Do Not Use Other Module Types)
Page 168: Video Card
Specifications Feature Specification Video Card NVIDIA GeForce Go 7950 GTX PCI-E Video NVIDIA GeForce 8700M GT PCI-E Video Card - Card - SLI Compatible (NVIDIA Scalable Link SLI Compatible (NVIDIA Scalable Link Interface supported) Interface supported) MXM-IV MXM-IV Video Card 512MB GDDR3 Video RAM on Board, Supporting 512MB GDDR3 Video RAM on Board, Supporting Options...
Page 169: Audio
Specifications Feature Specification Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS MMC Cards Require a PC Adapter Audio UAA (Universal Audio Architecture) S/PDIF Digital Output Integrated Azalia Compliant Interface Built-In Microphone 4 * Built-In Speakers...
Page 170: Communication
Specifications Feature Specification Communication AZALIA MDC 56K Modem (V.90 & V.92 Compliant) USB 2.0 Bluetooth Class II Module (Option) 1.3M/2.0M Pixel USB 2.0 PC Camera Module 1GB PCIe Fast Ethernet LAN Module (Factory Option) Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module (Option) Intel PRO/Wireless 4965AGN PCIe Wireless LAN Module (Option)
Page 171: Optional
Specifications Feature Specification Physical 397mm (w) * 298mm (d) * 51 ~ 60mm (h) 5.4kg Dimensions & Weight Optional Optical Drive Module Options: Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module Combo Drive Module Intel PRO/Wireless 4965AGN PCIe Wireless LAN DVD-DUAL Module Module DVD-Super Multi Drive Module Blu-ray Drive Module...
Page 172 Specifications C - 8...
Page 173: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 174: Dvd Regional Codes
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 175 Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 176: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.
Page 177: Application Hot Key
Windows XP Information Application Hot Key The hot key buttons give instant access to the default Internet browser and e-mail Application.exe program, and to a user-defined application, with one quick button press. To configure a program to open when the application hot key is pressed (Windows Media You will need to locate the Player is the default program), follow the instructions below (make sure you install...
Page 178 Windows XP Information Game Keys The two game hot keys on the left of the computer allow macros to be configured for common keystrokes used in applications (the keys can assigned macros for any pro- gram, not only games). To configure the keys follow the instructions below. 1.
Page 179: Video Features
Windows XP Information Video Features You can switch display devices, and configure display options, from the Display GeForce Control Properties control panel in Windows as long as the appropriate video driver is in- Panel stalled. access Force..control panel To access Display Properties in Windows: from the desktop: 1.
Page 180: Display Properties
Windows XP Information Display Properties Figure D - 6 - Display Properties & NVIDIA Control Panel Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. This computer features an NVIDIA Scalable Link Interface (SLI) that improves graphic quality and performance by combining dual NVIDIA GPUs in a single system for some of the video card op- “SLI Multi GPU Configuration”...
Page 181: Display Devices & Options
Windows XP Information Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port or external monitor port;...
Page 182: Sli Multi Gpu Configuration
Windows XP Information SLI Multi GPU Configuration This computer features an NVIDIA Scalable Link Interface (SLI) that improves SLI Configuration & graphic quality and performance by combining dual NVIDIA GPUs in a single sys- Multiple Displays tem. To enable/disable SLI Configuration: Note that if SLI configura- 1.
Page 183 Windows XP Information Control Panels (NVIDIA) The NVIDIA Control Panel provides additional video configuration controls and tools which allows quick access to features such as display configuration, appear- Navigating the ance, mobile support and Help menus etc. Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 184: Attaching Other Displays
Windows XP Information Attaching Other Displays 1. Attach your external display to the external monitor port/DVI-Out Port (or TV to the S- Function Key Video-Out jack), and turn it on. Combination 2. Go to NVIDIA Control Panel (see “Video Features” on page B - 3.
Page 185 Windows XP Information 7. Click Change Resolution (Display) to adjust the display resolution for any attached displays. 8. Click the display icon and use the sliders to adjust the resolution. 9. Click Apply (and Yes to confirm the settings change). Figure D - 10 - Change Resolution Attaching Other Displays D - 13...
Page 186: To Enable Windows Extended Desktop
Windows XP Information To Enable Windows Extended Desktop 1. Attach your external monitor to the external monitor port and turn it on. 2. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).
Page 187: Enabling Tv Display
Windows XP Information Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an S- Detect Displays Video cable from the TV to the S-Video-Out jack on the left of the computer. To get a full range of dis- You will need to enable the TV display from the NVIDIA Control Panel as per the play options click “My...
Page 188: Changing The Tv Signal Format
Windows XP Information Changing the TV Signal Format 1. When the TV is enabled as a display device, click the sub-menus under Video & Television. 2. Click “Change the signal or HD format” 3. Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format). 4.
Page 189: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 190: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 191: Stand By
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 192: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate the LED will be off (battery) or orange (AC/DC adapter). If you are in a power saving mode set to save power through individual components (e.g.
Page 193: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 24). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 194: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 195: Proper Handling Of The Battery Pack
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 196: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 197: Driver Installation
Windows XP Information Driver Installation The Device Drivers & Utilities + User’s Manual DVD-ROM contains the drivers and utilities necessary for the proper operation of the computer. Table D - 3 lists what you need to install, and it is very important that the drivers are installed in the order indicated.
Page 198: What To Install
Windows XP Information What to Install 1. Check the driver installation order from Table D - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu This section covers driver and utility installation instruc- below.
Page 199: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 2 this go to the Control Panel in the Windows OS and Make sure you install Windows XP Service Pack 2 (or a double-click the Add/Remove Programs item.
Page 200: Chipset
Windows XP Information Chipset Modem 1. Click 1.Install Chipset Driver > Yes. 1. Click 4.Install Modem Driver > Yes. 2. Click Next > Yes > Next. 2. Click OK. 3. Click Finish to restart the computer. 3. The modem is now ready for configuration. Video 1.
Page 201: Touchpad
Windows XP Information TouchPad Module Drivers 1. Click 6.Install Touchpad Driver > Yes. See the following pages for the driver installation pro- cedures for any of the optional modules included in 2. Click Next > Next > Next. your purchase configuration. 3.
Page 202: Setting Up Sata Raid Or Ahci Modes
Windows XP Information Setting Up SATA RAID or AHCI Modes AHCI Mode Advanced Host Controller Interface (AHCI) is an interface specification that allows the storage driver to enable advanced Serial ATA features such as Native Command Queuing (for maximum hard disk efficiency and per- formance).
Page 203 Windows XP Information What to Prepare for RAID or AHCI Setup Prepare the following before setting up your serial ATA hard disks in RAID mode (to configure AHCI mode you do not need to prepare any extra hard disks but will need to install the Intel Matrix driver): An operable computer (to create a SATA RAID/AHCI driver diskette).
Page 204: Sata Raid Or Ahci Setup Procedure (Bios
Windows XP Information SATA RAID or AHCI Setup Procedure (BIOS) Go to the operable computer running Windows and insert a prepared formatted blank 3.5" 1.44MB floppy dis- kette. Insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive of the operable computer.
Page 205: Raid Setup (Intel Matrix
Windows XP Information RAID Setup (Intel Matrix) Press Ctrl + i to enter RAID configuration menu. Figure D - 20 Intel(R) Matrix Storage Manager option ROM v6.1.0.1002 ICH8R wRAID5 Copyright (C) 2003-06 Intel Corporation. All Rights Reserved. Intel(R) Matrix Storage Manager [ MAIN MENU Create RAID Volume Delete RAID Volume...
Page 206 Windows XP Information 10. This will now return to the main menu. Intel(R) Matrix Storage Manager option ROM v6.0.0.1022 ICH8R wRAID5 Figure D - 21 Copyright (C) 2003-06 Intel Corporation. All Rights Reserved. RAID Created [ MAIN MENU Create RAID Volume Delete RAID Volume Reset Disks to Non-RAID Exit...
Page 207: Windows Setup For Raid & Ahci Modes
Windows XP Information Windows Setup for RAID & AHCI Modes 13. Start the computer up, and press a key when you see the message "Press any key to boot from CD". 14. Press the F6 key when you see the message “Press F6 if you need to install third party SCSI or RAID driver”.
Page 208: Intel Matrix Driver Installation
Windows XP Information Intel Matrix Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. 2. Click Optional. 3. Click 1.Install Intel Matrix > Yes. 4. Click Next > Next > Yes > Next 5.
Page 209: Intel Wlan Module
Windows XP Information Intel WLAN Module Before installing the Intel PRO/Wireless 3945ABG (802.11a/b/g) or Intel PRO/Wireless 4965AGN (802.11a/g/n) WLAN driver use the Fn + F11 key combination to toggle power to the module. Intel WLAN Driver Installation 1. Make sure the module is powered on (use the Fn + F11 key combination to toggle power to the mod- ule), and then insert the Device Drivers &...
Page 210 Windows XP Information User Guide You can view the User Guides from the Device Drivers & Utilities + Us- er’s Manual DVD-ROM. Click Optional and then click the Unlock button. Click 2.Wireless Lan > Yes. Click View User Guide (button). Figure D - 24 Intel PROSet/ Wireless...
Page 211: Bluetooth Module
Windows XP Information Bluetooth Module Before installing the Bluetooth driver use the Fn + F12 key combination to toggle power to the module . Bluetooth Driver Installation 1. Make sure the module is powered on and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive.
Page 212 Windows XP Information User Guide View the BlueSoleil User Guides (Contents and In- dex) from the Help menu (or press the F1 key) in Corporation BlueSoleil - Main Win- dow control panel. Click BlueSoleil User Guides in the Contents tab, and click to select the appro- priate User Guide from the panel on the right.
Page 213 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Disconnecting 1. Access the Network Connections control panel in Windows (Start > Settings > Net- In order to have the taskbar work Connections OR Start >...
Page 214 Windows XP Information Use the Fn + F12 key combination to turn on the Bluetooth module. Run the IVT Corporation BlueSoleil program from the desktop icon or Start menu. The connection status will then be displayed. Figure D - 27 - Bluetooth Connected To disconnect click File from the IVT Corporation BlueSoleil - Main Window, and select Exit (the Local Area Connection will then display “A network cable is unplugged”).
Page 215: Pc Camera Module
Windows XP Information PC Camera Module Before installing the PC Camera driver use the Fn + F10 key combination to toggle Taking Still Pictures power to the module . There are 2 camera options available for this computer, de- pending on your purchase configuration. The 1.3M pixel camera module uses the Double-click BisonCap application to capture video files.
Page 216: Pc Camera Driver Installation
Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on and then insert the Device Drivers & Utilities + User’s Manual DVD-ROM into the CD/DVD drive. 2. Click Optional, and then click 4.PC Camera, Web cam > Yes. For the 1.3M Pixel Camera Module: 3.
Page 217: Pc Camera Audio Setup
Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows (see Figure D - 29 on page D - 46). Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 218 Windows XP Information Figure D - 29 Audio Setup for PC Camera D - 46 PC Camera Module...
Page 219: Bisoncap (For 1.3M Pixel Camera Modules
Windows XP Information BisonCap (for 1.3M pixel camera modules) BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space 1. Run the BisonCap application from the Start > Programs/All Programs > BisonCam You may pre-allocate the menu (it is recommended that you set the capture file before the capture process - see file size for the capture file...
Page 220: Eliminating Screen Flicker (Bisoncap
Windows XP Information Eliminating Screen Flicker (BisonCap) If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. 1.Run the BisonCap program. 2.Go to Options and scroll down to select “Video Capture Filter...”. 3.Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 221: Video View (For 2.0M Pixel Camera Module
Windows XP Information Video View (for 2.0M pixel camera module) Video View is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space 1. Run the Video View program from the Start > Programs/All Programs > USB2.0 PC You may pre-allocate Camera menu (it is recommended that you set the capture file before the capture pro- the file size for the cap-...
Page 222: Eliminating Screen Flicker (Video View
Windows XP Information Eliminating Screen Flicker ( Video View If you find that the video screen in the Video View program is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the Video View program. 2.
Page 223 Windows XP Information Zoom (Video View) If you have enabled digital zoom when installing the 2.0M Pixel Camera driver you may use the Options > Setting menu to zoom the camera in and out. 1. Run the Video View program. Figure D - 32 2.
Page 224: Mini-Pci Tv Tuner Module
Windows XP Information Mini-PCI TV Tuner Module The Mini-PCI TV Tuner Module driver and application (for MPC788/MPC718) are provided on a separate CD- ROM for Windows XP (see “Mini-PCI TV Tuner Module” on page 7 - 25 for further information). MPC788/MPC718 Driver &...
