System Map: Front & Rear Views
1
2
1
Note that the TV Tuner module (factory) option is supported by the Windows Media Cen-
ter software. Windows Media Center is not included in Starter or Home Basic versions
of Windows 7.
4
3
2
5
TV Tuner Module Support
1
2
1
2
System Map: Front & Rear Views 1 - 11
Quick Start Guide
Figure 1 - 5
Front View
1. Color LEDs
2. Speakers
3. LED Power
Indicators
4. Consumer Infrared
Transceiver
(enabled with
optional TV Tuner
only)
5. DC-In Jack
See Appendix A for a more
detailed description of the
ports & jacks etc.
1
