Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 8: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 15: Table Of Contents
Preface Contents Notice .................I System Map: Rear View ..........1-12 FCC Statement .............II System Map: Right View ..........1-13 Instructions for Care and Operation ......IV System Map: Left View ..........1-14 Power Safety .............. VI System Map: Bottom View ..........1-15 Battery Precautions ...........VII Windows Vista Start Menu &...
Page 16 Preface Configuring the Infrared Settings for FIR ....2-11 Proper handling of the Battery Pack ......3-12 Adding a Printer ............2-12 Battery FAQ ..............3-13 USB Printer ...............2-12 Drivers & Utilities Install Instructions: ...........2-12 Parallel Printer ............2-12 RAID Setup ..............4-1 What to Install ..............4-1 Power Management Module Driver Installation ..........4-1 Overview ................3-1...
Page 17 Preface Bluetooth ..............4-7 Security Menu ..............5-11 TV Tuner ..............4-7 Set Supervisor Password (Security Menu) ....5-11 Password on boot: (Security Menu) ......5-12 BIOS Utilities Boot Menu ..............5-13 Exit Menu ..............5-14 Overview ................5-1 The Power-On Self Test (POST) ........5-2 Upgrading The Computer Failing the POST ............5-3 Fatal Errors ..............5-3 Overview ................6-1...
Page 18 Preface Eliminating Screen Flicker ........7-11 Infrared (FIR) Transceiver ..........A-3 Bluetooth Module ............7-12 Line-In Jack ..............A-3 Bluetooth Driver Installation ........7-12 Microphone-In Jack ............A-3 Mini-PCI TV Tuner Module ........7-14 Mini-IEEE 1394 Port ............A-3 YUAN PVR Mini-PCI MPC622 TV Tuner Module .7-15 RJ-11 Phone Jack ............A-4 Installing the MPC622-64 Driver ......7-15 RJ-45 LAN Jack ............A-4 Setting Up SATA RAID ..........7-16...
Page 19 Preface Security ................. C-2 To Enable Extended Desktop (for NVIDIA VGA) ..D-11 Memory ................. C-2 Attaching Other Displays (for ATI VGA)....D-12 BIOS ................C-2 Power Management Features ........D-13 Video Card Options ............C-3 Power Schemes ............D-13 Storage Options ............C-4 System Power Options..........
Page 20 Preface TouchPad ..............D-26 Card Reader/ExpressCard ...........D-26 Hot Key Utility ............D-26 AutoMail Checker ............D-27 Module Drivers............D-27 PC Camera Driver Installation ........D-28 Intel WLAN Driver Installation ........D-29 802.11 b/g WLAN Driver Installation ......D-30 Bluetooth Driver Installation ........D-31 Mini-PCI TV Tuner Module ........D-32 Installing the LifeView FlyDVB-T Driver ....
Page 21: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 23: Model Differences
Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 24: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, TV Tuner Module you will find the following operating systems are supported: Support Note that the TV Tuner module (factory) options...
Page 25: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 26: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 Front View LCD Panel Open Wireless Device Operation Aboard Optional Built-In PC Camera Aircraft Hot Key Buttons The use of any portable Power Button electronic transmission Keyboard devices (e.g. WLAN or TouchPad and Buttons Bluetooth) aboard aircraft usually...
Page 27: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful Orange The Battery is Charging information about the current status of the computer. Blinking The Battery has Reached Critically Orange Low Power Status Green The Battery is Fully Charged Icon Color...
Page 28: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard The keyboard has a numerical keypad for easy numer- ic data input, and features Function Keys to allow you These buttons give instant access to the default Inter- to change operational features instantly. net browser and e-mail program, and to a user-defined application, with one quick button press.
Page 29 Quick Start Guide Keys Description Play/Pause Figure 1 - 3 - Keyboard Fn + ~ (in Audio/Video Programs) Fn + F1 TouchPad Toggle Fn + F2 Fan Automatic Control / Full Power Function Keys Fn + F3 Mute Toggle Fn + F4 Sleep Toggle Num Lk &...
Page 30: System Map: Front View (Audio "Dj")
Quick Start Guide System Map: Front View (Audio "DJ") Figure 1 - 4 - Front View (Audio "DJ") Audio "DJ" Power Button Volume Down Audio "DJ" MP3 Track Limit Volume Up There is a track limit of 256 tracks on any MP3 CD/ Repeat DVD.
Page 31: Audio "Dj" Cd Player
Quick Start Guide Audio "DJ" CD Player The built-in standalone audio CD player gives direct hardware control for audio CDs/DVDs when the com- TV Tuner Option puter is shut down, but has a working power source. If you have included the optional TV Tuner in your purchase configuration, you can use the supplied re- Make sure that the computer is shut down (i.e.
Page 32: System Map: Rear View
Quick Start Guide System Map: Rear View 9 10 Figure 1 - 5 - Rear View Vent/Fan Intake/Outlet S/PDIF-Out Jack Overheating Line-In Jack To prevent your computer from overheating make sure noth- 2 * USB 2.0 Ports ing blocks the Vent/Fan Intake/Outlet while the computer is in DVI-Out Port use.
Page 33: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 6 - Right View Headphone-Out Jack Microphone-In Jack 7-in-1 Card Reader Express Card Slot Mini-IEEE 1394 Port 2 * USB 2.0 Ports Speaker Mini-IEEE 1394 Port Both Mini-IEEE 1394 ports only support SELF POWERED IEEE 1394 devices. USB Ports ExpressCard Slot Note that the connections to...
Page 34: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 7 - Left View Security Lock Slot Speaker Optional Device Drive Bay (for CD/DVD Device, see page 3, or 2nd SATA Hard Disk, or 2nd Battery) 2nd Battery Notes Note that the 2nd battery is designed to optimize and boost the power performance of the system.
Page 35: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 8 - Bottom View Vent/Fan Intake/Outlet Battery Optical Device Release Latches Video Card / HDD / RAM Bay Cover Infrared & Consumer Infrared Transceiver Sub Woofer Battery Information Always completely discharge, then fully charge, a new battery before using it. Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 36: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 37: Video Features
Quick Start Guide Video Features This computer features different PCI Express video cards, depending on your purchase option (see “Video Card Options” on page C - 3). You can configure display options, from the Display Settings control panel in Win- dows as long as the appropriate video driver is installed.
Page 38: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display (con- nected to the DVI-Out port) or TV (connected to the S-Video-Out jack) as your display device. Video Card Options Note that card types, spec- ifications and drivers are...
Page 39: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 16) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 40 Quick Start Guide 1 - 20...
Page 41: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 42: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 43: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage Options” on page C - Adjustment 4).
Page 44: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 45: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 46: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 47: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 48: Application Hot Key
Storage Devices, Mouse, Audio & Printer Application Hot Key The hot key button gives instant access to a user-defined application, with one quick Application.exe button press. To configure a program to open when the application hot key pressed, install the driver (see “Hot Key Utility”...
Page 49: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 50: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 51: Configuring The Infrared Settings For Fir
Storage Devices, Mouse, Audio & Printer Configuring the Infrared Settings for FIR To configure your computer’s infrared port (on the right of the computer) for Far In- Infrared frared (FIR) communication follow these steps: Communication Click Start, and click Control Panel (or point to Settings and click Control The infrared transceiver Panel).
Page 52: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 53: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 54: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components (see page Attach the AC/DC adapter to the DC-In jack at the rear of the computer.
Page 55: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot key ways shut your comput- er down by choosing the button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 56: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and If the display is off the to send the computer into Sleep after a period of inactivity.
Page 57 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 58: System Power Options
Power Management System Power Options You can use the system power options to stop the computer’s operation and restart Sleep Button where you left off. The system features Sleep and Hibernate power saving states (Hibernate will need to be enabled from power plan Advanced Settings see Figure The Sleep Button 3 - 1 on page 3 -...
Page 59: Sleep
Power Management Sleep Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle Sleep Mode & at its slowest speed.
Page 60: Configuring The Power Button
Power Management Configuring the Power Button The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to either Sleep or Hibernate. In Sleep, the LED will blink green. In Protection Hibernate the LED will be off (battery) or orange (AC/DC adapter).
Page 61: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- cally low, immediately grams you are running, and peripheral devices attached.
Page 62: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 63: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 64: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 65: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 66 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 67 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 68 Power Management 3 - 16...
Page 69: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM (Win Vista OR WinXP) contains the drivers and vantage of some newer hardware components for utilities necessary for the proper operation of the com-...
Page 70: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install Drivers (button) >...
Page 71: Manual Driver Installation
Drivers & Utilities Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Drivers Installer application, and then browse to the executable file in the location listed in the table below and follow the installation procedure for each driver.
Page 72: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 73: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Modem 1. Click 4.Install Modem Driver > Yes. Chipset 2. Click OK > OK. This driver is included in the Windows Vista OS and 3. The modem is now ready for configuration. therefore does not need to installed from the CD. Video (VGA) 1.
Page 74: Touchpad
Drivers & Utilities TouchPad Optional Drivers 1. Click 6.Install Touchpad Driver > Yes. See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- 2. Click Next > Finish. tion. 3. Click Restart Now to restart the computer. 4.
Page 75: Wireless Lan
Drivers & Utilities Wireless LAN See the appropriate install procedure for your WLAN module in “Intel WLAN Driver Installation” on page 7 - 2/“802.11 b/g WLAN Driver Installation” on page 7 - PC Camera See the install procedure in “PC Camera Driver In- stallation”...
Page 76 Drivers & Utilities 4 - 8...
Page 77: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 78: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 79: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 80: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a...
Page 81: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.
Page 82: Main Menu
BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [16:11:05] System Date: [01/10/2007] IDE Channel 0 Master [TOSHIBA MK6034GSX-(SD1)] <Tab>, <Shift Tab>, or IDE Channel 0 Slave [None] <Enter>...
Page 83: Ide Channel 0/1 Master/Slave (Main Menu)
BIOS Utilities IDE Channel 0/1 Master/Slave (Main Menu) Pressing Enter here opens the sub-menu to show the configuration of hard disks and CD/DVD device(s) on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you. Installed Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 84: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Power Boot Exit Item Specific Help Advanced Chipset Control Select options for National 381 SIO Control Sub-Menu Advanced Chipset features. Reset Configuration Data: [No] Legacy USB Support: [Enabled]...
Page 85: Advanced Chipset Control (Advanced Menu)
BIOS Utilities Advanced Chipset Control (Advanced Menu) Pressing Enter here will access the sub-menus which allow you to adjust advanced CPU controls. You can also enable/disable the SATA RAID function (see “Setting Up SATA RAID” on page 7 - 16), and the PXE OPROM (network boot) option. PhoenixBIOS Setup Utility Advanced Advanced...
Page 86: National 381 Sio Control Sub-Menu (Advanced Menu)
BIOS Utilities National 381 SIO Control Sub-Menu (Advanced Menu) The sub-menus under this item allow you to enable/disable the Serial port A (Serial Mouse), and FIR (Infrared) transceiver. Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 87: Security Menu
BIOS Utilities Security Menu Figure 5 - 5 PhoenixBIOS Setup Utility Security Menu Security Main Advanced Security Boot Exit Item Specific Help Supervisor Password Is: Clear Supervisor Password Set Supervisor Password [Enter] controls access to the Password on boot: [Disabled] setup utility.
Page 88: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...
Page 89: Boot Menu
BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 6 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB FDC: Keys used to view or USB KEY: configure devices: IDE CD: PIONEER DVD-RW DVR-K16RS-( Up and Down arrows IDE HDD: TOSHIBA MK6034GSX-(S1)
Page 90: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 7 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and save your changes to Load Setup Defaults CMOS. Discard Changes Save Changes Help...
Page 91: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 92: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 93: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, turn it over and remove the battery. service representative Slide latch...
Page 94: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s) The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage Options” on page C - Follow your operating system’s installation instructions, and install all necessary New HDD’s are blank.
Page 95 Upgrading The Computer Remove screws and lift the bracket up from the hard disk. Slide the hard disk in the direction of the arrow Remove the hard disk Insert the new hard disk into the computer. Re-Insert the bracket and insert screws Figure 6 - 3 HDD Removal Upgrading the Hard Disk Drive(s) 6 - 5...
Page 96: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDR II (DDR2) type memory modules (see “Memory” on page C - 2). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 97 Upgrading The Computer Gently pull the two release latches ( & on the sides of the memory socket in Figure 6 - 5 the direction indicated by the arrows in Figure 6 - RAM Module Release Contact Warning Be careful not to touch the metal pins on the module’s connecting...
Page 98 Upgrading The Computer Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the socket as it will go. DO NOT FORCE the module; it should fit without much pressure.
Page 99: Upgrading The Optical (Cd/Dvd) Device(S)
Upgrading The Computer Upgrading the Optical (CD/DVD) Device(s) Turn the computer off, turn it over and remove the battery. Slide the latch towards the unlock symbol and hold it in place. Slide latch (while still holding latch in place) in the direction indicated by the arrow in order to push the device out of the computer.
Page 100 Upgrading The Computer 6 - 10...
Page 101: Modules
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 102: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe Wireless Device WLAN module or 802.11 b/g USB WLAN module in your purchase option, make Operation Aboard sure that the Wireless LAN module is on before installing the driver. Use the Fn + Aircraft F11 key combination (see Table 1 - 4, on page 1 -...
Page 103: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
Page 104 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 3 Connecting Move the cursor over the taskbar icon...
Page 105 Modules To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network you...
Page 106: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 107: Pc Camera Module
Modules PC Camera Module If you have included the PC Camera module in your purchase option, you will have Latest PC Camera the appropriate software provided on the Device Drivers & Utilities + User’s Man- Driver Information ual CD-ROM . Check the PC Camera Before installing the driver, make sure the PC Camera is on.
Page 108: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. PC Camera & TV Tuner Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 109 Modules Figure 7 - 7 Audio Setup for PC Camera Right-click PC Camera Module 7 - 9...
Page 110: Bisoncap
Modules BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu (it is recommended that you set the capture file before the capture file size for the capture file process - see Set Capture File below).
Page 111: Eliminating Screen Flicker
Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 112: Bluetooth Module
Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft Make sure that the Bluetooth module is on.
Page 113 Modules User Guides & Help View BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Cor- poration BlueSoleil - Main Window control panel. Click the Help menu select Contents and Index. Look through Getting Started or select the ap- propriate User Guide from...
Page 114: Mini-Pci Tv Tuner Module
Modules Mini-PCI TV Tuner Module If your purchase includes the analog Mini-PCI TV Tuner module (for Windows Vis- CATV Cable Safety ta Home Premium or Ultimate Editions) you will be able to watch TV, play music CDs, video conference and capture still images and video on your PC. Make sure that your CATV system installer The YUAN PVR MPC622 TV Tuner module comes with a remote control unit, and...
Page 115: Yuan Pvr Mini-Pci Mpc622 Tv Tuner Module
Modules YUAN PVR Mini-PCI MPC622 TV Tuner Module If your purchase includes the YUAN PVR MPC622 TV Tuner, then you will need to install the driver as per the instructions below. TV Tuner Module Support Installing the MPC622-64 Driver Note that the TV Tuner 1.
Page 116: Setting Up Sata Raid
Modules Setting Up SATA RAID If your purchase includes the RAID (Redundant Array of Independent Disks) option, the following pages provide an introduction to configuring your hard disk(s) in RAID mode. You may use your hard disks in combination with Striping (RAID 0) or Mirroring (RAID 1) for either fault tolerance or performance.
Page 117 Modules SATA RAID Setup Procedure Start-up your notebook computer and press <F2> to enter the BIOS. Go to the Advanced menu, select "Advanced Chipset Control" and press Enter. Array Types Select "SATA RAID Function:" and press Enter, then select "Enabled" and press Enter.
Page 118 Modules Select 1.Create RAID Volume and press Enter. 10. Type the RAID volume name and then press Tab or Enter to advance to the next field. 11. Specify (use the up and down arrow keys) the RAID level (RAID 0 or RAID 1 - see Table 7 - 1, on page 7 - 16 and sidebar) and then press Tab or Enter to advance to the next field.
Page 119: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 120: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 121: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 122: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 123: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 124 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 125: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 126 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 127 Troubleshooting Problem Possible Cause - Solution Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. The sound cannot be The volume might be set too low.
Page 128 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark. keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 129: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 130: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) TV Antenna Jack...
Page 131: Headphone-Out Jack
Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Infrared (FIR) The FIR (far infrared) transceiver at the front of the computer allows the computer to Transceiver communicate with similarly equipped devices (see “Configuring the Infrared Settings for FIR”...
Page 132: Rj-11 Phone Jack
Interface (Ports & Jacks) Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 133: Usb 2.0/1.1 Ports
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which comes with the device).
Page 134 Interface (Ports & Jacks) A - 6...
Page 135: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Video Card Options NVIDIA Video Driver Installation Note that card types, specifications and driv- Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - ers are subject to contin-...
Page 136: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 18) control panel. To access the Ge- Click Advanced Settings (button). Force control Click GeForce Go 7950GTX (tab).
Page 137 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 138 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 139: Display Devices
NVIDIA Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel display or TV as your display device. The following are the display options: The built-in LCD. An external monitor connected to the DVI-Out Port (may require DVI to VGA converter).
Page 140: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Configuring an External Display in Windows Vista Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 141 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Function Key Attach your external monitor to the DVI-Out Port (or TV to the 7-pin S-Video-Out Combination jack), and turn it on.
Page 142: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content. Dualview Mode Dualview Mode treats both connected displays as separate devices, and they act as a virtual desktop resulting in a large workspace.
Page 143 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 144 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external monitor to the DVI-Out Port (or TV to the 7-pin S-Video-Out jack), and turn it on. Display Settings Click Start, and click Control Panel (or point to Settings and click Control Extended Desktop Panel).
Page 145: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays S-Video cable from the TV to the 7-pin S-Video-Out jack at the rear of the computer. To get a full range of dis- You will need to enable the TV display from the NVIDIA Control Panel as per the play options click...
Page 146: Changing The Tv Signal Format
NVIDIA Video Driver Controls Changing the TV Signal Format When the TV is selected as a display device, click the home icon to return to the category menu. Click Video and Television, and then click “Change the signal or HD format” Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 147: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 148: Processor Types
Specifications Feature Specification Processor Types Intel® Core™ Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache & 667MHz FSB T2300/ T2400/ T2500/ T2600/ T2700 1.66/ 1.83/ 2.0/ 2.16/ 2.33 GHz Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 4MB On-die L2 Cache &...
Page 149: Video Card Options
Specifications Feature Specification Video Card For Windows XP For Windows XP and Vista Options ATI Mobility Radeon X1600 (M56) NVIDIA Quadro FX 2500M (G71GLM-U) PCI-Express Video Card PCI-Express Video Card 128MB GDDRIII (GDDR3) Video RAM On Board 512MB GDDRIII (GDDR3) Video RAM On Board PCI Express * 16 256 bit Memory Interface Supports DirectX®...
Page 150: Storage Options
Specifications Feature Specification Storage Options One 2.5" 9.5mm (h) Serial-ATA (SATA) Hard Disk Drive One Changeable Device Bay For One of the Following Options: For 12.7 mm (h) Optical CD/DVD Device Drive Options (see“Optional” on page C - For Secondary 2.5" 9.5mm (h) Hard Disk Drive (RAID Option in SATA Configuration) RAID 0, RAID 1, HDD Fault Tolerance System in SATA Configuration For 2nd Battery Card Reader...
Page 151: I/O Ports
Specifications Feature Specification ExpressCard Slot ExpressCard/34/54 Slot I/O Ports Four USB 2.0 Ports One RJ-11 Modem Jack One Mini-IEEE1394 Port One RJ-45 Giga LAN Jack One Serial Port One DC-In Jack One DVI-Out Port One 7-Pin S-Video-Out Jack for TV & HDTV One Headphone/Speaker-Out Jack Output One Microphone-In Jack...
Page 152: Operating Systems Supported
Specifications Feature Specification Operating Windows XP SP2 Windows Vista 64bit Systems Home Premium/ Business/ Enterprise/ Ultimate Supported Power Supports ACPI 2.0 Supports Suspend to Disk (S3) Management Soft Off by System Power Button Supports Suspend to RAM (S4) Supports Resume from Alarm Supports Resume from Modem Ring Supports Wake on LAN Power...
Page 153: Optional
Specifications Feature Specification Optional Optical Drive Module Options: 1.3M Pixel USB 2.0 PC Camera Module (Factory Option) DVD/CD-RW Combo Drive Module DVD-Dual Drive Module 2nd SATA RAID Hard Disk Drive DVD-Super Multi Drive Module TV Tuner Module Options: Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module (Factory Option) For Windows XP (All Factory Options): Analog TV Tuner Module with Mini-PCI Interface...
Page 154 Specifications C - 8 Specifications...
Page 155: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 156: D - 2 Dvd Regional Codes
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 157: Windows Xp Start Menu & Control Panel
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 158: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.
Page 159: Video Features
Windows XP Information Video Features This computer features different PCI Express video cards, depending on the model purchased (see “Video Card Options” on page C - 3). You can switch display devices, and configure display options, from the Display Prop- erties control panel in Windows as long as the appropriate video driver is installed.
Page 160: Display Properties
Windows XP Information Display Properties Video Card Options Note that card types, specifications and driv- ers are subject to contin- updates changes. Check with your service center for ATI Display Properties the latest details on vid- eo cards supported. The items listed in the Additional Properties window allow you to configure...
Page 161: Display Devices & Options
Windows XP Information Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the DVI-Out port, a TV to the S- Video-Out jack.
Page 162: Display Modes
Windows XP Information Display Modes Single Display Mode Only one of your displays is used. Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple displays with the same content. Dualview Mode Dualview Mode treats both connected displays as separate devices, and they act as a virtual desktop resulting in a large workspace.
Page 163: Attaching Other Displays (For Nvidia Vga
Windows XP Information Attaching Other Displays (for NVIDIA VGA) If you prefer to use a monitor or flat panel display, connect it to the port at the rear of the computer. DVI-Out Attach your external monitor to the DVI-Out Port (or TV to the 7-pin S-Video-Out jack), and turn it on. Go to the Additional Properties in the GeForce Go/Quadro FX Properties control panel tab.
Page 164 Windows XP Information Select the display option from the Primary Display/ Secondary Display dropbox. If you have a TV and external monitor/flat panel display attached you will have a number of available options. Select and Apply the appropriate option. nView Display Mode Options The display options list- ed under the Primary/...
Page 165: To Enable Extended Desktop (For Nvidia Vga
Windows XP Information To Enable Extended Desktop (for NVIDIA VGA) Attach your external monitor to the external monitor port and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).
Page 166: Attaching Other Displays (For Ati Vga
Windows XP Information Attaching Other Displays (for ATI VGA) If you prefer to use a monitor or flat panel display, connect it to the DVI-Out Port at the rear of the computer. Attach your external monitor to the DVI-Out port (or TV to the 7-pin S-Video-Out port), and turn it on. Select Displays Manager from the Graphics Settings Tree View pane.
Page 167: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 168: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 169: Stand By
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 170: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g.
Page 171: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 20). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 172: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 173: Proper Handling Of The Battery Pack
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 174: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 175: Driver Installation
Windows XP Information Driver Installation WinXP SP2 Driver Page # The Device Drivers & Utilities + User’s Manual CD- Chipset Page - 24 ROM contains the drivers and utilities necessary for Video (ATI) Page - 24 the proper operation of the computer. Table D - 3 lists what you need to install, and it is very important that...
Page 176: D - 22 What To Install
Windows XP Information What to Install 1. Check the driver installation order from Table D - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu This section covers driver and utility installation instruc- below.
Page 177: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Driv- If you wish to update/reinstall individual drivers it may Windows XP Service Pack 2 be necessary to uninstall the original driver.To do this go to the Control Panel in the Windows OS and double- Make sure you install Windows XP Service Pack 2 (or a Windows XP version which includes Service Pack 2) be- click the Add/Remove Programs item.
Page 178: Chipset
Windows XP Information Chipset Video (for NVIDIA) 1. Click 1.Install Chipset Driver > Yes. 1. Click 2.Install Video Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to D:\Drivers\00Chipset\setup.bat and click D:\Drivers\01Vga\nvg7071\setup.exe and click OK.
Page 179: Modem
Windows XP Information Modem 1. Click 4.Install Modem Driver > Yes. 1. Click 5.Install LAN Driver > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse..) to (Browse..) to (one of the following): D:\Drivers\03Modem\Setup.exe and click OK.
Page 180: Touchpad
Windows XP Information TouchPad Card Reader/ExpressCard 1. Click 6.Install Touchpad Driver > Yes. 1. Click 7.Express Card Interface > Yes. Click Start (menu) > Run... and navigate Click Start (menu) > Run... and navigate (Browse...) to (Browse...) to D:\Drivers\05Touchpad\Synaptics\SETUP.EXE D:\Drivers\06PCMCIA\setup.exe and click D:\Drivers\05Touchpad\Elantech\Setup.exe 2.
Page 181: Automail Checker
Windows XP Information AutoMail Checker Module Drivers 1. Click Optional > Yes from the Drivers Installer See the following pages for the driver installation proce- dures for any of the optional modules included in your Menu. purchase configuration. 2. Click 4.AutoMail > Yes. Wireless LAN &...
Page 182: Pc Camera Driver Installation
Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Latest PC Camera Driver Information Manual CD-ROM into the CD/DVD drive Check the PC Camera CD, and any accompanying insert pag- (click Cancel if you see a “New Hardware es, for the latest updated information on the PC Camera driver, which may override the information provided here.
Page 183: Intel Wlan Driver Installation
Windows XP Information Intel WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Optional > Yes, and then click 2.Wire- less Lan >...
Page 184: 802.11 B/G Wlan Driver Installation
Windows XP Information 802.11 b/g WLAN Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Optional > Yes, and then click 2.Wire- less Lan >...
Page 185: Bluetooth Driver Installation
Windows XP Information Bluetooth Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Optional > Yes, and then click 3.Blue- tooth > Yes. 3.
Page 186: D - 32 Mini-Pci Tv Tuner Module
Windows XP Information Mini-PCI TV Tuner Module Installing the LifeView FlyDVB-T Driver 1. Insert the driver CD-ROM into the CD/DVD You may have one of three optional Mini-PCI TV drive. Tuner modules supplied with your computer, depend- 2. Double-click LifeView DTV and Driver. ing on your purchase configuration.
Page 187: Installing The Mpc622-Mce Driver
Windows XP Information Installing the MPC622-MCE Driver 5. Choose the language you prefer for Cyberlink PowerCinema, and then click OK. 1. Insert the driver CD-ROM into the CD/DVD 6. Click Next > Yes. drive. 7. Type in the Cyberlink PowerCinema CD Key 2.
Page 188: D - 34 Setting Up Sata Raid
Windows XP Information Setting Up SATA RAID If your purchase includes the RAID (Redundant Array Array Types of Independent Disks) option, the following pages pro- vide an introduction to configuring your hard disk(s) A Mirrored Array (RAID 1) provides full data protection, as data can simply be copied from a healthy disk to a re- in RAID mode.
Page 189 Windows XP Information SATA RAID Setup Procedure 12. Press Esc and go to the Boot menu. 13. Set the external CD/DVD-ROM Drive (make sure Go to the operable computer running Windows XP the Microsoft Windows OS CD is inserted) as the and insert a prepared formatted blank 3.5"...
Page 190 Windows XP Information 19. Specify the RAID level (RAID 0 or RAID 1 - see 31. Use the arrow keys to scroll down and select Table D - 4, on page D - 34) and then press Tab or Intel(R) 82801GHM SATA RAID Controller Enter to advance to the next field.

EUROCOM Notebook User Manual

Quick Start Guide

Storage Devices, Mouse, Audio & Printer

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Power Management

Windows XP Information

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM Notebook

Summary of Contents for EUROCOM Notebook
