Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Eup-Standby And Off Mode Power Consumption Statement
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
Page 6: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 7: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 8: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 9: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 10 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 11: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 12: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 13: General Battery Precautions
Preface General Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 14: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 15: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 16 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 17 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 18: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 19: Table Of Contents
Preface Contents Notice ................................I EuP-Standby and Off Mode Power Consumption Statement: ..............II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ...............................IX Polymer Battery Precautions ........................X General Battery Precautions ........................XI Cleaning ..............................
Page 20 Preface System Map: LCD Panel Open - Model A ....................1-7 System Map: LCD Panel Open - Model B ....................1-8 LED Indicators ............................1-9 Hot Key Buttons & Keyboard .........................1-11 Keyboard ..............................1-12 Function Keys & Visual Indicators ......................1-13 Control Center ............................1-14 System Map: Front & Left Views ......................1-15 System Map: Right &...
Page 21 Preface DVD Regional Codes ..........................2-5 Multi-in-1 Card Reader ..........................2-6 Audio Features ............................2-7 TouchPad and Buttons/Mouse ........................2-9 One-Finger ...............................2-13 Multi-Finger .............................2-15 Additional ..............................2-18 Power Management Overview ..............................3-1 The Power Sources ............................3-2 AC/DC Adapter ............................3-2 Battery ................................3-2 Turning On the Computer ..........................3-3 Power Plans ...............................3-4 Power-Saving States ..........................3-6 Sleep ................................3-6...
Page 22 Preface Battery Information ..........................3-11 Conserving Battery Power ........................3-12 Battery Life ..............................3-13 New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Drivers & Utilities What to Install ............................4-1 Module Driver Installation ........................4-1 Driver Installation ............................4-2 Manual Driver Installation .........................4-4 Updating/Reinstalling Individual Drivers ....................4-4...
Page 23 Preface Card Reader ...............................4-7 TouchPad ..............................4-7 Hot Key ..............................4-7 USB 3.0 ..............................4-7 MEI Driver ..............................4-7 Audio .................................4-7 Windows Experience Index ........................4-8 Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Power-On Self Test (POST) .......................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3 The Setup Utility ............................5-4 Entering Setup ............................5-4...
Page 24 Preface MB Series / BIOS Revision / KBC/EC Firmware Revision (Main Menu) ..........5-7 Advanced Menu ............................5-8 Advanced Chipset Control (Advanced Menu) ..................5-8 Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) ..........5-9 Intel(R) Rapid Start Technology (Advanced Menu) .................5-9 Intel Anti-Theft Technology (Advanced Menu ) ..................5-9 SATA Mode (Advanced Menu) ......................5-10 Boot Logo (Advanced Menu) ........................5-10 Power On Boot Beep (Advanced Menu) ....................5-10...
Page 25 Preface When Not to Upgrade ..........................6-2 Removing the Battery ..........................6-4 Removing the Component Bay Cover .......................6-5 Removing the Component Bay Cover .......................6-6 Replacing the Component Bay Cover .......................6-8 Upgrading the Hard Disk Drive(s) ......................6-9 Upgrading the Optical (CD/DVD) Device ....................6-14 Removing the Optical Device for Model A Computers ................6-15 Removing the Optical Device for Model B Computers ................6-16 Upgrading the System Memory (RAM) ....................6-17...
Page 26 Preface Windows Mobility Center ........................7-30 Intel® Wireless Display Application .......................7-31 Intel® WiDi Application Installation ......................7-32 Intel® Wireless Music Driver Installation ....................7-32 Intel® WiDi Application Configuration ....................7-33 Fingerprint Reader Module ........................7-36 Fingerprint Reader Driver Installation .....................7-37 AuthenTec TrueSuite Application ......................7-38 Bluetooth Module ............................7-48 3rd Party Bluetooth Combo Driver Installation Information ..............7-49 3rd Party Bluetooth Combo Driver Version 1 Installation ..............7-50 3rd Party Bluetooth &...
Page 27 Preface Text Messaging Service (SMS) .......................7-77 SMS Utility ..............................7-77 Sending a Text Message ..........................7-79 Phonebook ...............................7-82 SMS Settings ............................7-85 THX TruStudio Pro Audio ........................7-88 THX TruStudio AP Installation .......................7-88 THX TruStudio Pro Activation .......................7-89 THX TruStudio Pro Application ......................7-89 Intel® Rapid Storage Technology Driver ....................7-93 Troubleshooting Overview ..............................8-1 Basic Hints and Tips ..........................8-2...
Page 28 Preface Ports and Jacks ............................A-2 Card Reader ..............................A-2 DC-In Jack ..............................A-2 DVI-Out Port ............................A-2 e-SATA / USB 3.0 Combo Port .......................A-2 HDMI-Out Port ............................A-3 Headphone-Out Jack ..........................A-3 Microphone-In Jack ..........................A-3 RJ-45 LAN Jack ............................A-3 S/PDIF-Out Jack ............................A-3 Security Lock Slot ............................A-3 USB 2.0/1.1 Ports .............................A-4 USB 3.0 Port .............................A-4 Control Center...
Page 29 Preface Display Devices & Options ........................C-7 Attaching Other Displays .........................C-8 Configuring an External Display in Windows 7 ..................C-11 NVIDIA Control Panel ...........................C-14 Optimus™ Customization Options ......................C-16 Set PhysX® Configuration ........................C-20 Video Settings ............................C-21 HDMI Audio Configuration ........................C-22 Specifications Processor ..............................D-2 Processor ..............................D-2 Processor ..............................D-2 Processor ..............................D-3...
Page 30 Preface Keyboard & Pointing Device ........................D-4 Interface ..............................D-4 Slots ................................D-5 Card Reader ..............................D-5 Communication ............................D-5 Communication ............................D-5 Communication ............................D-5 Security ..............................D-5 Features ..............................D-5 Power Management ..........................D-6 Power ................................D-6 Environmental Spec ..........................D-6 Physical Dimensions & Weight ........................D-6 XXVIII...
Page 31: Quick Start Guide Overview
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 32: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 33: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 34: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system.
Page 35: Model Differences
Quick Start Guide Model Differences This notebook series includes two different model types that mainly differ as indicated in the table below. Note that your model may appear slightly different from those pictured in this manual. Feature Model A Model B 15.6”...
Page 36: System Startup
Quick Start Guide System Startup Remove all packing materials and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 37: System Map: Lcd Panel Open - Model A
Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 2 LCD Panel Open - Model A  Built-In PC Camera Wireless Device (Optional) Operation Aboard Aircraft Power Button GPU Button The use of any portable elec- LED Indicators tronic transmission devices Hot Key Buttons...
Page 38: System Map: Lcd Panel Open - Model B
Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open Model B  Built-In PC Camera Wireless Device (Optional) Operation Aboard Aircraft Power Button GPU Button The use of any portable elec- LED Indicators tronic transmission devices Hot Key Buttons...
Page 39: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Number Lock is Activated Orange AC/DC Power is Plugged In Green Caps Lock is Activated Green The Computer is On Green...
Page 40 Quick Start Guide Icon Color Description Green UMA Mode Activated Orange Optimus Mode Activated Green Intel Integrated GPU (iGPU) Activated Orange NVIDIA Discrete GPU (dGPU) Activated The (optional) WLAN Module is Green Powered On The (optional) Bluetooth Module is Orange Powered On White Hard Disk Activity...
Page 41: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard  Press the hot key buttons on the computer to toggle the appropriate function on/off. Other Keyboards Icon Color Description If your keyboard is dam- aged or you just want to Green UMA Mode Activated make a change, you can use any standard USB...
Page 42: Keyboard
Quick Start Guide Keyboard The keyboard has an embedded numerical keypad for easy numeric data input, and features function keys to al- low you to change operational features instantly. See Table 1 - 5, on page 1 - 13 for full function key combina- tion details.
Page 43: Function Keys & Visual Indicators
Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Visual in- dicators (see the table below) are available when the Hot Key driver is installed. Keys Function/Visual Indicators Keys...
Page 44: Control Center
Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off.
Page 45: System Map: Front & Left Views
Quick Start Guide System Map: Front & Left Views Figure 1 - 5 Front & Left Views 1. LED Indicators 2. DC-In Jack 3. Vent/Fan Intake 4. External Monitor Port 5. RJ-45 LAN Jack 6. 2 * USB 3.0 Ports 7.
Page 46 Quick Start Guide  Multi-In-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo The card reader features a push-in/push-out card insertion and ejection mechanism.
Page 47: System Map: Right & Rear Views
Quick Start Guide System Map: Right & Rear Views Figure 1 - 6 Right & Rear Views Headphone-Out Jack Microphone-In Jack S/PDIF-Out Jack USB 2.0 Port Optical Device Drive Bay Security Lock Slot  Battery CD/DVD Emergency Eject If you need to manually eject a CD/DVD (e.g. due to an unexpected power interruption) you may push the end of a straightened paper clip into the emergency eject hole.
Page 48: System Map: Bottom View - Model A
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 7 Bottom View  Model A Battery Information Battery Component Bay Always completely dis- Cover charge, then fully charge, Vent/Fan Intake a new battery before us- Speakers ing it.
Page 49: System Map: Bottom View - Model B
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 8 Bottom View  Model B Battery Information Battery Component Bay Always completely dis- Cover charge, then fully Fan Intake charge, a new battery Speakers before using it. Com- pletely discharge and charge the battery at least once every 30 days...
Page 50 Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 51: Video Features
Quick Start Guide Video Features ® NVIDIA Optimus Technology ™ NVIDIA Optimus technology is a seamless technology designed to get best performance from the graphics ® ™ system while allowing longer battery life, without having to manually change settings. When the computer is in Optimus Mode it will automatically switch between the integrated UMA (Unified Memory Architecture) GPU (iGPU) and the discrete GPU (dGPU) when required by the applications in use.
Page 52 Quick Start Guide To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category. Click Adjust Screen Resolution/Adjust resolution. Alternatively you can right-click the desktop and select Screen resolution. Use the dropbox to select the screen Resolution (Figure 1 - 10).
Page 53 Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 10 on page 1 - 22) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 11) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
Page 54 Quick Start Guide To access the NVIDIA Control Panel: Right-click the desktop and select NVIDIA Control Panel (Figure 1 - 12). Double-click the icon (Figure 1 - 12) in the Windows control panel. Figure 1 - 12 - NVIDIA Control Panel 1 - 24 Video Features...
Page 55: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 19) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 56: Mofa Lcd Back Covers - Model A
Quick Start Guide MOFA LCD Back Covers - Model A MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the spe- cially designed changeable LCD back covers. If your purchase option includes the specially designed change- able LCD back cover option (some Model A Computers Only), then follow the instructions in “Changing the Optional LCD Back Covers”...
Page 57: Storage Devices, Audio & Mouse Overview
Storage Devices, Audio & Mouse Chapter 2: Storage Devices, Audio & Mouse Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • Multi-in-1 Card Reader •...
Page 58: Hard Disk Drive
Storage Devices, Audio & Mouse Hard Disk Drive  The hard disk drive(s) is(are) used to store your data in the computer. The hard Power Safety disk(s) can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 59: Optical Device
Storage Devices, Audio & Mouse Optical Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page D - 4). The Adjustment optical device is usually labeled “Drive D:”...
Page 60: Handling Cds Or Dvds
Storage Devices, Audio & Mouse Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 61: Dvd Regional Codes
Storage Devices, Audio & Mouse DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.
Page 62: Multi-In-1 Card Reader
Storage Devices, Audio & Mouse Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 63: Audio Features
Storage Devices, Audio & Mouse Audio Features  You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Adjustment Deck control panel The sound volume level is set using the volume The volume may also be adjusted by means of the Fn + F5/F6 key combination.
Page 64 Storage Devices, Audio & Mouse Expert Mode will allow you to access more advanced configuration menus for  Speaker, Microphone and Stereo Mix. Syncing Left & Right Volume Balance If you wish to adjust the left and right channel volume levels separately, you will need to adjust this from the VIA HD Audio Deck in Ex-...
Page 65: Touchpad And Buttons/Mouse
Storage Devices, Audio & Mouse TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 66 Storage Devices, Audio & Mouse Elan TouchPad  Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you TouchPad Scrolling can configure the functions by double-clicking the TouchPad driver icon in the notification area of the taskbar (or from Options in the ELAN tab in the Mouse This computer model se- control panel in Windows).
Page 67 Storage Devices, Audio & Mouse The Elan Smart-Pad control panel allows you to use a specific gesture (action) on the surface of the TouchPad to perform specific actions to manipulate documents, objects and applications. Click the menu tabs (One-finger, Multi-finger or Additional) and then the function button on the left to access the Configuration controls in the right panel.
Page 68 Storage Devices, Audio & Mouse Click the Function Description button to get a detailed description of any func- tion. Click the Default button to set any of the functions to the default setting. Figure 2 - 9 Smart-Pad Control Panel with Function Description 2 - 12 TouchPad and Buttons/Mouse...
Page 69: One-Finger
Storage Devices, Audio & Mouse One-Finger Tapping The Smart-Pad supports one, two and three finger tapping, all configured from the Tapping control panel in the One-finger tab. You can configure two or three finger tapping to perform a number of different functions by selecting them from the drop- down menus provided.
Page 70 Storage Devices, Audio & Mouse Drag and Drop You can select the different drag and drop methods from the menu provided. The ob- ject can be released when you lift the finger off the TouchPad, when you tap again or after a set time delay. Figure 2 - 12 Drag and Drop 2 - 14 TouchPad and Buttons/Mouse...
Page 71: Multi-Finger
Storage Devices, Audio & Mouse Multi-Finger Zooming Place two fingers on the TouchPad (for best results use the tips of the fingers) and slide them apart to zoom in, or closer together to zoom out. Figure 2 - 13 Zooming Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically.
Page 72 Storage Devices, Audio & Mouse Rotation You can rotate objects by using a two-finger gesture. Touch and rotate using two fin- gers on the pad in the direction required. Alternatively place a finger down on the pad and rotate the other finger around it in a circular motion (clockwise or counter- clockwise).
Page 73 Storage Devices, Audio & Mouse Fast Keys The Fast Keys gesture allows you to switch windows or open My Computer. Figure 2 - 17 Fast Keys My Computer (Fast Keys) Tap three fingers simultaneously on the pad and then move them up until you get to the My Computer window, you can then release the fingers from the pad.
Page 74: Additional
Storage Devices, Audio & Mouse Additional Palm Tracking This feature helps guard against accidental contact such as palms resting on the pad. Use the slider to adjust the sensitivity of the feature as appropriate. Figure 2 - 18 Palm Tracking Sensitivity Adjust the sensitivity, using the slider, to determine the level of pressure reuired to be exerted by the finger for a response from the pointer/cursor .
Page 75: Power Management Overview
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 76: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-In jack on the left of the computer.
Page 77: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 78: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 79 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 80: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 81: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 82: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 83: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status Icon Color To Resume...
Page 84: Power Conservation Modes
Power Management Power Conservation Modes  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
Page 85: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 86: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 87: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 88: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...
Page 89: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 90 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 91 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 92 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 93: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities  Driver Installation & This chapter deals with installing the drivers and utilities essential to the operation or Power improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Page 94: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 95 Drivers & Utilities Windows 7 SP1 Driver Page Windows 7 SP1 Driver Page Chipset Page 4 - 6 PC Camera Module Page 7 - 2 Video (VGA) Page 4 - 6 Wireless LAN Module Page 7 - 10 NVIDIA Video (VGA) Page 4 - 6 Intel®...
Page 96: Manual Driver Installation
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click the Browse CD/DVD button in the Drivers In- If you wish to update/reinstall individual drivers it staller application and browse to the executable file in may be necessary to uninstall the original driver.To do the appropriate driver folder.
Page 97: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue/Al- ing the installation procedure (other than when out- low, and follow the installation procedure as directed.
Page 98: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Video (VGA) Insert the Device Drivers & Utilities + User’s Manual 1. Click 2.Install VGA Driver > Yes. disc and click Install Drivers (button), or Option Driv- 2. Click Next > Yes > Next > Next. ers (button) to access the Optional driver menu.
Page 99: Card Reader
Drivers & Utilities Card Reader MEI Driver 1. Click 5.Install Cardreader Driver > Yes. 1. Click 9.Install MEI Driver > Yes. 2. Click Finish. 2. Click Next > Yes > Next. 3. Click Finish. TouchPad Audio 1. Click 6.Install Touchpad Driver > Yes. 2.
Page 100: Windows Experience Index
Drivers & Utilities Windows Experience Index It is recommended that you install the THX Tru Stu- dio Pro Audio application (see “THX TruStudio AP After Video (VGA) driver has been installed, and the Installation” on page 7 - 88) and Intel Rapid Storage system restarted, the OS will automatically run the Technology driver (see “Intel®...
Page 101: Optional Drivers
Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules in- cluded in your purchase option. Models A & B Figure 4 - 3 - Optional Drivers Installer Screen Note that for Intel and some 3rd party WLAN &...
Page 102 Drivers & Utilities 4 - 10...
Page 103: Bios Utilities Overview
BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 104: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) If you enable the Boot-time Diagnostic Screen in the Setup Utility, each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong.
Page 105: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 106: The Setup Utility
BIOS Utilities The Setup Utility  The Aptio Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 (give the system a few seconds malfunction.
Page 107: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
Page 108: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 109: Sata Port # (Main Menu)
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
Page 110: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting . 5 - 8 Advanced Menu...
Page 111: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is started up or restarted. Enabling the power setting will have the module retain the last power status (on or off) before any restart or shut down.
Page 112: Sata Mode (Advanced Menu)
BIOS Utilities SATA Mode (Advanced Menu)  You can configure SATA (Serial ATA) control to operate in IDE (native/compati- ble) or AHCI (Advanced Host Controller Interface) modes from this menu. The SATA Mode SATA Mode should be set BEFORE installing an operating system, and after you Selection have backed up all necessary files and data (see sidebar).
Page 113: Security Menu
BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
Page 114: Password On Boot: (Security Menu)
BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then  press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning Note: You can only set the user password after you have set the supervisor pass- If you set a boot pass- word.
Page 115: Boot Menu
BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
Page 116: Fast Boot (Boot Menu)
BIOS Utilities Fast Boot (Boot Menu) Eanble this item to boot with the initialization with the minimum set of devices re- quired for an active boot. Skip VGA/USB/PS2 (Boot Menu) If these items are enabled then BIOS will skip loading the EFI VGA driver/USB or5 PS2 devices.
Page 117: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 118 BIOS Utilities 5 - 16...
Page 119: Upgrading The Computer Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 120: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 121 Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may damage the processor or mainboard.
Page 122: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ Please check with your DC adapter from the computer first. service representative Turn the computer off, remove the AC/DC adapter and turn it over.
Page 123: Removing The Component Bay Cover
Upgrading The Computer Removing the Component Bay Cover To upgrade any components you need to remove the component bay cover first. The procedure for removing the component bay cover will depend upon your particular computer model: Removing the Component Bay Cover 6 - 5...
Page 124: Removing The Component Bay Cover
Upgrading The Computer Removing the Component Bay Cover Turn off the computer, and turn it over and remove the battery. Locate the component bay cover and remove screws & Slide the cover in the direction of arrow , by appling pressure at points until the case markers line up.
Page 125 Upgrading The Computer Remove the component bay cover Model A Model B Figure 6 - 3 Component Bay Cover Removal  Heat Sink Warning When the cover is removed try to avoid contact (particurlarly when re- moving the secondary HDD) with the heat sink area Removing the Component Bay Cover 6 - 7...
Page 126: Replacing The Component Bay Cover
Upgrading The Computer Replacing the Component Bay Cover Reinsert the component bay cover by placing it on the bottom case assembly and sliding it on to the case in the direction of arrow by applying pressure at points Make sure the case markers line up.
Page 127: Upgrading The Hard Disk Drive(S)
Upgrading The Computer Upgrading the Hard Disk Drive(s)  The hard disk Drive(s) can be taken out to accommodate up to two other 2.5" serial HDD System Warning (SATA) hard disk drives with a height of 9.5mm (h) (see “Storage” on page D - Follow your operating system’s installation instructions, and install all necessary New HDD’s are blank.
Page 128 Upgrading The Computer Removing the Hard Disk from the Primary HDD Bay Note that only Model B is pictured, however the procedure for removing the primary hard disk from Model A is the same. Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 &...
Page 129 Upgrading The Computer Remove screws & and the insulation plate Reverse the process to install a new disk and do not forget to reinstall the insulation plate and tuck the protective rubber carefully into the case to secure a tight fit. Replace the component bay cover (see page Figure 6 - 6 Primary Hard Disk...
Page 130 Upgrading The Computer Removing the Hard Disk from the Secondary HDD Bay Note that only Model B is pictured, however the procedure for removing the primary hard disk from Model A is the same. Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 &...
Page 131 Upgrading The Computer Remove screws & and the case bracket Figure 6 - 8 Secondary Hard Disk Case Bracket Removal  Heat Sink Warning When replacing the HDD assembly try to avoid contact with the heat sink area Reverse the process to install a new disk (pay careful attention to the orientation of the hard disk in the case bracket before tightening the screws).
Page 132: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device The procedure for removing the optical device will depend upon your particular computer model: • See “Removing the Optical Device for Model A Computers” on page 6 - • See “Removing the Optical Device for Model B Computers” on page 6 - 6 - 14 Upgrading the Optical (CD/DVD) Device...
Page 133: Removing The Optical Device For Model A Computers
Upgrading The Computer Removing the Optical Device for Model A Computers Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & Figure 6 - 9 Remove the screw at point , and use a screwdriver to carefully push out the Removing the optical device at point...
Page 134: Removing The Optical Device For Model B Computers
Upgrading The Computer Removing the Optical Device for Model B Computers Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & Figure 6 - 10 Remove the primary HDD assembly (see page 10).
Page 135: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR III (DDR3) type memory modules (see “Memory” on page D - The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 136 Upgrading The Computer Turn off the computer, and turn it over and remove the battery and component bay cover (see pages 6 - 4 & The memory sockets will be visible at point on the mainboard. Figure 6 - 11 RAM Module Location ...
Page 137 Upgrading The Computer The RAM module will pop-up, and you can remove it.  Figure 6 - 13 Single Memory Module RAM Module Installation Removal If your computer has a single memory module, then insert the module into the Channel 0 (JDIMM1) socket. In this ...
Page 138 Upgrading The Computer 6 - 20...
Page 139: Modules Overview
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 140: Pc Camera Module
Modules PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Latest PC Camera combination, or Control Center button, to toggle power to the to the PC Camera mod- Driver Information ule.
Page 141: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install Webcam Driver > Yes. 4. Click Finish to restart the computer. Click Next >...
Page 142: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 143 Modules Figure 7 - 1 Audio Setup for PC Camera Right-click PC Camera Module 7 - 5...
Page 144 Modules Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below). Go to the Capture menu heading (if you wish to capture audio check “PC Camera Audio Setup”...
Page 145 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 146 Modules Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 147 Modules Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 148: Wireless Lan Module
Modules Wireless LAN Module  If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth Wireless Device combo) module in your purchase option, make sure that the WLAN module is on be- Operation Aboard fore installing the driver. Aircraft The use of any portable Use the Fn + F11 key combination, or Control Center button, to toggle power to the...
Page 149: 3Rd Party 802.11B/G/N Driver Installation
Modules There are two different drivers provided for 3rd party WLAN & Bluetooth combo  modules The appropriate driver for your system will be installed from the Option Drivers menu in the Device Drivers & Utilities + User’s Manual disc. WLAN &...
Page 150: Intel® Wi-Fi Link Series Driver Installation
Modules Intel® Wi-Fi Link Series Driver Installation  If you see the message “Found New Hardware” click Cancel to close the window. Intel(R) PROSet/ 1. Make sure the module is powered on, then insert the Device Drivers & Util- Wireless ities + User’s Manual disc into the CD/DVD drive.
Page 151: Connecting To A Wireless Network In Windows 7
Modules Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Click the notification area wireless icon , and then double-click an access point Network and to connect to or click to Open Network and Sharing Center if you do not see a Sharing Center network you want to connect to in the notification area menu (a list of options will You can also use the Net-...
Page 152 Modules You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 153 Modules Click the notification area icon to see any currently connected networks.  To disconnect from the wireless network you can click the notification area wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Page 154 Modules Intel My WiFi Configuration ®  Intel® My WiFi Technology uses your WLAN (for Intel WLAN modules only) module to allow you to connect up to eight other WiFi enabled devices (e.g. digital Intel® My WiFi Help cameras, other computers, cell phones, handheld devices etc.) to your computer To get help on Intel®...
Page 155: Intel® My Wifi Configuration
Modules Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the notification area icon Click Enable (on the first run of the program there will be no connected...
Page 156 Modules Click Start and click Control Panel. Click Network and Sharing Center (Network and Internet). Click Change adapter settings. Figure 7 - 7 Network and Sharing Center Click Change adapter settings 7 - 18 Wireless LAN Module...
Page 157 Modules Right-click Wireless Network Connection and select Properties. Figure 7 - 8 Network Connections Right-click Wireless Network Connection and select Proper- ties. Wireless LAN Module 7 - 19...
Page 158 Modules Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Connection under Home networking connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Figure 7 - 9 Connection.
Page 159 Modules 10. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the notification area icon 11. Click Profiles Figure 7 - 10 Intel®...
Page 160 Modules 12. Click Profiles, click Intel Wireless PAN and click Edit or New (Note that all preset settings may not be editable - see sidebar). Figure 7 - 11 Profiles  Profile Settings Profiles that are preset may not be fully edit- 13.
Page 161 Modules 14. Click Security (tab). 15. Change the Security Type to WEP and the Encryption Type to 64bit. 16. Enter a password (8 characters long) in the Password box. Figure 7 - 13 Intel® My WiFi Profile Settings - Security Wireless LAN Module 7 - 23...
Page 162 Modules 17. Click Sharing (tab). 18. It is recommended that the Filter Network Traffic and DHCP and DNS Server are Disabled. Figure 7 - 14 Intel® My WiFi Profile Settings - Sharing 7 - 24 Wireless LAN Module...
Page 163 Modules 19. Click Advanced (tab). 20. It is recommended that the Default Channel is set to Channel 1, 6 or 11. 21. Click OK to save the settings. Figure 7 - 15 Intel® My WiFi Profile Settings - Advanced Wireless LAN Module 7 - 25...
Page 164 Modules 22. Double-click Wireless Network Connection in Network Connections. 23. Click Details to display the Network Connection Details. Figure 7 - 16 Wireless Network Connection Details 7 - 26 Wireless LAN Module...
Page 165 Modules 24. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the notification area icon 25. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 166: Intel Wlan & Bluetooth Combo Module High-Speed Data Transfer Configuration
Modules Intel WLAN & Bluetooth Combo Module High-Speed Data Transfer Configuration You will need to configure the following settings to enable high-speed wireless data transfer as supported by Intel Wireless LAN & Bluetooth Combo modules (note this information applies to Intel WLAN & Bluetooth Combo modules only). Go the Windows control panel and double-click Device Manager (in Hardware and Sound under Devices and Printers).
Page 167 Modules Click Network adapters to expand the sub-menu. Double-click the Intel WiFi Link ..module. Click Advanced (tab). Click 802.11n Channel Width for band 2.4 under “Property:”. Click the pull-down menu under “Value:” Click to select Auto. Click OK and close the control panels. Figure 7 - 19 Intel WiFi Link Properties...
Page 168: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 169: Intel® Wireless Display Application
Modules Intel Wireless Display Application ®  The Intel ® Wireless Display Application (requires Intel® Centrino WLAN/ Compatible Combo module), in conjunction with a compatible video adapter (purchased sep- Adapters arately), allows you to display the contents of the notebook display on another dis- play (e.g.
Page 170: Intel® Widi Application Installation
Modules Intel WiDi Application Installation ® 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install WiDi AP > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.
Page 171: Intel® Widi Application Configuration
Modules Intel WiDi Application Configuration ® Click Start > All Programs > Intel Corporation > Intel(R) Wireless Display > Intel(R) Wireless Display, or double click the icon on the desktop. Click I agree to the terms of this license (button). The application will scan for any connected compatible adapters (or you can click the Scan for available adapters button to enable Intel My WiFi Technology).
Page 172 Modules Click to select any detected adapters, and click Connect. The system will then prompt you to enter the 4-digit security code which will be displayed on the external TV Screen (or press the connect button on the wireless speaker adapter). Enter the code for the video adapter and click Continue.
Page 173 Modules You will then be prompted to enter a name for the video adapter and click  Continue. Click Finished to complete the setup. Test Audio Adapter To verify a successful audio connection (for In- tel® Wireless Music), select the “Test your audio connection”...
Page 174: Fingerprint Reader Module
Modules Fingerprint Reader Module  (For Model A Computers Only) Password Warning The fingerprint reader Protector Suite Software provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and If you set passwords for have a Windows password enabled for full security protection.
Page 175: Fingerprint Reader Driver Installation
Modules Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 4.Install Finger Print Driver > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.
Page 176: Authentec Truesuite Application
Modules AuthenTec TrueSuite Application  The AuthenTec TrueSuite application is used in conjunction with your fingerprint reader to enroll fingerprints and manage settings etc. Fingerprint Enrollment User Enrollment Note that it is strongly rec- Click Start > All Programs > AuthenTec TrueSuite. ommended that you enroll Click Yes when you have identified your fingerprint sensor ( Fingerprint...
Page 177 Modules You will be prompted to select another finger for enrollment (it is recommended  that you enroll a number of fingers - see sidebar). Click the button to continue once you have enrolled a number of fingerprints. Help Enter the required information and click the button to register your software, or click to register later.
Page 178 Modules Settings Click the Settings button on the menu bar to access the personalization settings for AuthenTec TrueSuite. Here you can choose to enable/disable Website Log On, QuickLaunch, Fast User Switching and the desktop icon. You can also select the Theme and export/import identities.
Page 179 Modules Windows Log On Windows log on allows you to gain access to your computer by swiping your finger across the fingerprint reader sensor. Use the Biometric Devices control panel (in the Hardware & Sound category) in Windows to turn Biometrics on/off when re- quired.
Page 180 Modules Website Log On Use a fingerprint swipe to log on to websites to help you avoid having to remember user names and passwords across multiple websites (browsers supported are Internet Explorer, Firefox and Chrome). Registering a Website Use your web browser to navigate to the website required. Enter your user name and password and sign in to the website.
Page 181 Modules QuickLaunch QuickLaunch allows you to drag and drop icons (which represent websites, folders, applications and/or computer actions) to any enrolled finger and then swipe your fin- ger to launch the icons assigned to that finger. Click Start > All Programs > AuthenTec TrueSuite. Click Select Category (button) to group icons if required.
Page 182 Modules Adding a Website to QuickLaunch Click Start > All Programs > AuthenTec TrueSuite. Click the Add Website button on the menu bar and the dialog box will be displayed. Enter the website URL, name, icon and category as required. Click Save and an icon will be associated with the selected website.
Page 183 Modules Dock View Dock View displays the website icons across the bottom of the screen. Each icon wiLl have an associated web card which displays the website information, user name and password etc. This information may be edited or deleted as required. Figure 7 - 32 Dock View Editing a Web Card...
Page 184 Modules Exporting and Importing Your Identity You can export your identity to backup your information, or to move it to another computer. Exporting Your Identity Click Start > All Programs > AuthenTec TrueSuite. Click the Settings button on the menu bar. Click Export My Identity.
Page 185 Modules AuthenTec KeepSafe The KeepSafe folder is an encrypted area assigned on your hard drive that allows you to store files and folders to be protected by fingerprint protection. The folder will appear on your desktop (if selected in the Personalization Settings) and in My Computer, but will not be visible to other users of your computer.
Page 186: Bluetooth Module
Modules Bluetooth Module  If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf. Operation Aboard Use the Fn + F12 key combination (see Table 1 - 5, on page 1 - 13) or Control Aircraft...
Page 187: 3Rd Party Bluetooth Combo Driver Installation Information
Modules 3rd Party Bluetooth Combo Driver Installation Information  There are two different drivers provided for 3rd party WLAN & Bluetooth combo modules for this computer. Bluetooth In Device Manager (For Driver Version 2 • Driver Version 1 (for WLAN & Bluetooth Combo V3.0) requires the Blue- Bluetooth V4.0) tooth driver to be installed separately (see overleaf).
Page 188: 3Rd Party Bluetooth Combo Driver Version 1 Installation
Modules 3rd Party Bluetooth Combo Driver Version 1 Installation  Note this driver is required for the 3rd Party combo Bluetooth and WLAN module version 1 (Bluetooth V3.0) only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 189: 3Rd Party Bluetooth & Wlan Combo Settings
Modules 3rd Party Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module driver ver- sion 1 (Bluetooth V3.0) only. For driver version 2 (Bluetooth V4.0) see “Intel Bluetooth Module & Bluetooth Combo Driver Installation” on page 7 - Resuming From Sleep Mode Make sure the Bluetooth module is powered on.
Page 190 Modules Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 35 General Settings 7 - 52 Bluetooth Module...
Page 191 Modules Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 36 File Transfer Settings Bluetooth Module 7 - 53...
Page 192: 3Rd Party Bluetooth Networking Setup
Modules 3rd Party Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module driver ver- sion 1 (Bluetooth V3.0) only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu).
Page 193: 3Rd Party Bluetooth & Wlan Combo Module Configuration
Modules 3rd Party Bluetooth & WLAN Combo Module Configuration  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
Page 194 Modules You will then be presented with a menu of options to select from. Figure 7 - 39 Bluetooth Device Options Click the appropriate button to connect to the device. 7 - 56 Bluetooth Module...
Page 195 Modules You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection. Figure 7 - 40 Bluetooth Pairing Code &...
Page 196: Intel Bluetooth Combo Driver Installation
Modules Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Page 197: Standard Bluetooth Configuration In Windows 7
Modules Standard Bluetooth Configuration in Windows 7  For Intel and 3rd Party Driver Version 2 (Bluetooth V4.0) modules only. Setup your Bluetooth Device so the Computer Can Find it Add a Device Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Click Start, and click Con- Make the device discoverable (to do this check your device documentation).
Page 198 Modules To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con- nections.
Page 199 Modules Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 43 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 200 Modules To Change Settings for the Bluetooth Device  Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 201: 3.75G/Hspa Module
Modules 3.75G/HSPA Module  If you have included an optional (for Model A Only) 3.75G/HSPA (High Speed 3.75G Module Power Packet Access) module (see “Communication” on page D - 5 for specification de- tails) in your purchase option, you will have the appropriate application provided for Note that when the com- puter resumes from a your module (Wireless Manager).
Page 202 Modules 3.75G/HSPA Module USIM Card Installation  Follow the instructions below to install the USIM card (which will be provided by your service provider). Power Safety Warning Turn off the computer, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.
Page 203 Modules Before installing the application, make sure that the 3.75G/HSPA module is ON  (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 4, on 3.75G/HSPA page 1 - 12) or Control Center button to toggle power to the 3.75G/HSPA mod-...
Page 204: Wireless Manager
Modules Wireless Manager  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Wireless Manager application. The Wireless Wireless Device Operation Aboard Manager application allows you to directly access your HSPA internet service from Aircraft the computer.
Page 205: Wireless Manager Application
Modules Wireless Manager Application  The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a PIN Number Profile” on page 7 - 73).
Page 206 Modules The system will connect to your network.  Connected will appear above the timer icon (the timer will indicate your connected time for the current session) Wireless Manager You can then access the internet, download e-mail etc. as per any internet Help connection.
Page 207 Modules Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status Figure 7 - 49 Notification Area Icons (Connected)  Notification Area The indicator will display the signal strength and radio access Icon technology.
Page 208: Profiles
Modules Profiles Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 50 Advanced Settings - Profiles 7 - 70 3.75G/HSPA Module...
Page 209 Modules Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 51 Multiple Profiles Found Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator pro- file database for a profile that matches the details on your USIM card.
Page 210 Modules Selecting a Profile Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 52 Profile - Manual Selection (Filter) 7 - 72 3.75G/HSPA Module...
Page 211 Modules Creating a Profile  Click Manual selection (button). Click the New. Deleting a Profile Enter a name you prefer for the profile. Enter the Access Point Name (APN). To delete a profile click Enter the User Name and Password if required (some service providers may not to select Manual selec- require this information and the fields may then be left blank).
Page 212: Settings
Modules Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Win- dows Startup. Figure 7 - 54 Settings The Advanced settings allows more detailed configuration. To access the Ad- vanced settings: Access the Wireless Manager program from the Start menu (Start >...
Page 213 Modules  Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can PIN Notes also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes).
Page 214 Modules Networks  The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select Warning a network. Note that some applica- tions automatically Connection transmit data when con- You can set the Wireless Manager to automatically connect at Windows startup...
Page 215: Text Messaging Service (Sms)
Modules Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 216 Modules Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash Figure 7 - 58 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in as- cending or descending order by name or date.
Page 217: Sending A Text Message
Modules Sending a Text Message Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click SMS and the SMS Utility will then start. Click the New Message tab. Enter the phone number in the To field (multiple numbers may be entered separated by a semicolon (;), or click the phonebook icon to select a name from...
Page 218 Modules Click Send to send the message or Save to save the message in the Drafts folder. Clicking the Clear icon clears both the Message and To fields. If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox.
Page 219 Modules Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 61 Click to close the message Close Message •...
Page 220: Phonebook
Modules Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 221 Modules Contacts  • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other Import/Export fields are available) for the contact. Click the icon to expand the number Contacts details.
Page 222 Modules Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group.
Page 223: Sms Settings
Modules SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 65 SMS Utility Settings  SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks).
Page 224 Modules Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages writ- ten when the radio is off, will then be sent automatically the next time radio is turned on.
Page 225 Modules Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card.
Page 226: Thx Trustudio Pro Audio
Modules THX TruStudio Pro Audio  Install the THX TruStudio AP to allow you to configure the audio settings to your THX TruStudio & requirements for the best performance in games, music and movies. Speaker Configuration THX TruStudio AP Installation Note that THX TruStu- 1.
Page 227: Thx Trustudio Pro Activation
Modules THX TruStudio Pro Activation  On the first run of THX TruStudio Pro you will need to activate the application. THX Audio & HDMI To activate the application you will need to be connected to the internet. Double-click the THX Activate icon on the desktop and click the Activate Note that the THX audio effects do not apply to...
Page 228 Modules THX Control Panel Each control has an On/Off button to allow you to enable/disable the control, and most controls feature a slider to adjust the levels (the subwoofer may be turned on/ off). Figure 7 - 69 Menu THX TruStudio Pro Controls •...
Page 229 Modules THX TruStudio Pro Headphone Settings THX TruStudio selects the built-in speakers by default and this setting may cause some sound quality issues when using headphones. To adjust the settings for head- phones do the following: Run the THX TruStudio Pro application. Select Settings from the menu.
Page 230 Modules THX TruStudio Pro & HDMI When you connect an HDMI display to the HDMI-Out port, the THX Tru Studio Pro controls will be disabled. A warning box will pop-up and will prompt “Do you want to select another audio device now?”.
Page 231: Intel® Rapid Storage Technology Driver
Modules Intel Rapid Storage Technology Driver ® Install the Intel® Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 10) . 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Page 232 Modules 7 - 94...
Page 233: Troubleshooting Overview
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 234: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 235: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 236: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 237: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 238 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 239: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 240 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 241 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 242 Troubleshooting Problem Possible Cause - Solution The TouchPad doesn’t The Touchpad has been disabled. Press the Touchpad toggle (Fn + F1) key combination (make work. sure you have installed the Touchpad driver. I am sliding my finger up There are different TouchPad versions available on this computer, and this version requires and down on the right tapping/holding to scroll.
Page 243 Troubleshooting Problem Possible Cause - Solution When a DVD is played in This is an issue with Windows Media Player/Media Center and audio output through the S/PDIF- Windows Media Player/ Out Jack. We recommend that you use the Power DVD application to play DVDs. Media Center, the audio track in other languages (commentaries etc.) is...
Page 244 Troubleshooting Problem Possible Cause - Solution No sound can be heard You have not configured the HDMI audio output. See “HDMI Audio Configuration” on page C - through HDMI connected display. Audio Volume is too You have set the Speaker Configuration to 5.1 or 7.1 Speaker. It is recommended that you set the when listening Speaker Configuration to Stereo (not to 5.1 or 7.1 Speaker) when listening through...
Page 245 Troubleshooting Problem Possible Cause - Solution The Bluetooth module experiencing problems/ 2 Bluetooth adapters appear in the Device Manager under Bluetooth Radios. There is a conflict between an existing Bluetooth module and a Bluetooth & WLAN combination module. You should have only one Bluetooth module installed in order to prevent any conflicts (this includes the Bluetooth element of any combination WLAN &...
Page 246 Troubleshooting Problem Possible Cause - Solution cannot obtain high To obtain high speed Bluetooth data transfer take into account the following: speed Bluetooth data transfer. • Only the combination Wireless LAN & Bluetooth module supports high speed (data transfer. • To achieve high speed transfer speeds, both devices must support high speed data transfer (i.e both the computer and the Bluetooth compatible device you are connecting to).
Page 247: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 248 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 249 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 250 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 18 Bluetooth Connection Problems...
Page 251: Intel® Wlan & Bluetooth Hs Combo Modules
Troubleshooting Intel® WLAN & Bluetooth HS Combo Modules Note that, at the time of going to press, Intel® Centrino® Wireless-N 2230 and Intel® Centrino Advanced 6235 WLAN & Bluetooth combo modules use the standard Bluetooth configuration in Windows 7 (see “Intel Bluetooth Combo Driver Installation”...
Page 252 Troubleshooting 8 - 20...
Page 253: Interface (Ports & Jacks) Overview
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 254: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) / RSMMC SD (Secure Digital) / Mini SD / SDHC / SDXC MS (Memory Stick) / MS Pro / MS Duo Push the card into the slot and it will appear as a removable device.
Page 255: Hdmi-Out Port
Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) port is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external HDMI monitor, TV or Flat Panel Display etc. as a display device (see “Attaching Other Displays”...
Page 256: Usb 2.0/1.1 Ports
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be USB 3.0 Port plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power...
Page 257: Control Center Overview
Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
Page 258 Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
Page 259 Control Center User Modes Power Saving Flight Entertainment Quiet Performance Defined Icon Power Plan Power Saver Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN Bluetooth BIOS Default PC Camera (Model A Only) TouchPad...
Page 260 Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
Page 261 Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - 6). Click in a blank area of the icon or press a key on the keyboard to exit Power Conservation Mode without making any changes Display Switch Click the Display Switch button to access the menu (or use the...
Page 262 Control Center B - 6...
Page 263: Video Driver Controls
Video Driver Controls Appendix C: Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - Video Driver Installation Video Card Options Note that card types, Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - specifications and driv- Insert the Device Drivers &...
Page 264: Nvidia Optimus ™ Technology
Video Driver Controls NVIDIA Optimus Technology ® ™  Most notebook computers come with either a discrete or integrated graphics solu- iGPU or dGPU tion. Note the NVIDIA control Discrete graphics solutions feature a dedicated Graphics Processing Unit (GPU) panel refers to High- performance NVIDIA which are capable of playing games, watching HD video or running GPU-based ap-...
Page 265 Video Driver Controls How Optimus Technology works  When the system is powered up and is displaying just the desktop, the dGPU will be powered off. In this case the system is running in the same way as a system without Customization a discrete graphics solution.
Page 266 Video Driver Controls GPU Button This computer also features a button that allows the user to switch between Op- timus Mode and UMA Mode (Unified Memory Architecture). UMA Mode will use only the integrated GPU; Optimus Mode will allow the system to automatically de- termine whether the dGPU or iGPU is used.
Page 267: Intel® Graphics & Media Control Panel
Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
Page 268 Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Page 269: Display Devices & Options
Video Driver Controls Display Devices & Options  Note that you can use an external display connected to the HDMI-Out port or exter- nal monitor port. See your display device manual to see which formats are support- Function Key Combination You can use the Fn + F7 ...
Page 270: Attaching Other Displays
Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 271 Video Driver Controls To Enable Extended Desktop:  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 272 Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.
Page 273: Configuring An External Display In Windows 7
Video Driver Controls Configuring an External Display in Windows 7  You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your display to the external monitor port or HDMI-Out port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see page 22).
Page 274 Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 275 Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 276: Nvidia Control Panel
Video Driver Controls NVIDIA Control Panel  More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Click Start, and click Control Panel (or point to Settings and click Control Panel). To access the Ge- Double-click NVIDIA Control Panel (click "Classic View"...
Page 277 Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and  tools which allow quick access to features such as image settings, 3D Settings and video configuration. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 278: Optimus™ Customization Options
Video Driver Controls Optimus Customization Options ™  One of the most important aspects of Nvidia Optimus technology is that it will ® ™ Display GPU switch between the integrated GPU and discrete GPU seamlessly and automatically, Activity Icon and does not require any input from the user. However customization options are of- fered for users who prefer to set their own parameters for GPU usage.
Page 279 Video Driver Controls Close the NVIDIA Control Panel.  Find the executable file icon of the application you want to run. Right-click the icon and select Run with graphics processor from the context iGPU or dGPU menu. Select either High-performance NVIDIA processor (dGPU) or Integrated Note the NVIDIA con- graphics (iGPU) to run the program with the selected GPU.
Page 280 Video Driver Controls Global Settings Global settings allows you to set the preferred graphics processor for overall use. Ideally this would be the iGPU for battery life, but this can be set to the dGPU if pre- ferred. Run the NVIDIA Control Panel (see page 14).
Page 281 Video Driver Controls Program Settings Program settings allows you to make specific adjustments for installed applications. Run the NVIDIA Control Panel (see page 14). Click Manage 3D Settings (3D Settings) and select Program Settings (tab). Select a program to customize from the drop-down menu, or click Add to add any program that does not appear in the menu.
Page 282: Set Physx Configuration
Video Driver Controls Set PhysX Configuration ® NVIDIA PhysX is a physics engine that can use the GPU to accelerate game and ® ® 3D application performance. You can select the GeForce video card or CPU as a PhysX processor, or configure the computer to auto-select a PhysX processor ®...
Page 283: Video Settings
Video Driver Controls Video Settings Click the sub-menus under Video to adjust the video color or image settings. Figure C - 16 Video Settings Video Settings C - 21...
Page 284: Hdmi Audio Configuration
Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Indicator In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click the taskbar volume indicator when an...
Page 285 Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure C - 18 HDMI Device Properties HDMI Audio Configuration C - 23...
Page 286 Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Page 287: Specifications
Specifications Appendix D:Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 288: Processor
Specifications Processor Processor Processor Intel® Core i7-3820QM (2.7GHz) Intel® Core i5-3320M (2.6GHz) Intel® Core i7-2760QM (2.4GHz) Quad-Core Mobile Processor Mobile Processor Quad-Core Mobile Processor 8M L3 Cache, 22nm (22 Nanometer), 3M L3 Cache, 22nm (22 Nanometer), 6M L3 Cache, 32nm (32 Nanometer), DDR3-1600MHz, TDP 45W DDR3-1600MHz, TDP 35W DDR3-1600MHz, TDP 45W...
Page 289: Processor
Specifications Processor Processor Core Logic Intel® Core i7-2640M (2.8GHz) Intel® Core i5-2430M (2.4GHz) Mobile Intel® HM76 Express Chipset Mobile Processor Mobile Processor Memory 4M L3 Cache, 32nm (32 Nanometer), 3M L3 Cache, 32nm (32 Nanometer), DDR3-1333MHz, TDP 35W DDR3-1333MHz, TDP 35W Dual Channel DDRIII (DDR3) Intel®...
Page 290: Video Adapter Options
Specifications Video Adapter Options Storage Keyboard & Pointing Device Intel® Integrated GPU and NVIDIA® One 12.7 mm Super Multi/Blu-Ray Full Size Winkey Keyboard with Numeric GeForce Video: Combo/Blu-Ray Writer SATA Optical Keypad Device Drive (Factory Option) Supports NVIDIA® Optimus Built-In TouchPad (with Multi Gesture Switchable GPU Technology between Functionality) Two Changeable 2.5"...
Page 291: Card Reader
Specifications Slots Communication Communication Two Mini-Card Slots: Intel® Centrino Advanced-N 6235 2*2 UMTS/HSPDA-based 3.75G Module with (802.11 a/g/n) Half Mini-Card PCIe WLAN + USB Half Mini-Card Interface (Factory Slot 1 for WLAN or WLAN & Bluetooth Bluetooth V4.0+HS Combo Module (Facto- Option for Model A Computers) Combo Half Mini-Card Module with PCIe ry Option)
Page 292: Power Management
Specifications Power Management Physical Dimensions & Weight Supports Wake on LAN Model A (Design Style I): 374mm (w) * 250mm (d) * 16.3 - 39.4mm (h) Supports Wake on USB 2.7kg with ODD and Battery Power Model A (Design Style II): Full Range AC/DC Adapter –...

EUROCOM Notebook User Manual

Quick Start Guide Overview

Storage Devices, Audio & Mouse Overview

Power Management Overview

Drivers & Utilities

BIOS Utilities Overview

Upgrading the Computer Overview

Modules Overview

Troubleshooting Overview

Interface (Ports & Jacks) Overview

Control Center Overview

Video Driver Controls

Specifications

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EUROCOM Notebook

Summary of Contents for EUROCOM Notebook
