Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 5: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 6: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 7: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Page 10: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 11: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 12: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 13 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 14 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 15: Lcd Screen Care
Preface Lighting Proper lighting and a comfortable viewing angle can reduce eye strain and shoulder and neck muscle fatigue. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 16 Preface...
Page 17: Table Of Contents
Preface Contents Notice .................I System Map: Front & Rear Views .......1-10 FCC Statement .............II System Map: Right View ..........1-11 FCC RF Radiation Exposure Statement: ....III System Map: Left View ..........1-12 Instructions for Care and Operation ......V System Map: Bottom View ..........1-13 Power Safety .............VII Windows Vista Start Menu &...
Page 18 Preface USB Printer ...............2-11 Drivers & Utilities Install Instructions: ...........2-11 What to Install ..............4-1 Parallel Printer ............2-11 Module Driver Installation ..........4-1 Driver Installation ............4-2 Power Management Updating/Reinstalling Individual Drivers ....4-4 Overview ................3-1 User Account Control (Win Vista) ......4-4 The Power Sources ............3-2 Windows Security Message .........4-4 AC/DC Adapter ............3-2 New Hardware Found ..........4-4...
Page 19 Preface BIOS Utilities Fixed disk boot sector: (Security Menu) ......5-12 Boot Menu ..............5-13 Overview ................5-1 Exit Menu ..............5-14 The Power-On Self Test (POST) ........5-2 Failing the POST ............5-3 Upgrading The Computer Fatal Errors ..............5-3 Overview ................6-1 Non-Fatal Errors ............5-3 When Not to Upgrade ..........6-2 The Setup Utility ............5-4 Removing the Battery ............6-3 Entering Setup .............5-4...
Page 20 Preface Fingerprint Reader Driver Installation .....7-20 DVI-Out Port ..............A-2 User Enrollment ............7-21 e-SATA/USB Port ............A-3 USB TV Tuner Module ..........7-24 HDMI-Out Port .............A-3 Consumer Infrared Remote Control Unit Driver ..7-25 Headphone-Out Jack .............A-3 TV Tuner Driver Installation ........7-25 Infrared (FIR) Transceiver ..........A-3 Digital TV Broadcast Signal ........7-27 Line-In Jack ..............A-4 TV Recording and Power Plans .......7-27...
Page 21 Preface Specifications Windows XP Information Processor Types ............C-2 DVD Regional Codes ...........D-2 Core Logic ..............C-2 Windows XP Start Menu & Control Panel ....D-3 LCD ................C-2 Audio Features ..............D-4 Security ................. C-3 Function/Hot Key Indicators ........D-5 Memory ................. C-3 Video Features ..............D-6 Video Adapter Options ..........
Page 22 Preface Battery FAQ..............D-23 Intel WLAN Driver Installation ........D-42 Driver Installation ............D-24 Fingerprint Reader Module .........D-44 Manual Driver Installation........... D-25 User Enrollment ............D-45 Updating/Reinstalling Individual Drivers ....D-26 USB TV Tuner Module ..........D-47 Driver Installation Procedure........D-27 Consumer Infrared Remote Control Unit Driver ..D-48 Found New Hardware Wizard ........
Page 23: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 24: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “Drivers & Utilities” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 25: Model Differences
Quick Start Guide Model Differences This notebook series includes two different design types, however only one design is pictured in this manual. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the appropriate drivers.
Page 26: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported: Operating System &...
Page 27: System Startup
Quick Start Guide System Startup 1. Remove all packing materials, and place the computer on a stable surface. Shutdown 2. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Note that you should 3.
Page 28: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open 1. Optional Built-In PC Wireless Device Camera Operation Aboard 2. LCD Aircraft 3. Hot Key Buttons 4. Power Button The use of any portable elec- tronic transmission devices 5.
Page 29: Led Indicators
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Icon Color Description Green The Computer is On Orange The Battery is Charging Blinking Blinking The Battery has Reached Critically Low The Computer is In Sleep Mode Green Orange...
Page 30: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard The keyboard has a numerical keypad for easy numer- ic data input, and features Function Keys to allow you These buttons give instant access to the default Inter- to change operational features instantly. net browser and e-mail program, and to Silent Mode* Activate the Number Lock feature by pressing the with one quick button press.
Page 31: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is installed (see “Hot Key”...
Page 32: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front View 1. LCD Latches 2 3 4 5 2. Line-In Jack 3. Headphone-Out Jack 4. Microphone-In Jack 5. S/PDIF-Out Jack 6. LED Indicators 7. Infrared Transceiver &...
Page 33: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 5 Right View 1. Express Card Slot 2. 7-in-1 Card Reader 3. 2 * USB 2.0 Ports 4. Mini-IEEE 1394 Port 5. RJ-11 Phone Jack 6. RJ-45 LAN Jack 7. CATV Antenna Jack Mini-IEEE 1394 Port (Enabled With TV The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices.
Page 34: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 6 Left View 1. Speaker 2. Security Lock Slot 3. Optional Device Drive Bay (for CD/DVD Device, see page Changing DVD Regional Codes CD/DVD Emergency Eject If you need to manually eject a CD/DVD Go to the Control Panel and double-click (e.g.
Page 35: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 Bottom View 1. Vent/Fan Intake/Out- 2. Battery 3. Battery Release Latch 4. Optical Device Release Latches 5. Component Bay Cover 6. Infrared & Consumer Infrared Transceiver 7. Sub Woofer Battery Information Always completely discharge, then fully charge, a new battery before using it.
Page 36: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 37: Video Features
Quick Start Guide Video Features You can configure display options, from the Display Settings control panel in Windows as long as the appro- priate video driver is installed. For more detailed video information see “NVIDIA Video Driver Controls” on page B - To access Display Settings in Windows: 1.
Page 38: Display Devices & Options
Quick Start Guide Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV (connected to the DVI-Out port/HDMI-Out port) as your display device. Figure 1 - 9 - Display Settings & NVIDIA Control Panel NVIDIA Display Mode Description Single...
Page 39: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 40 Quick Start Guide 1 - 18...
Page 41: Storage Devices, Mouse, Audio & Printer
Storage Devices, Mouse, Audio & Printer Chapter 2: Storage Devices, Mouse, Audio & Printer Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical Device • 7-in-1 Card Reader •...
Page 42: Hard Disk Drive
Storage Devices, Mouse, Audio & Printer Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 43: Optical Device
Storage Devices, Mouse, Audio & Printer Optical Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the model you purchased (see “Storage” on page C - 4). The Adjustment optical device is usually labeled “Drive D:”...
Page 44: Handling Cds Or Dvds
Storage Devices, Mouse, Audio & Printer Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed.
Page 45: Dvd Regional Codes
Storage Devices, Mouse, Audio & Printer DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 46: 7-In-1 Card Reader
Storage Devices, Mouse, Audio & Printer 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 47: Expresscard Slot
Storage Devices, Mouse, Audio & Printer ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g.
Page 48: Touchpad And Buttons/Mouse
Storage Devices, Mouse, Audio & Printer TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse.
Page 49: Audio Features
Storage Devices, Mouse, Audio & Printer Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up the audio menu).
Page 50: Setup For Audio Recording
Storage Devices, Mouse, Audio & Printer Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
Page 51: Adding A Printer
Storage Devices, Mouse, Audio & Printer Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options.
Page 52 Storage Devices, Mouse, Audio & Printer 2 - 12...
Page 53: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 54: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Silent Mode AC/DC Adapter Use the key to tog- gle Silent Mode to re- Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ duce fan noise and save DC adapter will damage the computer and its components (see page power...
Page 55: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 56: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 57 Power Management Each Windows Power Plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 58: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where Power Button you left off. Sleep is the default power-saving state in Windows Vista. The Power Button Earlier versions of Windows used Stand By and Hibernate as system power-saving in the Start Menu (in Classic View use the states.
Page 59: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Hibernate Mode In power failure occurs the system can restore your work from the hard disk; if a power Windows Vista SP1 failure occurs when work is saved only to memory, then the work will be lost.
Page 60: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Protection It is recommended that you enable a password on wake up in order to protect your data.
Page 61: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color send the computer to...
Page 62: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power When the battery is criti- Your computer’s battery power is dependent upon many factors, including the pro- cally low, immediately grams you are running, and peripheral devices attached.
Page 63: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 64: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 65: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 66: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 67 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 68 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 69: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 70: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Page 71 Drivers & Utilities Manual Driver Installation Driver - Windows Vista with Service Click Browse CD (button) in the Drivers Installer ap- Page Pack 1 plication and browse to the executable file in the ap- propriate driver folder. Chipset Page 4 - 5 Video Page 4 - 5 Windows Update...
Page 72: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control (Win Vista) If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 73: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Audio Drivers Note that two drivers are provided on the disc for the Audio sys- Insert the Device Drivers & Utilities + User’s Manual tem. disc and click Install Drivers (button), or Option Driv- ers (button) to access the Optional driver menu.
Page 74: Modem
Drivers & Utilities Modem Card Reader/ExpressCard 1. Click 4.Install Modem Driver > Yes. 1. Click 6.Install Cardreader Driver > Yes. 2. Click Next > Install. 2. Click OK. 3. Click Finish. 3. The modem is now ready for configuration. TouchPad 1.
Page 75: Optional Drivers
Drivers & Utilities Optional Drivers See the pages indicated for the driver installation pro- cedures for any modules included in your purchase op- Windows Update tion. After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- Bluetooth Module dates etc.
Page 76: Fingerprint Reader Module
Drivers & Utilities Fingerprint Reader Module See the install procedure in “Fingerprint Reader Driver Installation” on page 7 - TV Tuner Module See the install procedure in “USB TV Tuner Module” on page 7 - 4 - 8 Driver Installation...
Page 77: Overview
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 78: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 79: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 80: The Setup Utility
BIOS Utilities The Setup Utility The Phoenix Setup utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen in Figure 5 - 1 on page 5 - 2 is usually present for a...
Page 81: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 82: Main Menu
BIOS Utilities Main Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help BIOS Version: ************* System Time: [22:12:05] <Tab>, <Shift Tab>, or System Date: [04/28/2008] <Enter> selects field. SATA Port 1 [FUJITSU MHY2120BH-(PM)] SATA Port 2 [Optiarc CDRWDVD CRX890S-(]...
Page 83: Sata Port 1/2/3 (Main Menu)
BIOS Utilities SATA Port 1/2/3 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a hard disk or op- tical device drive on the computer’s SATA Ports. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 84: Advanced Menu
BIOS Utilities Advanced Menu Phoenix SecureCore(tm) Setup Utility Main Advanced Advanced Security Boot Exit Item Specific Help Select the operating Installed O/S: [Vista] system installed Figure 5 - 3 SATA Mode Selection: [AHCI] on your system which Legacy USB Support: [Enabled] you will use most Advanced Menu...
Page 85: Sata Mode Selection (Advanced Menu)
BIOS Utilities SATA Mode Selection (Advanced Menu) This menu is only available if you select the Vista O/S as your operating system. You can configure SATA (Serial ATA) control to operate in either IDE (native/ compatible) or AHCI (Advanced Host Controller Interface) modes from this menu. The SATA mode should be set to AHCI mode for this system (unless you are sure your hard disk can only operate in IDE mode).
Page 86: Reset Configuration Data: (Advanced Menu)
BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 87: Security Menu
BIOS Utilities Security Menu Phoenix SecureCore(tm) Setup Utility Security Menu Security S S e e c c u u r r i i t t y y Main Advanced Boot Exit Item Specific Help changes Supervisor Password Is: Clear make here affect the User Password Is: Clear Supervisor Password...
Page 88: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer (you may only set a password on boot if a supervisor password is enabled). If “Enabled” Password Warning is selected, only users who enter a correct password can boot the system (see the If you set a boot pass- warning in the sidebar).
Page 89: Boot Menu
BIOS Utilities Boot Menu Phoenix SecureCore(tm) Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: Keys used to view or USB KEY: USB FDC: configure devices: USB CD: Optiarc CDRWDVD CRX890S-(P Up and Down arrows IDE CDROM: select a device.
Page 90: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Phoenix SecureCore(tm) Setup Utility Main Advanced Security Boot Exit Exit Menu Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help...
Page 91: Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 92: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts.You should not perform any of these upgrades if: Power Safety Warning Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 93: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, turn it over and remove the battery. service representative Slide latch...
Page 94: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive(s) can be taken out to accommodate other 2.5" serial (SATA) HDD System Warning hard disk drives with a height of 9.5mm (h) (see “Storage” on page C - 4).
Page 95 Upgrading The Computer Remove the bay cover Figure 6 - 3 Bay Cover Removal Remove screws from the hard disk cover. Slide the hard disk assembly in the direction of the arrow Figure 6 - 4 Hard Disk Assembly Removal Upgrading the Hard Disk Drive 6 - 5...
Page 96 Upgrading The Computer Carefully remove the hard disk assembly in the direction of the arrow Figure 6 - 5 HDD Removal Remove screws to separate the hard disk from the bracket. Reverse the process to install any new hard disk. Figure 6 - 6 HDD Bracket Screws...
Page 97: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDR II (DDR2) type memory modules (see “Memory” on page C - 3). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 98 Upgrading The Computer Remove the bay cover Figure 6 - 8 Bay Cover Removal Contact Warning Be careful not to touch the metal pins on the module’s connecting edge. Even the cleanest Gently pull the two release latches ( & on the sides of the memory socket in hands have oils which the direction indicated by the arrows in...
Page 99 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 10 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket.
Page 100: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn the computer off, turn it over and remove the battery. Slide the latch towards the unlock symbol and hold it in place. Slide latch (while still holding latch in place) in the direction indicated by the arrow in order to push the device out of the computer.
Page 101: Overview
Modules Chapter 7: Modules Overview This chapter contains the information on the various modules (some of which are optional) which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. The chapter includes information on the following: •...
Page 102: Bluetooth Module
Modules Bluetooth Module The optional Bluetooth module allows you to connect your computer to Bluetooth Wireless Device enabled devices such as other computers, desktop computers, mobile phones, print- Operation Aboard ers, digital cameras, PDAs, headsets etc. using a short-range radio frequency. Aircraft Use the Fn + F12 key combination (see Table 1 - 4, on page 1 -...
Page 103: Bluetooth Configuration In Windows Vista
Modules Bluetooth Configuration in Windows Vista Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon If you cannot see the To Turn the Bluetooth Module On Bluetooth icon in the...
Page 104 Modules To Add a Bluetooth Device Access the Bluetooth Devices control panel. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. Click Devices (tab), and then click Add. The Add Bluetooth Device Wizard will appear.
Page 105 Modules To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click General, type a new name and click OK). •...
Page 106: Pc Camera Module
Modules PC Camera Module The PC Camera module uses the BisonCap application to capture video files. Be- Latest PC Camera fore installing the driver, make sure the PC Camera is on. Use the Fn + F10 key Driver Information combination (see Table 1 - 4, on page 1 - 9) to toggle power to the PC Camera Check the disc, and any ac-...
Page 107: Pc Camera Driver Installation
Modules PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2.0M PC Camera 2. Click Option Drivers (button). Screen Refresh 3. Click 1.Install WebCam Driver > Yes. The 2.0M PC Camera 4.
Page 108: Pc Camera Audio Setup
Modules PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 109 Modules Figure 7 - 5 Audio Setup for PC Camera Right-click PC Camera Module 7 - 9...
Page 110 Modules BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and for capturing video files to .avi format. Pre-Allocating File Space Run the BisonCap program from the Start > Programs/All Programs > Bison- Cam menu (it is recommended that you set the capture file before the capture You may pre-allocate process - see Set Capture File below).
Page 111 Modules Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 112 Modules Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 113 Modules Zoom The BisonCap program allows you to zoom the camera in and out. Run the BisonCap/Video View program. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 7 Zoom/Setting Snapshot Folder Taking Still Pictures The Snapshot folder’s The BisonCap program allows you to take still pictures.
Page 114: Wireless Lan Module
Modules Wireless LAN Module If you have included an Intel® Wi-Fi Link 5100/5300 Series (802.11 a/g/n) WLAN Wireless Device module in your purchase option, make sure that the Wireless LAN module is on be- Operation Aboard fore installing the driver. Aircraft The use of any portable Use the Fn + F11 key combination (see...
Page 115: Connecting To A Wireless Network
Modules Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 8 Taskbar Menus Click icon...
Page 116 Modules Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network). Figure 7 - 10 Connecting Move the cursor over the taskbar icon...
Page 117 Modules To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make sure that any network...
Page 118: Windows Mobility Center
Modules Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 119: Fingerprint Reader Module
Modules Fingerprint Reader Module The optional fingerprint reader Protector Suite Software provides a high level Password Warning of security for your computer. A further level of security and control is provided in the BIOS (see “Security Menu” on page 5 - 11).
Page 120: Fingerprint Reader Driver Installation
Modules Fingerprint Reader Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. Help & Manual 2. Click Option Drivers. Right-click the taskbar icon 3. Click 3.Install FingerPrint Driver > Yes. to bring up the menu to 4.
Page 121: User Enrollment
Modules User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Page 122 Modules Click the button above any of the fingers to begin the enrollment process for that finger. 10. Swipe the finger three times to enroll that finger. Fingerprint 11. Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Next.
Page 123 Modules 15. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, Start Control Center, access the Help menu etc. You can also run the Control Center etc. from the Protector Suite QL item in the Programs/All Programs menu.
Page 124: Usb Tv Tuner Module
Modules USB TV Tuner Module A CD containing drivers, software and a user guide will be supplied if your purchase TV Antenna configuration includes the optional USB TV Tuner module. In addition a driver is provided on the Device Drivers & Utilities + User’s Manual disc for the remote The TV antenna sup- plied with any TV Tuner control supplied with the TV Tuner.
Page 125: Consumer Infrared Remote Control Unit Driver
Modules Consumer Infrared Remote Control Unit Driver 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers. 3. Click 4.Install ITE CIR Driver > Yes. 4. Click Next > Yes > Next > Finish. TV Tuner Driver Installation 1.
Page 126 Modules 14. Choose the language you prefer, and click Next. 15. Click Next > Next > Next. 16. Click “Yes, restart my computer now.” (button) and click Next. Windows Media 17. Click Finish to restart the computer. Center 18. Run the Hybrid DTV application from the Start > Programs/All Pro- Note that the Windows grams >...
Page 127: Digital Tv Broadcast Signal
Modules Digital TV Broadcast Signal The antenna is the most crucial factor in receiving a clear digital terrestrial TV broadcast signal. The passive antenna provided should provide a clear signal when CATV Cable Safety placed beside a window. If the signal is not clear then you can purchase an active Make sure that your antenna (it should also be placed beside a window) to improve the signal.
Page 128 Modules 7 - 28...
Page 129: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 130: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 131: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 132: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 133: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 134 Troubleshooting • Don’t over complicate things. The less you have to deal with then the easier the source of the problem may be found; Example - if your computer has many devices plugged into its ports, and a number of programs running, then it will be difficult to determine the cause of a problem.
Page 135: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution You turned the power on Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 136 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the vents/fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 137 Troubleshooting Problem Possible Cause - Solution Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk. The sound cannot be The volume might be set too low.
Page 138 Troubleshooting Problem Possible Cause - Solution The system freezes or The system’s power saving features have timed-out. Use the AC/DC adapter, press a key on the the screen goes dark. keyboard, or press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 139 Troubleshooting Problem Possible Cause - Solution Nothing appears on the You have selected an external display as the default display device. The PC Camera application screen when the PC software needs to be run while the default notebook LCD is the selected display device. Camera software is run.
Page 140 Troubleshooting Problem Possible Cause - Solution The Hibernate function You have a computer with 4GB of RAM and have installed Windows Vista Service Pack 1. This has disappeared. is a known issue if your computer has 4GB of RAM and is running Windows Vista Service Pack 1.
Page 141 Troubleshooting Problem Possible Cause - Solution On some occasions the This is an known issue acknowledged by NVIDIA which can arise when using NVIDIA chipsets with will appear DirectX 10.0. Check the NVIDIA website for the latest updated drivers and current information. flicker while running the 3D Mark 2006 in demo mode, or while playing...
Page 142: Screen Resolution Error
Troubleshooting Screen Resolution Error If you are experiencing either screen resolution reduction, or screen flickering after resuming from Sleep in Windows Vista only then follow the instructions below to fix this problem. This error arises in compliance with Windows Vista policy, which triggers TMM (Transient Multi-Monitor Manager) when the notebook lid (S3) is closed.
Page 143 Troubleshooting Double-click Task Scheduler Library > Microsoft > Windows. Click MobilePC to open the control panel. Right-click TMM and select Disable. Figure 8 - 2 - TMM Disable Close all the control panels. Screen Resolution Error 8 - 15...
Page 144 Troubleshooting 8 - 16...
Page 145: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the ports & jacks which allow your computer to commu- nicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 146: Ports And Jacks
Interface (Ports & Jacks) Ports and Jacks Item Description Card Reader The card reader allows you to use the following digital storage cards: MMC (MultiMedia Card) RS MMC (requires PC adapter) SD (Secure Digital) Mini SD (requires PC adapter) MS (Memory Stick) MS Duo (requires PC adapter) MS (Memory Stick Pro) CATV Antenna Jack...
Page 147: E-Sata/Usb Port
Interface (Ports & Jacks) Item Description e-SATA/USB Port This is a combined e-SATA (external Serial Advanced Technology Attachment)/ USB 2.0 compatible port. e-SATA Plug external Serial ATA hard drives into this e-SATA (external Serial Advanced Technology Attachment) port. See “USB 2.0/1.1 Ports” on page A - 5 for USB port information.
Page 148: Line-In Jack
Interface (Ports & Jacks) Item Description Line-In Jack The Line-In jack allows you to play audio sources through the computer’s speakers. Microphone-In Jack Plug an external microphone in to this jack to record on your computer. Mini-IEEE 1394 Port This allows high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below).
Page 149: S/Pdif-Out Jack
Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Port allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store.
Page 150 Interface (Ports & Jacks) A - 6...
Page 151: Nvidia Video Driver Controls
NVIDIA Video Driver Controls Appendix B: NVIDIA Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - Resolution Error NVIDIA Video Driver Installation If you are experiencing Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - screen resolution...
Page 152: Nvidia Control Panel
NVIDIA Video Driver Controls NVIDIA Control Panel More advanced video configuration options are provided in the NVIDIA Control NVIDIA Control Panel tab. Panel Open the Display Settings (see page 16) control panel. To access the Ge- Click Advanced Settings (button). Force..
Page 153 NVIDIA Video Driver Controls The NVIDIA Control Panel provides additional video configuration controls and tools which allow quick access to features such as display configuration, 3D Settings and Help menus etc. Navigating the Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 154 NVIDIA Video Driver Controls The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure B - 3 Help Menus B - 4 NVIDIA Control Panel...
Page 155: Attaching Other Displays
NVIDIA Video Driver Controls Attaching Other Displays Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI Display Devices (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to connect an external display (if you are using an older type of monitor you can use a Besides built-in converter to convert the signal from DVI to VGA).
Page 156 NVIDIA Video Driver Controls Configuring an External Display using the NVIDIA Control Panel Alternatively you can use the NVIDIA control panel to configure any attached dis- plays. Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to NVIDIA Control Panel (see “NVIDIA Control Panel”...
Page 157: Hdmi Audio Configuration
NVIDIA Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 158 NVIDIA Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • If you disconnect the HDMI cable the default audio playback device will not If you are using a third party application to play revert to speakers until the computer is restarted (if you do not wish to restart the...
Page 159: Display Modes
NVIDIA Video Driver Controls Display Modes Single Display Mode Resolution Error Only one of your displays is used. If you are experiencing screen resolution prob- Clone Mode lems/screen flickering after Clone Mode simply shows an exact copy of the Primary display desktop on the other resuming from Sleep in display(s).
Page 160 NVIDIA Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. If a New Display Detected window does not appear in Windows Vista, go to the Windows Mobility Center control panel (Mobile PC >...
Page 161 NVIDIA Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Click Start, and click Control Panel (or point to Settings and click Control Display Settings Panel).
Page 162: Enabling Tv Display
NVIDIA Video Driver Controls Enabling TV Display To display desktop images on a TV, connect the TV to your computer by using an Detect Displays HDMI cable/DVI cable from the TV to the HDMI-Out port/DVI-Out port at the rear of the computer. To get a full range of dis- play options click “My dis- You will need to enable the TV display from the NVIDIA Control Panel as per the...
Page 163: Changing The Tv Signal Format
NVIDIA Video Driver Controls Changing the TV Signal Format When the TV is enabled as a display device, click the sub-menus under Video & Television. Click “Change the signal or HD format”. Select the TV signal format (the menu allows you to select TV format by country if you are unsure of your TV format).
Page 164 NVIDIA Video Driver Controls B - 14...
Page 165: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 166: Processor Types
Specifications Feature Specification Processor Types Intel® Core™2 Duo Processor 45nm (45 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 3MB On-die L2 Cache & 1066MHz FSB, P8400 / P8600 TDP 25W 2.26GHz / 2.4GHz Intel® Core™2 Duo Processor 45nm (45 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package, Socket P 6MB On-die L2 Cache &...
Page 167: Security
Specifications Feature Specification Security Security (Kensington® Type) Lock Slot Fingerprint Reader Module (Factory Option) BIOS Password Memory Two 204 Pin SO-DIMM Sockets Supporting DDRIII (DDR3) at 800 MHz / 1066 MHz Supports Dual Channel DDRIII (DDR3) SDRAM 64-bit Wide Per Data Channel Memory Expandable up to 4GB (1024/ 2048 MB DDRIII Modules) Video Adapter NVIDIA GeForce 9800M-GTX...
Page 168: Storage
Specifications Feature Specification Storage One Changeable 12.7mm(h) SATA Optical Device (CD/DVD) Type Drive (see “Optional” on page C - for drive options) Easy Changeable 2.5" 9.5 mm (h) SATA (Serial) HDD Card Reader Embedded 7-in-1 Card Reader (MS/ MS Pro/ SD/ Mini SD/ MMC/ RS MMC/ MS Duo) Note: MS Duo/ Mini SD/ RS MMC Cards Require a PC Adapter Audio Integrated AZALIA Compliant Interface...
Page 169: I/O Ports
Specifications Feature Specification I/O Ports Four USB 2.0 Ports One Mini-IEEE1394a Port One eSATA Port (eSATA/USB Port Combined) One RJ-11 Modem Jack eSATA supported in Windows Vista only: One RJ-45 Gigabit LAN Jack AHCI mode supports hot swapping One DC-In Jack IDE mode does not support hot swapping One Infrared Transceiver One Cable (CATV) Antenna (Analog/Digital) Jack...
Page 170: Power Management
Specifications Feature Specification Power Supports ACPI 3.0 Supports Resume from Modem Ring Management Supports Wake on LAN Power Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 20V, 6A (120 Watts) Easy Changeable 8-Cell Smart Lithium-Ion 4400mAH Main Battery Environmental Temperature Relative Humidity...
Page 171: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 172: Dvd Regional Codes
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 173: Windows Xp Start Menu & Control Panel
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 174: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel. For advanced options double-click the Realtek Adjustment HD Audio Manager icon in the taskbar (or click the control panel) to bring up How high the sound vol- the Realtek Audio Configuration menus.
Page 175: Function/Hot Key Indicators
Windows XP Information Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators (see the table below) are available when the hot key utility is in- stalled (see “Hot Key”...
Page 176: Video Features
Windows XP Information Video Features You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed. To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel). Double-click Display (icon) - In the Appearances and Themes category.
Page 177: Display Properties & Nvidia Control Panel
Windows XP Information Display Properties & NVIDIA Control Panel Figure D - 4 - Display Properties & NVIDIA Control Panel Video Card Options Note that card types, specifications and drivers are subject to continual updates and changes. Check with your service center for the latest details on video cards supported.
Page 178: Nvidia Video Driver Controls
Windows XP Information NVIDIA Video Driver Controls Access the NVIDIA Control Panel as indicated on page D - 6. You may make Navigating the changes to the video and display settings by clicking the appropriate menu item. Control Panel Navigate through the control panels in much the same way as you would a web page.
Page 179 Windows XP Information The Help menus provide index and search features, and direct links to the NVIDIA website etc. Figure D - 6 Help Menus NVIDIA Video Driver Controls D - 9...
Page 180: Display Devices And Modes (Nvidia
Windows XP Information Display Devices and Modes (NVIDIA) Note that you can use a DVI cable connected to the DVI-Out port, or an HDMI (High-Definition Multimedia Interface) cable connected to the HDMI-Out port to Display Devices connect an external display (if you are using an older type of monitor you can use an You can use the Fn + F7 adapter to convert the signal from DVI to VGA).
Page 181 Windows XP Information Switching Displays When using the Fn + F7 key combination to toggle through the display options; give the displays time to refresh. The displays will toggle though in the order below (note that CRT refers to an older type of monitor connected to the DVI-Out port using an adapter): •...
Page 182: Attaching Other Displays
Windows XP Information Attaching Other Displays Attach your external display to the DVI-Out Port or HDMI-Out port, and turn it on. Go to the NVIDIA Control Panel. Click Display, and then click Set up multiple displays. Choose the nView display mode you wish to use. Select the displays you want to use (if your display is not shown click “My Display is not shown in the list...”...
Page 183 Windows XP Information To Enable Extended Desktop (Windows Display Properties) Attach your external display to the external monitor port or HDMI-Out port, and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).
Page 184: Hdmi Audio Configuration
Windows XP Information HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI 1. Connect a device with HDMI support to the HDMI-Out port. 2.
Page 185: Hdmi Video Configuration
Windows XP Information HDMI Video Configuration Connect an HDMI cable from the HDMI-Out port to your external display. Configure your external display as per the instructions in “Attaching Other Other Applications Displays” on page D - Set up your external display (TV or LCD) for HDMI input (see your display device If you are using a third manual).
Page 186: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 187: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 188: Stand By
Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 189: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery). If you are in a power saving mode set to save power through individual components (e.g.
Page 190: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 23). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 191: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 192: Proper Handling Of The Battery Pack
Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 193: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 194: Driver Installation
Windows XP Information Driver Installation Check the driver installation order from Table D - 4, on page D - 25 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the Drivers Installer menu below.
Page 195: Manual Driver Installation
Windows XP Information WinXP SP2 Driver Page # Manual Driver Installation Chipset D - 27 Click the Browse CD button in the Drivers Installer appli- Video D - 27 cation and browse to the executable file in the appropriate Audio D - 27 driver folder.
Page 196: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Drivers If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Windows XP Service Pack 2 this go to the Control Panel in the Windows OS and Make sure you install Windows XP Service Pack 2 (or a double-click the Add/Remove Programs item.
Page 197: Driver Installation Procedure
Windows XP Information Driver Installation Procedure Audio Insert the Device Drivers & Utilities + User’s Manual 1. Click 3. Install Audio Driver > Yes. disc and click Install Drivers (button). 2. Click Next (click Cancel if a Found New Hardware Wizard appears). Found New Hardware Wizard 3.
Page 198: Lan
Windows XP Information Module Drivers 1. Click 5.Install LAN Driver > Yes. See the following pages for the driver installation pro- cedures for any of the optional modules included in 2. Click Next > Install. your purchase configuration. 3. Click Finish. 4.
Page 199: Bluetooth Module
Windows XP Information Bluetooth Module The operating system’s Bluetooth Devices control panel is used to configure the Bluetooth settings in Windows XP, and therefore does not require a driver. Use the Fn + F12 key combination (see “Function/Hot Key Indi- cators”...
Page 200 Windows XP Information Bluetooth Local Area Connection Icon If you want to display the Local Area Connection icon for the Bluetooth connection in the taskbar, set it up as follows: Wireless Device Operation Aboard 1. Access the Network Connections control panel in Windows (Start > Settings > Aircraft Network Connections OR Start >...
Page 201: Bluetooth Configuration In Windows Xp
Windows XP Information Bluetooth Configuration in Windows XP Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Taskbar Make the device discoverable (to do this check your device documentation). Icon To Turn the Bluetooth Module On If you cannot see the...
Page 202: To Add A Bluetooth Device
Windows XP Information To Add a Bluetooth Device 1. Access the Bluetooth Devices control panel. 2. Click Options (tab), and make sure that Allow Bluetooth devices to connect to this computer check box (Connections) has a tick inside it. 3. Click Devices (tab), and then click Add. 4.
Page 203 Windows XP Information To Change Settings for the Bluetooth Device Access the Bluetooth Devices control panel. Click on the device you want to change and click Properties to: • Change the name of the device (click General, type a new name and click OK). •...
Page 204: D - 34 Pc Camera Module
Windows XP Information PC Camera Module Before installing the optional PC Camera module driver use the Fn + F10 key com- Taking Still Pictures bination to toggle power to the module. The PC Camera module uses the BisonCap application to capture video files. Double-click Computer icon on the desktop, or go the Start...
Page 205: Pc Camera Driver Installation
Windows XP Information PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. Latest PC Camera Driver Information 2. Click Option Drivers (button). 3.
Page 206: Pc Camera Audio Setup
Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 207: Bisoncap
Windows XP Information BisonCap BisonCap is a video viewer for general purpose video viewing and testing, and cap- turing video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate Cam menu (it is recommended that you set the capture file before the capture the file size (File >...
Page 208: Reducing Video File Size
Windows XP Information Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties) If necessary you can remove the recorded video file to a removable medium e.g.
Page 209: Eliminating Screen Flicker
Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap program is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select Video Capture Filter..Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 210 Windows XP Information Zoom The BisonCap program allows you to zoom the camera in and out. 1. Run the BisonCap program. 2. Go to Zoom and select Zoom Out/Zoom In. Figure D - 22 Zoom/Setting Snapshot Folder Taking Still Pictures The Snapshot folder’s The BisonCap program allows you to take still pictures.
Page 211: Wlan Module
Windows XP Information WLAN Module Before installing the Wireless LAN driver use the Fn + F11 key combination to toggle power to the module. Your installation procedure will be dependent upon which WLAN module is included in your purchase option. Download Prerequisite Files Before beginning the driver installation process for Windows XP it is necessary to make sure you have a working inter- net connection.
Page 212: Intel Wlan Driver Installation
Windows XP Information Intel WLAN Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 2.Install Wireless Lan Driver > Yes. 4.
Page 213 Windows XP Information 16. If you do not see your Wireless Access Point click Refresh (button). 17. Click Help (link) to bring up the Help Menu. 18. Make sure that the WiFi On button is selected. Figure D - 23 - Intel PROSet Wireless WiFi Connection Utility WLAN Module D - 43...
Page 214: D - 44 Fingerprint Reader Module
Windows XP Information Fingerprint Reader Module If you have included the fingerprint reader in your purchase option you will need to Help & Manual install the driver as per the instructions below. Right-click the taskbar icon Make sure you have administrator’s rights to your computer, and have a Windows to bring up the menu to password enabled for full security protection.
Page 215: User Enrollment
Windows XP Information User Enrollment Click Start > Programs/All Programs > Protector Suite QL > User Enrollment, or double click the taskbar icon On the first run of the program you will be asked to click the button to accept the license, and then click OK. Click Next and select “Enrollment to the hard disk”, and click Finish.
Page 216 Windows XP Information 10. Click Finish. 11. Click any of the headings under “Learn more about:” to get more information on any topic. 12. Click Close. 13. Right-click the taskbar icon to bring up the menu that allows you to Edit Fingerprints, start Control Center, access the Help menu etc.
Page 217: Usb Tv Tuner Module
Windows XP Information USB TV Tuner Module A CD containing drivers, software and a user guide will be supplied if your purchase TV Antenna configuration includes the optional USB TV Tuner module. In addition a driver is provided on the Device Drivers & Utilities + User’s Manual disc for the remote The TV antenna sup- plied with any TV Tuner control supplied with the TV Tuner.
Page 218: Consumer Infrared Remote Control Unit Driver
Windows XP Information Consumer Infrared Remote Control Unit Driver 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 4.Install CIR Driver > Yes. 4. Click Next > Yes > Next. 5.
Page 219 Windows XP Information 14. Choose the language you prefer, and click Next. 15. Click Next > Next > Next. 16. Click “Yes, restart my computer now.” (button) and click Next. 17. Click Finish to restart the computer. 18. Run the Hybrid DTV application from the Start > Programs/All Programs > Hybrid DTV and select the Hybrid DTV program or double-click the Hybrid DTV shortcut on the desktop.
Page 220 Windows XP Information D - 50...

EUROCOM Notebook User Manual

Quick Start Guide

Storage Devices, Mouse, Audio & Printer

Power Management

Drivers & Utilities

Upgrading the Computer

BIOS Utilities

Modules

Troubleshooting

Interface (Ports & Jacks)

NVIDIA Video Driver Controls

Specifications

Windows XP Information

Quick Links

Need help?

Questions and answers

Related Manuals for EUROCOM Notebook

Summary of Contents for EUROCOM Notebook
