Removing the Hard Disk in the Secondary HDD Bay
1. Turn off the computer, and turn it over and remove the battery.
2. The secondary hard disk bay is located under the battery compartment.
3. Remove screws -
25
4. Slide the hard disk assembly in the direction of the arrow
5. Lift the hard disk assembly
6. Remove the screws
31
7. Reverse the process to install any new hard disk(s).
25 26
28 27
29
.
28
out of the compartment.
30
- to release the hard disk from the case
34
30
Upgrading The Computer
.
29
.
35
33
35 34
31
32
Upgrading the Hard Disk Drive(s) 6 - 7
Figure 6 - 5
Secondary HDD
Removal
