Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 7 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 8: Power Safety
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply. If you are unsure of your local power specifications, consult Warning your service representative or local power company.
Page 9: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 12 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 13 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 14 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 15: Table Of Contents
Preface Contents Notice .................I System Map: Front & Rear Views .......1-12 FCC Statement .............II System Map: Left View ..........1-13 Instructions for Care and Operation ......IV System Map: Right View ..........1-14 Power Safety .............. VI System Map: Bottom View ..........1-15 Battery Precautions ...........VII Windows Vista Start Menu &...
Page 16 Preface Audio Features .............2-14 Proper handling of the Battery Pack ......3-12 S/PDIF-Out Support ..........2-15 Battery FAQ ..............3-13 Adding a Printer ............2-16 Drivers & Utilities USB Printer ..............2-16 Parallel Printer ............2-16 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ....4-3...
Page 17 Preface BIOS Utilities Upgrading The Computer Overview ................5-1 Overview ................6-1 The Power-On Self Test (POST) ........5-2 When Not to Upgrade ..........6-2 The Setup Program ............5-3 Removing the Battery ............6-3 Entering Setup .............5-3 Upgrading the Hard Disk Drive ........6-4 Setup Screens ...............5-4 Upgrading the Optical (CD/DVD) Device ....6-6 Main Menu ..............5-5 Upgrading the System Memory (RAM) ......6-7...
Page 18 Preface Troubleshooting Intel Video Driver Controls Overview ................8-1 Intel Video Driver Installation ........B-1 Basic Hints and Tips ............8-2 Video (VGA) ............. B-1 Backup and General Maintenance .........8-3 Dynamic Video Memory Technology ......B-1 Viruses ................8-4 Intel Graphics Properties ..........B-2 Upgrading and Adding New Hardware/Software ..8-5 Scheme Options ............
Page 19 Preface ExpressCard Slot ............C-3 System Power Options..........D-23 Communication ............. C-4 Stand by Mode vs. Hibernate Mode ......D-23 Power Management ............C-4 Configuring the Power Button ........D-25 Power ................C-4 Battery Information ............. D-26 Battery ................C-4 Recharging the Battery with the AC/DC Adapter ..D-27 Environmental Spec ............
Page 20 Preface XVIII...
Page 21: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Model & Design Differences
Quick Start Guide Model & Design Differences This notebook series includes two different model types (Model A or Model B) based upon the battery type sup- ported (see Table 1 - 1 below). The series also includes three different designs which vary slightly in color and appearance.
Page 23: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 24: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows Vista/Windows XP) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 25: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find the following operating systems are sup- ported.
Page 26: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 27: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Optional Built-In PC Camera Speakers Wireless Device Power Button Operation Aboard Hot Key Buttons Aircraft Keyboard The use of any portable TouchPad and Buttons electronic transmission de- Built-In Microphone vices aboard aircraft is usu- LED Indicators ally prohibited.
Page 28: Led Indicators
Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Table 1 - 3 - LED Indicators Icon Color Description Green Number Lock Activated Green Caps Lock Activated Green Scroll Lock Activated Green The Computer is On Blinking Green...
Page 29: Hot Key Buttons
Quick Start Guide Hot Key Buttons These buttons give instant access to the functions indicated in the table below. The Application and zoom hot key functions depend on whether or not a PC Camera module installed. Table 1 - 4 - Hot Key Buttons Hot Key Function PC Camera Installed...
Page 30: Keyboard
Quick Start Guide Keyboard The keyboard has a numerical keypad for easy numeric data input, and features function keys to allow you to change operational features instantly (see Figure 1 - Function Keys NumLk & ScrLk Keys Numeric Keypad Fn Key Figure 1 - 3 - Keyboard Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard.
Page 31 Quick Start Guide Function Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Function Function Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8 Decrease LCD Brightness Fn + F1 TouchPad Toggle Fn + F9...
Page 32: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views LED Indicators Serial Port Mini-IEEE 1394 Port 1 * USB Port DC-In Jack Battery Figure 1 - 4 - Front & Rear Views Mini-IEEE 1394 The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. 1 - 12 System Map: Front &...
Page 33: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 5 - Left View Security Lock Slot Optical Device Drive Bay (see page RJ-11 Modem Jack S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack Line-In Jack Changing DVD Regional Codes Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click the + CD Emergency Eject next to DVD/CD-ROM drives.
Page 34: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 6 - Right View ExpressCard Slot (see page 7-in-1 Card Reader 2 * USB 2.0 Ports RJ-45 LAN Jack 7-Pin S-Video-Out Jack ExpressCard Slot External Monitor Port The ExpressCard Slot accepts either ExpressCard/34 or ExpressCard/54 formats. 7-in-1 Card Reader The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / SD (Secure Digital) /...
Page 35: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 7 - Bottom View Vent/Fan Intake Battery Hard Disk Bay Cover The CPU is not a user ser- CPU/RAM Bay Cover viceable part. Opening this compartment, or accessing the CPU in any way, may vi- olate your warranty.
Page 36: Windows Vista Start Menu & Control Panel
Quick Start Guide Windows Vista Start Menu & Control Panel Most of the control panels, utilities and programs within Windows Vista (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 37: Video Features
Quick Start Guide Video Features Your computer has built-in Intel (Intel 945GM) video. You can switch display devices, and configure display options, from the Display Settings control panel (in Personalization) in Windows Vista as long as the appro- priate Intel video driver is installed. To access Display Properties in Windows Vista: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 38 Quick Start Guide Figure 1 - 9 - Display Properties Desktop Intel Display Mode Description Single Mode One of the connected displays is used as the display device Intel(R) Dual Display Clone Mode Both connected displays output the same view and may be configured independently Extended Desktop Mode Both connected displays are treated as separate devices, and act as a virtual desktop Table 1 - 6 - Display Options...
Page 39: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 16) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 40 Quick Start Guide 1 - 20...
Page 41: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • 7-in-1 Card Reader • ExpressCard Slot •...
Page 42: Hard Disk Drive
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives (see “Storage” on page C - 2) with a height of 9.5 mm.
Page 43: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 2). The Adjustment optical device is usually labeled “Drive D:”...
Page 44: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 45: Dvd Regional Codes
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 46: 7-In-1 Card Reader
Features & Components 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 47: Expresscard Slot
Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which require a larger interface slot, e.g. rubber cover provided in CompactFlash card reader.
Page 48: Touchpad And Buttons/Mouse
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- Once you have installed the TouchPad driver (see...
Page 49: Function Keys/Hot Keys
Features & Components Function Keys/Hot Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn Hot Key Program key is held down. In addition to the basic function key combinations; visual indica- tors are available when the hot key driver is installed (see “Hot-Key Buttons”...
Page 50 Features & Components Fn/Hot Key Function Fn + F1 TouchPad Toggle Fn + F3 Mute Toggle Fn + F5/F6 Volume Decrease/Increase Table 2 - 2 Fn + F8/F9 Brightness Decrease/Increase Hot Key & Function Key Combo Fn + F10 PC Camera Power Toggle Indicators Fn + F11 WLAN Module Power Toggle...
Page 51: Application Quick Buttons
Features & Components Application Quick Buttons Note that the application quick button utility is designed to allow use of the hot key Application.exe buttons in absence of the optional PC Camera (only install the application quick button utility if the PC Camera is not installed). You will need to install the You will need to locate Quick Button Utility (see “Application Quick Button”...
Page 52: Recording Audio
Features & Components Recording Audio audio record hot key button allows you to record audio (the hot key program Hot Key Program must be running - see sidebar) from either the built-in microphone, or from a micro- phone connected to the microphone-in jack. To record on the computer, setup the au- audio record dio recording options in Windows as follows (see...
Page 53 Features & Components Figure 2 - 9 Audio Setup for Recording (Windows Vista) Right-click Recording Audio 2 - 13...
Page 54: Audio Features
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 55: S/Pdif-Out Support
Features & Components S/PDIF-Out Support If you wish to configure your system for S/PDIF-Out sound support, then follow the instructions below: Double-click the icon in the taskbar to access the Realtek HD Audio Manager menu. Right-click the Analog Back Panel icon , and click to select Connector Retasking.
Page 56: Adding A Printer
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Page 57: Power Management
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 58: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack at the rear of the computer.
Page 59: Turning On The Computer
Power Management Turning on the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Shut Down er button on the front panel. Note that you should al- When the computer is on, you can use the power button as a Sleep/Hibernate hot- ways shut your comput- er down by choosing the key button when it is pressed for less than 4 seconds (pressing and holding the power...
Page 60: Power Plans
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and If the display is off the to send the computer into Sleep after a period of inactivity.
Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance for maximum performance when the computer is pow- ered from an AC power source.
Page 62: System Power Options
Power Management System Power Options You can use the system power options to stop the computer’s operation and restart Sleep Button where you left off. The system features Sleep and Hibernate power saving states (Hibernate will need to be enabled from power plan Advanced Settings see Figure The Sleep Button 3 - 1 on page 3 -...
Page 63: Sleep
Power Management Sleep Sleep uses very little system power, and takes a short time to return to full operation. After an extended period of time in Sleep the computer will save the contents of sys- Sleep Mode & tem memory (e.g. any open documents and applications) to the hard disk and shut Mobile PC Battery the system down.
Page 64: Configuring The Power Buttons
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to either Sleep or Hibernate. In Sleep mode the LED will blink Protection green. In Hibernate mode the LED will be off. If only the display is turned off, the LED will remain green.
Page 65: Battery Information
Power Management Battery Information Please follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- cally low, immediately grams you are running, and peripheral devices attached.
Page 66: Conserving Battery Power
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 67: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason see “Removing the Battery”...
Page 68: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if bat- tery is incorrectly replaced.
Page 69: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 70 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 8 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 71 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 72 Power Management 3 - 16...
Page 73: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM (Win Vista OR WinXP) contains the drivers and vantage of some newer hardware components for utilities necessary for the proper operation of the com-...
Page 74: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install Vista Drivers (button), or Drivers Installer menu below.
Page 75: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers Driver Page # If you wish to update/reinstall individual drivers it may be necessary to uninstall the original driver.To do Video Page 4 - 5 this go to the Control Panel in the Windows OS and Audio Page 4 - 6 double-click the Programs and Features icon (Pro-...
Page 76: Manual Driver Installation
Drivers & Utilities Manual Driver Installation If you wish to install the drivers manually, click the Exit button to quit the Drivers Installer application, and then browse to the executable file in the location listed in the table below and follow the installation procedure for each driver.
Page 77: User Account Control (Win Vista)
Drivers & Utilities User Account Control (Win Vista) Driver Installation Procedure If a User Account Control prompt appears as part of Video the driver installation procedure, click Continue or Allow, and follow the installation procedure as direct- 1. Click 1.Install Video Driver > Yes. 2.
Page 78: Modem
Drivers & Utilities Modem CardReader 1. Click 3.Install Modem Driver > Yes. 1. Click 5.Install CardReader Driver > Yes. 2. Click OK. 2. Click Next. 3. The modem is ready for dial-up configuration. 3. Click the button to accept the license and click Next.
Page 79: Application Quick Button
Drivers & Utilities Application Quick Button If you do not have a PC Camera module installed, then the Quick Button Utility will appear in the Driv- Adding/Removing a PC Camera ers Installer menu (only install the quick button driver if the PC Camera is not installed). See Note that the Quick Button and PC Camera drivers can- not co-exist.
Page 80: Wireless Lan
Drivers & Utilities Wireless LAN See the introduction in “Wireless LAN Module” on page 7 - 2, and check the installation procedure. Bluetooth See the introduction in “Bluetooth Module” on page 7 - 7, and check the installation procedure. PC Camera See the introduction in “PC Camera Module”...
Page 81: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Settings Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return to Set- up and restore the Set- Configuration: The Setup utility up Defaults with <F9>.
Page 82: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 83: The Setup Program
BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage ba- sic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 3 is usually present for a few seconds...
Page 84: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section are screen to make changes to Setup.
Page 85: Main Menu
BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 5 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:12:05] System Date: [01/15/2007] IDE Channel 0 Master [60012MB SATA1] <Tab>, <Shift Tab>, or IDE Channel 1 Master [CD-ROM] <Enter>...
Page 86: Ide Channel 0 Master/Ide Channel 1 Master (Main Menu)
BIOS Utilities IDE Channel 0 Master/IDE Channel 1 Master (Main Menu) Pressing Enter opens the sub-menu to show the configuration of either a CD Device or HDD on the computer’s IDE Channel 0/SATA port 1. Use the Auto (Type:) set- ting to have the items configured automatically for you.
Page 87: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Chipset Information Menu: Display Chipset Information of you Reset Configuration Data: [No] need Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Disabled] Power on Boot Beep: [Disabled]...
Page 88: Reset Configuration Data: (Advanced Menu)
BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to No as default. You can change the setting to Yes if you have in- stalled a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot.
Page 89: Security Menu
BIOS Utilities Security Menu Figure 5 - 4 PhoenixBIOS Setup Utility Security Menu Main Advanced Security Boot Exit Item Specific Help Supervisor Password Is: Clear User Password Is: Clear Supervisor Password Set Supervisor Password [E E nter] controls access to the setup utility.
Page 90: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system (see Password Warning the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password, then...
Page 91: Boot Menu
BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 5 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: USB FDC: Keys used to view or USB KEY: configure devices: IDE CD: TSSTcorpCD/DVDW TS-L632D-( Up and Down arrows IDE HDD: TOSHIBA MK6034GSX-(S1) select a device.
Page 92: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help Select Item...
Page 93: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help. Before you begin you will need: Please check with your service representative...
Page 94: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...
Page 95: Removing The Battery
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Page 96: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2). Follow your Warning operating system’s installation instructions, and install all necessary drivers and util- ities (as outlined in...
Page 97 Upgrading The Computer Use the tab to slide the hard disk in the direction of arrow Lift the hard disk up in the direction of arrow Reverse the process to install a new hard disk drive. Figure 6 - 3 HDD Removal Upgrading the Hard Disk Drive 6 - 5...
Page 98: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and remove screws Remove the hard disk bay cover Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.
Page 99: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 200 pin Small Outline Dual In-line (SO- DIMM) DDRII (DDR2) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 100 Upgrading The Computer Remove the bay cover Figure 6 - 6 CPU/RAM Bay Cover Removed Contact Warning Be careful not to touch Gently pull the two release latches on the sides of the memory socket in the the metal pins on the direction indicated by the arrows ( &...
Page 101 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 8 RAM Module Removal Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot.
Page 102: Upgrading The Processor
Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing processor with a fast- Warranty er/new one you will need to contact your customer service representative. We rec- ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.
Page 103: Modules & Options
Modules & Options Chapter 7: Modules & Options Wireless Device Overview Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 104: Wireless Lan Module
Modules & Options Wireless LAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe Wireless Device WLAN module or 802.11 b/g USB WLAN module in your purchase option, make Operation Aboard sure that the Wireless LAN module is on (the LED will be green and the indica- Aircraft will briefly be displayed when the module is powered on) before installing...
Page 105: Connecting To A Wireless Network
Modules & Options Connecting to a Wireless Network Make sure the Wireless LAN module is turned on. Click the taskbar wireless icon , and then click Connect to a network (or right- click the icon , and then click Connect to a network). Figure 7 - 1 Taskbar Menus Click icon...
Page 106 Modules & Options Click a network, and then click Connect. If you do not see a network you want to connect to, click Set up a connection or network (a list of options will appear allowing manual searching, and creating a new network).
Page 107 Modules & Options To disconnect from the wireless network you can click the taskbar wireless icon , and then select Connect or disconnect to access the network menu, and click Disconnect (or right-click the icon , and then click Disconnect from). Security Enabled Networks You should try to make...
Page 108: Windows Mobility Center
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 109: Bluetooth Module
Modules & Options Bluetooth Module If you have included a Bluetooth module in your purchase option, make sure that Wireless Device the optional Bluetooth module is on (the LED will be green and the indicator Operation Aboard will briefly be displayed when the module is powered on) before installing the Aircraft Bluetooth driver.
Page 110 Modules & Options User Guides & Help View BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Cor- poration BlueSoleil - Main Window control panel. Click the Help menu select Contents and Index. Look through Getting Started or select the ap- propriate User Guide...
Page 111: Pc Camera Module
Modules & Options PC Camera Module If you have included a PC Camera module in your purchase option, make sure that the optional PC Camera module is on (the indicator will briefly be displayed Taking Still Pictures when the module is powered on) before installing the PC Camera driver. Make sure You can use the applica- you install the drivers in the order indicated in Table 4 - 1, on page 4 -...
Page 112: Pc Camera Driver Installation
Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Install Option Drivers (button). 3. Click 3.Install Camera Driver > Yes. 4.
Page 113: Pc Camera Audio Setup
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 114 Modules & Options Figure 7 - 8 Audio Setup for PC Camera Right-click 7 - 12 PC Camera Module...
Page 115: Bisoncap
Modules & Options BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu, or by pressing the application button (it is recommended that you...
Page 116: Eliminating Screen Flicker
Modules & Options Eliminating Screen Flicker If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the BisonCap program. Go to Options and scroll down to select “Video Capture Filter...”. Click either 50Hz or 60Hz under Frequency in Property Page (tab).
Page 117: Pc Camera Hot Key Buttons
Modules & Options PC Camera Hot Key Buttons You can use the PC Camera hot key buttons (the quick button utility must NOT be installed - see “Application Quick Button” on page 4 - to run the Bison- Snapshot Folder Cap program, to take still pictures and to zoom the camera in and out (if you have The Snapshot folder’s installed the hot key and PC Camera drivers - see...
Page 118 Modules & Options 7 - 16...
Page 119: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 120: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 121: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 122: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 123: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 124 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 125: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power Battery missing / incorrectly installed. Check the battery bay, make sure the battery is present and but it doesn’t work. seated properly (the design of the battery only allows it to go in one way). Make sure there’s nothing interfering with the battery contacts.
Page 126 Troubleshooting Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 127 Troubleshooting Problem Possible Cause - Solution forget boot If you forget the password, you may have to discharge the battery of the CMOS. Contact your password. service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 128 Troubleshooting Problem Possible Cause - Solution Unwelcome numbers If the LED is lit, then Num Lock is turned ON. (see “LED Indicators” on page 1 - appear when typing. Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically.
Page 129 Troubleshooting Problem Possible Cause - Solution Wireless LAN/ The modules are off. Check the LED indicator and/or function key indicator to see if the Bluetooth modules WLAN/Bluetooth module is on or off (see “LED Indicators” on page 1 - 8). If the LED indicator is cannot be detected.
Page 130 Troubleshooting 8 - 12...
Page 131: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 132: Notebook Ports And Jacks
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 133: Mini-Ieee 1394 Port
Interface (Ports & Jacks) Item Description Mini-IEEE 1394 Port This port allows a high-speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). Mini-IEEE 1394 Port The Mini-IEEE 1394 port only supports SELF POWERED IEEE 1394 devices. RJ-11 Modem Jack This port connects to the built-in modem.
Page 134: S/Pdif-Out Jack
Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. 7-Pin S-Video-Out Jack Connect your television to your computer and view DVDs, VCDs or anything else your computer can display.
Page 135: Intel Video Driver Controls
Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on page 1 - DVMT Notes Intel Video Driver Installation DVMT is not local video memory. Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 DVMT will not function 3.
Page 136: Intel Graphics Properties
Intel Video Driver Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for Mobile. The Intel GMA control Open the Display Settings (Personalization) control panel (see “Video Fea- panel can also be ac- tures”...
Page 137 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.
Page 138: Scheme Options
Intel Video Driver Controls Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate the actual application Open the Display Settings control panel and click Advanced Settings (button).
Page 139: Display Devices
Intel Video Driver Controls Display Devices Besides the built-in LCD, you can also use an external monitor/flat panel display or Function Key TV as your display device. The following are the display options: Combination The built-in LCD. You can use the Fn + F7 An external monitor connected to the external monitor port.
Page 140: Attaching Other Displays
Intel Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor port at the rear of the computer. Windows Vista Attach your external display to the external monitor port (or TV to the S-Video-Out Jack), and turn it on.
Page 141 Intel Video Driver Controls ® Intel GMA Driver for Mobile Go to the Intel Graphics Properties control panel (see “Intel Graphics Proper- ties” on page B - 2) and click Display Devices. Multiple Display Click to choose the display option from the Multiple Display menu. Click Apply (and OK to confirm the settings change) and OK (button).
Page 142: Display Modes
Intel Video Driver Controls Display Modes Single Display Only one of your attached displays is used. Intel(R) Dual Display Clone (mirrored) This mode will drive multiple displays with the same content. Each device may be configured independently for different resolutions, refresh rates, color quality etc. Use this feature to display the screen through a projector for a presentation.
Page 143 Intel Video Driver Controls To Enable Intel(R) Dual Display Clone Attach your external monitor to the external monitor port (or TV to the S-Video-Out Jack), and turn it on. Go to the Intel Graphics Properties control panel (see “Intel Graphics Properties”...
Page 144 Intel Video Driver Controls To Enable Extended Desktop Attach your external monitor to the external monitor port (or TV to the S-Video-Out Jack), and turn it on. Display Settings Go to the Intel Graphics Properties control panel (see “Intel Graphics Extended Desktop Properties”...
Page 145 Intel Video Driver Controls Using New Display Detected to Enable Extended Mode Attach your external display to the external monitor port (or TV to the S-Video-Out Jack), and turn it on. Display Settings If a New Display Detected window does not appear in Windows Vista, go to the Extended Desktop Windows Mobility Center control panel (Mobile PC >...
Page 146 Intel Video Driver Controls Using Display Settings to Enable Extended Mode Attach your external display to the external monitor port (or TV to the S-Video-Out Jack), and turn it on. Open the Display Settings control panel (see “Video Features” on page 1 - 17).
Page 147: Tv Settings
Intel Video Driver Controls TV Settings If you are using a TV as a display device adjust the display settings as follows: Function Key Use an S-Video cable to connect your TV to the S-Video-Out Jack and turn it on. Combination Go to the Intel Graphics Properties control panel (see “Intel Graphics...
Page 148 Intel Video Driver Controls Click Display Settings to adjust the settings for the television. Choose the appropriate TV system from Video Standard dropbox. Click the TV Settings (button) to make any video adjustments for the television. Figure B - 11 TV Settings B - 14 TV Settings...
Page 149: Specifications
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, delayed or updated due to the manufacturer's release schedule. Check with your service center for details.
Page 150: Core Logic
Specifications Feature Specification Core Logic Intel 945GM + ICH7-M Memory Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) 533/667 MHz 64-bit Wide DDRII (DDR2) Data Channel Memory Expandable up to 2GB (256/ 512/ 1024 MB DDRII Modules) (Note: Do Not Use Other Module Types) Video Adapter Intel 945GM Integration Dynamic Video Memory Technology DVMT - Supports up to 224MB of Video Memory (dynamically...
Page 151: Keyboard & Pointing Device
Specifications Feature Specification Audio Integrated AZALIA Compliant Interface (HDA) 3D Stereo Enhanced Sound System Sound-Blaster PRO™ Compatible 2 * Built-In Speakers Built-In Microphone Note: External 7.1 CH Audio Output Support Configurable Through Headphone-Out, Microphone-In, Line-In and S/PDIF Out Jacks Keyboard & Winkey Keyboard Built-In TouchPad with Scrolling Function Pointing Device...
Page 152: Communication
Specifications Feature Specification Communication AZALIA 56K Plug & Play Fax/Modem v1.5 Compliant 10/ 100/ 1000 PCIe Fast Ethernet LAN USB Bluetooth V2.0 + EDR Module (Factory Option) 1.3M Pixel USB PC Camera Module (Factory Option) Wireless Module Options: Intel PRO/Wireless 3945ABG PCIe Wireless LAN Module 802.11 b/g USB Wireless LAN Module Power Supports ACPI 3.0...
Page 153: Optional
Specifications Feature Specification Optional Optical Drive Module Options: Intel PRO/Wireless 3945ABG PCIe Wireless LAN DVD/CD-RW Combo Drive Module Module DVD-Dual Drive Module 802.11 b/g USB Wireless LAN Module DVD-Super Multi Drive Module 6 Cell Smart Lithium-Ion Battery Pack USB Floppy Disk Drive (Factory Option) 1.3M Pixel USB PC Camera Module (Factory Option) USB Bluetooth V2.0 + EDR Module (Factory...
Page 154 Specifications C - 6...
Page 155: Windows Xp Information
Windows XP Information Appendix D: Windows XP Information This Appendix contains information (including control panel information, driver installation etc.) for users of the Windows XP OS. D - 1...
Page 156: D - 2 Dvd Regional Codes
Windows XP Information DVD Regional Codes Changing DVD Regional Codes Go to the Control Panel and double-click System > Hardware (tab), click Device Manager, then click the + next to DVD/CD-ROM drives. Double-click on the DVD-ROM device to bring up the Properties dialogue box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 157: Windows Xp Start Menu & Control Panel
Windows XP Information Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 158: Function Keys/Hot Keys
Windows XP Information Function Keys/Hot Keys The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key Hot Key Program is held down. In addition to the basic function key combinations; visual indicators are available when the hot key driver is installed (see “Hot Key (WinXP)”...
Page 159 Windows XP Information Fn/Hot Key Function Fn + F1 TouchPad Toggle Fn + F3 Mute Toggle Fn + F5/F6 Volume Decrease/Increase Fn + F8/F9 Brightness Decrease/Increase Fn + F10 PC Camera Power Toggle Fn + F11 WLAN Module Power Toggle Fn + F12 Bluetooth Module Power Toggle Activate BisonCap Program/ Take Still Picture...
Page 160: Recording Audio
Windows XP Information Recording Audio audio record hot key button allows you to record audio (the hot key program must be running - see sidebar) from either the built-in microphone, or from a micro- Hot Key Program phone connected to the microphone-in jack. To record on the computer, setup the au- audio record dio recording options in Windows as follows (see...
Page 161 Windows XP Information Figure D - 4 Audio Setup for Recording (Windows XP) Function Keys/Hot Keys D - 7...
Page 162: Application Quick Buttons
Windows XP Information Application Quick Buttons Note that the quick button driver is designed to allow use of the hot key buttons in Application.exe absence of the optional PC Camera (only install the quick button driver if the PC Camera is not installed). You will need to install the Application Quick Button You will need to locate driver (see “Application Quick Button (WinXP)”...
Page 163: Audio Features
Windows XP Information Audio Features You can configure the audio options on your computer from the Sounds and Audio Devices Windows con- trol panel, or from the Realtek HD Audio Manager icon in the taskbar/control panel (this will bring up the Realtek Audio Configuration menus).
Page 164 Windows XP Information 8 Channel Sound Support If you wish to configure your system for 8 channel sound support, then the following ports should be used as outputs. Connect the system cables to the following audio jacks: • Side Speaker Out - Connect to S/PDIF Out •...
Page 165: Touchpad And Buttons/Mouse
Windows XP Information TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an exter- nal mouse your operat- Configuring the TouchPad and Buttons...
Page 166: D - 12 Video Features
Windows XP Information Video Features Your computer has built-in Intel (Intel 945GM) video. You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is in- stalled. To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel).
Page 167 Windows XP Information Display & Graphics Properties Taskbar Icon You can also access the controller prop- erties from the taskbar. Click on the icon to bring up the menu and scroll to Graph- ics Properties. If you cannot see the tray icon go to the Intel(R) Graphics Media Accelerator Driver for Mobile tab and click the “Show Tray Icon”...
Page 168 Windows XP Information You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful information about the graphics properties of the computer, and see the Support tab in Information to get weblinks to the latest information on the Intel Website. Function Key Combination You can use the Fn + F7 key combination to toggle through...
Page 169: Display Devices & Options
Windows XP Information Display Devices & Options Besides the built-in LCD, you can also use an external VGA monitor (CRT)/external Flat Panel Display or TV as your display device. A VGA monitor/Flat Panel Display connects to the external monitor port, a TV to the S-Video-Out jack.
Page 170: Attaching Other Displays
Windows XP Information Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor port at the rear of the com- puter. Attach your external monitor to the external monitor port (or TV to the S-Video-Out jack), and turn it on. Go to the Graphics Properties control panel and click Display Devices.
Page 171 Windows XP Information To Enable Intel(R) Dual Display Clone Mode Attach your external monitor to the external monitor port (or TV to the S-Video-Out jack), and turn it on. Go to the Graphics Properties control panel and click Display Devices. Click to choose Intel(R) Dual Display Clone.
Page 172 Windows XP Information To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port (or TV to the S-Video-Out jack), and turn it on. Go to the Graphics Properties control panel and click Display Devices. Click to choose Extended Desktop. Click Apply, and OK to confirm the settings change.
Page 173 Windows XP Information To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port (or TV to the S-Video-Out jack), and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if you are in Category View choose Appearance and Themes).
Page 174: Tv Settings
Windows XP Information TV Settings If you are using a TV as a display device adjust the display settings as follows: Attach your TV to the S-Video-Out jack and turn it on. Go to the Graphics Properties control panel and click Display Devices. Choose the television as one of your display devices.
Page 175: Power Settings
Windows XP Information Power Settings Click the Power Settings button in Display Settings (tab) to set the display options based on power status of the computer. Intel Display Power Saving Technology If this option is enabled, the system will adjust LCD brightness and contrast in order to save power (when the notebook LCD is the only display device and the system is battery powered).
Page 176: Power Management Features
Windows XP Information Power Management Features The Power Options control panel icon in Windows (see page 3) allows you to configure power management features for your computer. You may conserve power through individual components such as the monitor or hard disk, or you may use either Stand by or Hibernate mode to conserve power throughout the system.
Page 177: System Power Options
Windows XP Information Each Windows Power Scheme will also adjust the processor performance of your machine in order to save pow- er. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose the Home/Office Desk scheme for maximum performance when the computer is powered from an AC power source.
Page 178 Windows XP Information Stand by Stand by saves the least amount of power, but takes the shortest time to return to full operation. During Stand by the hard disk is turned off, and the CPU is made to idle at its slowest speed. All open applications are retained in memory.
Page 179: Configuring The Power Button
Windows XP Information Configuring the Power Button The power button may be set to send the computer in to either Stand by or Hibernate mode. In Stand by mode, the LED will blink green. In Hibernate mode the LED will be off (battery) or orange (AC/DC adapter). If you are in a power saving mode set to save power through individual components (e.g.
Page 180: Battery Information
Windows XP Information Battery Information Please follow these simple guidelines to get the best use out of your battery. New Battery Always completely discharge, then fully charge, a new battery (see “Battery FAQ” on page D - 29). Battery Life Your computer’s battery life is dependent upon many factors, including the programs you are running, and pe- ripheral devices attached.
Page 181: Recharging The Battery With The Ac/Dc Adapter
Windows XP Information Battery life may be shortened through improper maintenance. To optimize the life and improve its perfor- mance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to remove the battery for any reason “Removing the Battery”...
Page 182 Windows XP Information Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode • DO NOT connect the metal terminals (+, -) to each other Damaged Battery Warning Should you notice any physical defects (e.g.
Page 183: Battery Faq
Windows XP Information Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer by yourself even when you see a message that indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 184: D - 30 Driver Installation
Windows XP Information Driver Installation WinXP SP2 Driver Page # The Device Drivers & Utilities + User’s Manual CD- Install the appropriate Service Pack for WinXP D - 32 ROM contains the drivers and utilities necessary for the proper operation of the computer. Table D - 4 lists Chipset...
Page 185: Drivers Installer Application
Windows XP Information Drivers Installer Application 1. Check the driver installation order from Table D - 4 (the drivers must be installed in this order) which is the same Insert the Device Drivers & Utilities + User’s Manual as that listed in the Drivers Installer menu below. CD-ROM (WinXP) and click Install WinXP Drivers 2.
Page 186: Updating/Reinstalling Individual Drivers
Windows XP Information Updating/Reinstalling Individual Driv- If you wish to update/reinstall individual drivers it may Windows XP Service Pack 2 be necessary to uninstall the original driver.To do this go Make sure you install Windows XP Service Pack 2 (or a to the Control Panel in the Windows OS and double- Windows XP version which includes Service Pack 2) be- click the Add/Remove Programs item.
Page 187: Chipset D
Windows XP Information Chipset (WinXP) Modem (WinXP) 1. Click 1.Install Chipset Driver > Yes. 1. Click 5.Install Modem Driver > Yes. 2. Click Next > Yes > Next. 2. Click OK. 3. Click Finish to restart the computer. 3. The modem is ready for dial-up configuration. 4.
Page 188: Hot Key
Windows XP Information Hot Key (WinXP) 1. Click 8.Install Hotkey Utility > Yes. 2. Click Next > Install > Finish. Adding/Removing a PC Camera 3. Click Finish to restart your computer. Note that the Quick Button and PC Camera drivers can- not co-exist.
Page 189: Bluetooth Module
Windows XP Information Bluetooth Module If you have included a Bluetooth module in your purchase option, make sure that the Wireless Device optional Bluetooth module is on (the LED will be green and the indicator Operation Aboard will briefly be displayed when the module is powered on) before installing the Blue- Aircraft tooth driver.
Page 190 Windows XP Information User Guide View the BlueSoleil User Guides from the Help Menu (or press the F1 key) in the IVT Corpora- tion BlueSoleil - Main Window control panel. Click BlueSoleil User Guides in the Contents tab, and click to select the appropriate User Guide from the panel on the right.
Page 191: Pc Camera
Windows XP Information PC Camera Before installing the PC Camera driver, make sure that the optional PC Camera is Stand by/Hibernate on. Use the Fn + F10 key combination (see “Function Keys” on page 1 - 10) to or Shutdown Error toggle power to the PC Camera module.
Page 192 Windows XP Information PC Camera Driver Installation 1. Press the Fn + F10 key combination to power on the PC Camera module. 2. Insert the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP) into the Taking Still Pictures CD/DVD drive. 3.
Page 193 Windows XP Information PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows (see Figure D - 24 on page D - 40). Go to the Start menu and point to Settings (or just click Control Panel) and click Control Panel, then double- click the Sounds &...
Page 194 Windows XP Information Figure D - 24 Audio Setup (Windows XP) D - 40 PC Camera...
Page 195: Bisoncap
Windows XP Information BisonCap BisonCap is a video viewer useful for general purpose video viewing and testing, and can capture video files to .avi format. Pre-Allocating File Space Run the BisonCap application from the Start > Programs/All Programs > Bison- You may pre-allocate the Cam menu (it is recommended that you set the capture file before the capture file size for the capture file...
Page 196 Windows XP Information Eliminating Screen Flicker If you find that the video screen in the BisonCap application is flickering, you can try to adjust the setting in the Video Capture Filter options. 1. Run the BisonCap program. 2. Go to Options and scroll down to select “Video Capture Filter...”. 3.
Page 197: Pc Camera Hot Key Buttons
Windows XP Information PC Camera Hot Key Buttons You can use the PC Camera Hot key buttons (the quick button driver must not be in- stalled - see “Application Quick Button (WinXP)” on page D - to run Snapshot Folder the BisonCap program, to take still pictures and to Zoom the camera in and out (if The Snapshot folder’s you have installed the hot key and PC Camera drivers - see...
Page 198: D - 44 Wireless Lan Module
Windows XP Information Wireless LAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe WLAN Wireless Device module or 802.11 b/g USB WLAN module in your purchase option, make sure that Operation Aboard the Wireless LAN module is on (the LED will be green and the indicator Aircraft will briefly be displayed when the module is powered on) before installing the driv-...
Page 199 Windows XP Information Intel WLAN Driver Installation 1. Press the Fn + F11 key combination to power on the WLAN module. 2. Insert the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP) User Guide into the CD/DVD drive. Insert the Device Driv- 3.
Page 200 Windows XP Information 802.11 b/g WLAN Driver Installation 1. Press the Fn + F11 key combination to power on the WLAN module. 2. Insert the Device Drivers & Utilities + User’s Manual CD-ROM (WinXP) into the CD/DVD drive. 3. Click Install Options Drivers. 4.

EUROCOM Notebook User Manual

Quick Start Guide

Features & Components

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

Intel Video Driver Controls

Specifications

Power Management

Windows XP Information

Quick Links

Need help?

Questions and answers

Related Manuals for EUROCOM Notebook

Summary of Contents for EUROCOM Notebook
