System Map: Bottom View

1
2
Always completely discharge, then fully charge, a new battery before using it. Completely
discharge and charge the battery at least once every 30 days or after about 20 partial dis-
charges. See "Battery Information" on page 3 - 10
3
4 5
Battery Information
2
2
for full instructions.
System Map: Bottom View 1 - 15
Quick Start Guide
Figure 1 - 8
Bottom View
1. Sub Woofer
2. Fan Outlet/Intake
3. Component Bay
Cover
4. Battery
(Secondary HDD
Bay - HDD3)
5. Primary HDD Bay
(HDD1 & 2)
See Appendix A for a more
detailed description of the
ports & jacks etc.
Overheating
To prevent your comput-
er from overheating make
sure nothing blocks the
vent(s)/fan intake(s)
while the computer is in
use.
