Disassembly
Removing the Processor
1. Turn off the computer, and remove the battery (
2. Remove screws
3. Carefully lift up the memory socket cover
Figure 9
nect it).
4. Remove screws
Processor Removal
5. Carefully lift up the heat sink
a. Remove the screws.
b. Carefully lift the cover off
the computer.
c. Remove the screws in
the order indicated.
d. Remove the heat sink.
When replacing the
heat sink, make sure
you insert the screws
Heat Sink Unit
in the same order indi-
cated on the label.
The elongated heat
sink
13
pictured ap-
plies to models in this
series with two CPU
fan units. Some mod-
els may have a shorter
heat sink unit and a
single CPU fan.
7. Socket Cover
13. Heat Sink
• 10 Screws
2 - 16 Removing the Processor
-
from the memory socket cover
1
6
-
from the heat sink, in the order indicated on the label
9
12
off the computer.
13
a.
1
Reassembly Screw
Order
2
c.
12
9
page 2 - 8
).
.
(a fan cable
is still attached to the mainboard and you can discon-
7
8
b.
6
3
4
5
d.
10
11
.
8
7
13
