SECTION 6 : MOVING FADERS

Moving Faders vs
Standard Faders:
SmartDisplay
Menus
Setup
F1
Moving Faders Menu
SIDE NOTE:
Notice that the Macros
menu has been replaced by
the Moving Faders menu at
position F4. The macros
menu has been relocated to
position F1 in the Console
menu as shown here.
Euphonix CS3000/2000 MixView 3.0 Software Supplement
E
uphonix CS3000 & 2000 series consoles are designed to accept
Euphonix Moving Fader automation hardware and software. Each
optional moving fader I/O controller module provides four premium quality,
touch-sensitive, motorized faders in the lower fader positions as well as four
premium quality, non-motorized faders in the upper positions.
Traditionally, moving faders provide the following advantages when used in
automated audio consoles:
• Immediate visual feedback of exact channel level settings
• Instant touch control, a quicker, more intuitive way of writing and updat-
ing channel level automation "on the fly"
Visually, the differences between standard faders and moving faders installed
in a CS3000/2000, are subtle. The most obvious difference is the fader cap
itself, the former being dark gray in color while the latter are silver, touch-
sensitive metal caps which allow the fader to respond to the touch of the
engineer.
Let's get familiar with the Moving Fader SmartDisplay menus. [Esc] to the
Main menu, then press [F1] and then [F4] to access the Moving Faders menu:
Snap System Grps
F2 F3 F4
Motors:ON
F1
Setup Menu
Console Menu
Mstr Cnsl
F1 F2
Touch Slvs
F2 F3 F4
Mstr Cnsl Meter
F1 F2 F3
Macs Cnfg Diag
F1 F2 F3
Section 6: Moving Faders
Meter MFdr
F3 F4
MFdr
F4
Backup
F4
