Fader Source
Tracking
Exercise 2
16A->
F1
Aux Source Select Menu
SIDE NOTE:
When setting Fader Source
Tracking, the aux source selection
changes immediately to match that
of the designated fader, overriding
any previous aux setting. Note that
the previous aux settings are
not restored if tracking is later
set off. After removing Fader
Source Tracking, the aux send
retains its current settings but no
longer follows any fader source
selection changes.
Euphonix CS3000/2000 MixView 3.0 Software Supplement
Repeat the previous steps for aux sends C and D. Once completed, you can
verify routing by feeding a test tone to L4 and trying the aux sends. Be sure the
aux bus master controls are turned up and unmuted.
This concludes Exercise 1.
For reference, the possible aux send pre/Post routing configurations as seen in
the Aux Status menu are:
pre
pre lower & upper fader
PostLF
post lower fader
PostUP
post upper fader
Aux source selections are independent from fader source selections by
default. However, if desired, you can set any aux send to "track" a fader's
source selection changes using the Fader Source Tracking feature.
In this exercise, we will setup aux sends A thru D to source track channel 16's
lower fader source selections.
Press channel 16's aux A/B block attention key to display the Aux Status menu
and confirm that console attention is directed to aux send A. Press [F4] (down
arrows), then [F2] (SRC) to display the Aux Source Select menu:
ON
pre
F2
F3
F4
16A->
SRC ?
F1
F4 is used to set the aux send Fader Source Tracking. A lower case letter "p"
denotes pre fader routing and an upper case letter "P" denotes post fader
routing, while two dots " . ." denotes fader tracking disabled. Press [F4] to
select Post Lower Fader Source Tracking:
16A->
Repeat the previous steps for aux sends B, C and D. Once completed, the aux
sends' sources will automatically "track" whatever sources have been se-
lected to the channel's Lower fader.
Section 7: Channel Function Enhancements
16A->
SRC
F1
F2
<-p . .
F2
F3
F4
SRC ?
F1
F2
MODE
ASGN
F3
F4
<-PLF
F3
F4
7 - 49
