Section 5: Hyper-Surround
Exercise 1
3P1->
F1
Pan Setup Menu
Setting Up a 5.1 Panner
5 - 32
panner that is just the Sl-Sr (surrounds) sending to buses 4 and 5. All of these
formats and more are possible simultaneously with Hyper-Surround.
You will need 11 buses defined as pan buses in your Cube to complete all
three exercises. To quickly determine the number of pan buses available, press
the DSC [Pan Assign] and then [Bus Master] keys to view the Pan Bus
Master screen. The number of red bus master pots displayed on the screen
indicates the number of Pan buses available. Again, see the Cube section of
the main manual for details on how to define Cube buses. If you have fewer
than 11 Cube buses, complete as many exercises as possible until you run out.
Press the DSC [Pan Assign], [F4] (down arrows) and then [F2] (Setup) to view
the Pan Assign menu (only the DSC Pan Assign key should be lit).
OFF
F2 F3 F4
P1-> – – – – – – : – – –
F1
All panner setup operations use the "MCP" (Master Control Panel) section of
the DSC.
Euphonix CS3000/2000 MixView 3.0 Software Supplement
Preset Setup
F1 F2
B – –
F2 F3 F4
Pg 1 Pg 1 Pg 2 Pg 2 Pg 3 Pg 3 Pg 4 Pg 4
EQ EQ Dyn Dyn Aux Aux Pan Pan
Assign Assign
Active
F3 F4
List List
Bus Bus Chan Chan
Master Master
