Section 7: Channel Function Enhancements
SIDE NOTE:
Since aux sends A/B and C/D share their
respective aux blocks, the DSC [left
arrow] and [right arrow] keys are used
to direct attention between them.
M1 M2 DIR
L1 L2 ST1
L3 L4 ST2
7 8 9
4 5 6
1 2 3
7 - 48
Press the DSC [L4] key to directly assign the aux source routing:
16A->
Aux Source Menu
F1
Press the DSC keypad [1] key to directly assign the aux send to aux bus 1:
16A->
Aux Assign Menu
F1
Press the DSC [right arrow] key to direct attention to aux send B. Confirm
that B is now displayed in the SmartDisplay menu:
16B->
F1
As before, press the [L4] key to directly assign the aux source routing:
16B->
F1
Press the DSC keypad [2] key to directly assign aux send B to aux bus 2:
16B->
F1
Press channel 16's aux C/D block attention key to display the aux menu.
Confirm that C is now displayed in the SmartDisplay menu:
16C->
F1
Euphonix CS3000/2000 MixView 3.0 Software Supplement
Left and right DSC arrow keys
F2 F3
BUS 1
F2 F3
ON pre
F2 F3
F2 F3
BUS
F2 F3
ON pre
F2 F3
L4<-p. .
F4
F4
F4
L4<-p. .
F4
2
F4
F4
