Hyper-Surround Panning - Euphonix MixView CS3000 Software Manual

Section 4: The Audio Cube
Hyper-Surround
Panning
DSC Screen Display
Active panner
meters & position
controls displayed
DSC Assignable Rotary Controls
4 - 18
Once the Hyper-Surround panners are configured, the are accessed by pressing
the DSC [Pan Assign] key. While in the Pan menu and screen, calling atten-
tion to any fader block will access the panners available to that fader.
Position
indicator
Panner name
All panner
(Page 1)
Some Audio Cube "pre-configuration" is required before the Aux and Hyper
Surround screens appear as they do in the diagrams above. Typically, though,
once these configurations are done, they rarely need to be revisited.
This section deals mainly with hardware overview and the Audio Cube pre-
configurations and Cube aux sends. The following section explains in detail
how Hyper Surround panners are created and used.
