Unpacking the System

CAUTION Carefully remove the monitor and the base unit from their packaging. Do not let the monitor
or the base unit drop onto a hard surface, or damage to internal components may result.
Remove everything from the shipping cartons, and then look for the following items:
u
A monitor with video cable, power cord, and documentation (if purchased from
Intergraph Computer Systems)
u
The system's base unit and power cord
u
The system's keyboard and mouse
u
Intergraph Computer Systems documentation
u
Windows NT Workstation 4.0 or Windows 95 operating system software and
documentation
u
System software and documentation for any expansion cards or additional peripheral
devices purchased from Intergraph Computer Systems
If any of these items were not delivered, call the Customer Response Center immediately at
1-800-633-7248.
Save the packaging materials. If you need to return the system for repair, it must be in its
original packaging for you to obtain warranty service.

Placing System Components

CAUTION Do not move the base unit without first turning off the power, or damage to internal
components may result.
Remember these guidelines when placing system components:
u
Move and place the monitor and base unit carefully.
u
Place the base unit in a location with good air flow. Leave at least 3 inches of clearance
around the front and back panels.
u
Do not operate the base unit on its side.
u
Do not expose the system to high levels of dust, smoke, or moisture.
u
The location should maintain a temperature range of 10 C to 26 C (50 F to 80 F);
the optimum operating temperature is 21 C (70 F).
u
The location should maintain a humidity range from 20 percent to 80 percent non-
condensing; the optimum humidity level is 50 percent.
