TD-22x Bank 0
Memory SIMMs
16 MB Two 8 MB
32 MB Two 8 MB
Two 16 MB
48 MB Two 8 MB
Two 8 MB
64 MB Two 8 MB
Two 16 MB
Two 32 MB
96 MB Two 16 MB
Two 16 MB
128 MB Two 16 MB
Two 32 MB
Two 64 MB
192 MB Two 32 MB
Two 32 MB
256 MB Two 64 MB
Two 32 MB
Two 32 MB
320 MB Two 64 MB
384 MB Two 64 MB
450 MB Two 64 MB
512 MB Two 64 MB
The following illustrations show the sockets on the system board, which combined can hold
up to 128 MB (TD-2x), 256 MB (TD-220), or 512 MB (TD-225) of random-access memory
(RAM). TD-2x systems use synchronous dynamic RAM (SDRAM) memory, while TD-22x
systems use Extended Data Out (EDO) or Fast Page Mode (FPM) memory.
Bank 1 Bank 2
SIMMs SIMMs
Two 8 MB
Two 16 MB
Two 8 MB Two 8 MB
Two 8 MB Two 8 MB
Two 16 MB
Two 32 MB
Two 16 MB Two 16 MB
Two 16 MB Two 16 MB
Two 32 MB
Two 64 MB
Two 32 MB Two 32 MB
Two 64 MB
Two 32 MB Two 32 MB
Two 32 MB Two 64 MB
Two 32 MB Two 32 MB
Two 64 MB Two 32 MB
Two 64 MB Two 64 MB
Two 64 MB Two 64 MB
Bank 3
SIMMs
Two 8 MB
Two 16 MB
Two 32 MB
Two 32 MB
Two 32 MB
Two 32 MB
Two 64 MB
