Adding System Memory

You can add system memory to the computer by adding or replacing Single Inline Memory
Modules (SIMMs) or Dual Inline Memory Modules (DIMMs) on the system board. The
system board supports the following memory module sizes, according to system type:
TD-2x
Memory size
16 MB
32 MB
64 MB
TD-22x
Memory size
8 MB
16 MB
32 MB
64 MB
The following are common memory configurations:
TD-2x
Memory
16 MB
32 MB
48 MB
64 MB
96 MB
128 MB
DIMM Configuration
(non-parity)
2 x 64
4 x 64
8 x 64
SIMM Configuration
(non-parity)
2 x 32
4 x 32
8 x 32
16 x 32
Bank 0 Bank 1
DIMMs DIMMs
One 16 MB
One 16 MB One 16 MB
One 32 MB
One 16 MB One 32 MB
One 64 MB
One 32 MB One 32 MB
One 64 MB One 32 MB
One 64 MB One 64 MB
