Using TD-220 System Resources

Available system resources are assigned to PCI devices before they are assigned to ISA
devices. To install more ISA devices than you have open IRQs, you must disable one unused
system port for each excess ISA device, unless the device does not require an IRQ.
To disable an unused system port:
1. Restart the system and start the BIOS Setup program.
2. On the Advanced/Peripheral Configuration screen, select the port you want to disable
(Serial Port 1 Address, Serial Port 2 Address, or Parallel Port Address).
3. Change the value of the setting to Disabled.
4. Save the changes and exit from the BIOS Setup program.
The following expansion cards require specific system resource settings, as noted (all are
ISA devices except for the Ensoniq PCI Sound Card):
Expansion card
(installed in the system)
First modem (Windows NT)
Second modem (Windows NT)
First parallel printer adapter
Second parallel printer adapter
3Com network adapter
On a system running Windows 95, ensure the following system resources are set as noted:
System resource
Ensoniq sound card -- needed for
DOS legacy sound driver
Plug and Play operating system
Serial port 1 COM1
Serial port 2 COM2
Parallel port LPT1
Resources BIOS Setup
required parameter settings
COM3, IRQ 4 Disable serial port 1 (COM1)
COM2, IRQ 3 Disable serial port 2 (COM2)
Base address 278 None
Base address 3BC None
IRQ 10 (default) None
BIOS Setup parameter settings
Reserve IRQ 5
Serial port 1, serial port 2, and parallel port Enabled;
Plug and Play OS set to Yes
Reserve IRQ 4 (if port is to be used)
Reserve IRQ 3 (if port is to be used)
Reserve IRQ 7 (if port is to be used)
