User recommendations

To avoid over-allocation of disk space and the possibility of running out of disk space for non-user data:
• Only configure the libraries that you need
• Only configure the number of cartridges that you are likely to need
You can add cartridges at a later date to expand the system and remove individual blank cartridges
from a library without deleting the whole library, but cannot remove cartridges that have been written to.
See "Cartridges

To view device details

Click on a device in the top half of the page to view its details in the bottom half of the page,
where you can also edit and delete details. There are three tabs with device information. See
"Device parameters" on page 92.

To edit device details

1.
Select the device in the list to display its details and then click on Edit.
2.
Amend details as appropriate and click Update to apply them. The information for the
World Wide Names tab is generated automatically and cannot be changed. See also
"Device parameters" on page 92.

To create a new device

1.
To create a new device for the host, click on Create library.
2. Enter the appropriate details in the Libraries tab and click Create. There is also a tab to enable
and configure iSCSI Authentication, if this is required. Any information you enter on this tab
must match the information that you have configured in the iSCSI Initiator itself. (See also
"Device parameters" on page 92 below.)
Table 6 Device parameters
Libraries tab
Library Name
92
The Web Management Interface
(Configuration)" on page 94.
This is the name that is used to identify that device. You may like to enter a name
that identifies the host or backup job with which it is associated.
