Table 13 Replication source for local library parameters
Replication-Source library selected
Slot Mapping Name
Target Appliance Name
Target Appliance Address
Target Appliance Serial Number
Target Library Name
Status
Online
Replication-Target library selected
Slot Mapping Name
Source Appliance Address
Source Appliance Serial Number
Source Library Name
Status
Online
Table 14 Slot mapping for local library to source library parameters
Only when a Replication-Target library is selected
Slot Mappings
Source Slot Name Cartridge Barcode
Target Slot Name
Target Slot Name Cartridge Barcode
Replication Status

The replication wizards

When you select a Non-Replicating library, you will be able to run the Replication or Recovering wizard.
• Use the Replication wizard to create slot mappings for the non-replicating library; it becomes a Source
library. See "The Replication process" on page 68 for more information.
This is the slot mapping name. Is it created when you
run the wizard to define the grouping of slots that
you select.
The name of the Target Appliance to which cartridges
will be replicated.
The IP address of the Target Appliance to which
cartridges will be replicated.
The serial number of the Target Appliance to which
cartridges will be replicated.
The name of the library to which cartridges will be
replicated on the Target Appliance .
The status of the replication link for that library.
Whether the library is online.
This is the slot mapping name. Is it created when you
run the wizard to define the grouping of slots that
you select.
The IP address of the Source Appliance from which
cartridges will be replicated.
The serial number of the Source Appliance from
which cartridges will be replicated.
The name of the library from which cartridges will be
replicated on the Source Appliance.
The status of the replication link — need more info.
more info? — both online, target online?
These are the slot numbers in the Replication-Source
library that have been selected for replication.
These are any barcodes associated with those slots in
the Replication-Source library.
These are the mapped slot numbers in the
Replication-Target library. They usually have the name
of the barcode or they may be Unmapped.
These are any barcodes associated with those slots
in the Replication-Target library. The wizard allocates
barcodes automatically.
This is the status of the replication link between this
pair of mapped slots.
D2D Backup System HP D2D2503
109
