Switch View
This chapter briefly describes the views and interfaces available through the Switch View, which
consist of the following:
•
The Switch View
•
Events
•
Fabric Watch
•
Performance Monitor
•
Admin
•
Telnet
Note:

Web Tools

When using the Switch View, you are actually accessing Web Tools.
For more information on Web Tools, refer to the appropriate version of the Web Tools User's Guide.
Access
To access Web Tools:
1. Enter Fabric Manager.
The Switch window (or view) appears as part of the main Fabric View. See
3-1.
2. Select an individual switch icon.
Web Tools launches, as shown in
Capabilities
The Switch View, or Web Tools, provides a graphical interface that allows the administrator to
monitor and manage individual switches and ports from a standard workstation. All switches in the
fabric are displayed in the main window of Web Tools.
The Switch View displays as shown in
Fabric Manager User's Guide
on page 10-2
on page 10-3
on page 10-3
on page 10-3
on page 10-3
on page 10-3
The options available in the Switch View will vary depending on the version of Web Tools
that is installed on the individual switch.
Figure 10-1.
Figure 10-1.
Chapter
10
Figure 3-1 on page
10-1
