HP StorageWorks 8B - FC Entry Switch User Manual page 110

11
Administrative Task Examples
6. Select the highlighted switch by clicking on the left-arrow button, or by dragging and dropping
selections from the navigation-tree to the table.
7. Select the Login button and log in to the switch (if you have not previously done so).
8. Set up File Transfer properties, if you are prompted to do so.
Note:
9. Select OK.
The Configure Compare/Download window appears.
10. Select Apply to apply baseline configuration to switches.
Select Print a Report to print a report of switch configuration comparisons.
Select Cancel to exit window without saving changes.
Download and Apply Baseline Configuration
from a Switch
Perform the following steps to download and apply a baseline configuration from a
switch:
1. Create a Reboot Group if you intend to apply a Baseline Configuration to an entire fabric.
This is an optional step, however, it is recommended to maintain the stability of a fabric as
switches are rebooted.
For more information, refer to
2. Select Tools > Config.
3. Select Compare/Download from Switch.
4. Highlight a switch from the navigation-tree to use as a baseline configuration.
Note:
5. Highlight switches that you want to compare to the baseline configuration from the
navigation-tree.
6. Select the highlighted switch by clicking on the left-arrow button, or by dragging and dropping
selections from the navigation-tree to the table.
7. Select the Login button and log in to the switch (if you have not previously done so).
8. Set up File Transfer properties, if you are prompted to do so.
Note:
9. Select OK.
11-4
You can setup File Transfer properties anytime by selecting File > Options and selecting
the File Transfer tab. For detailed information about setting up File Transfer properties, see
File Transfer Tab on page 4-7.
or
or
Create a Reboot Group
You must select one switch only, not a whole fabric.
You can setup File Transfer properties anytime by selecting File > Options and
selecting the File Transfer tab. For detailed information about setting up File Transfer
properties, see File Transfer Tab
on page 11-6.
on page 4-7.
Fabric Manager User's Guide
