User Id
Password
IP, Name, WWN
SAN Elements
Filter
Selected Switches:
IP Address
Switch Name
Firmware Version
Userid
Status
Test & Apply
OK
Cancel
Apply
Setting up a Login for Multiple Switches
1. Select File > Fabric Login.
The Login Setup window appears.
2. Select the SAN Elements tab to list the available elements by IP, Name, or WWN.
3. Select a switch to setup and click it to highlight.
Fabric Manager User's Guide
Enter the User Id for a selected switch.
Enter the Password for a selected switch.
Click the appropriate radio button to display a selected group of
switches by IP address, name, or World Wide Name.
Displays the fabrics or groups that belong to the Storage Area
Network that the Admin is logged into.
Allows you to search for switches by IP address, Name, Type, FOS
Version, WWN, or Domain ID.
Displays the IP address of the selected switch.
Displays the name of the selected switch.
Displays the version of Fabric OS that is installed on the switch.
Displays the UserID of the individual who is logged into the
switch.
Displays the status of the switch login. Possible status reports are:
Ready, Success, or Authorization Failed.
When Success is displayed, the background will be green and
UserID and Password will be saved for performing admin
operations until the session is terminated.
When Authorization Failed is displayed, the background will be red
and the UserID and Password will not be saved in memory.
Select to check Userid and Password login on the listed switches.
Select to save configuration and exit window.
Click to cancel all changes made since changes were last applied,
and to exit Fabric Login. Changes cannot be cancelled once they
are applied.
Select to save configuration but leave window open.
