Installing Fabric Manager
To set the refresh frequency:
1.
2.
3.
The correct Browser Process Model must be selected.
To select the Browser Process Model (only required for Windows NT):
1.
2.
3.
Installing Fabric Manager on the Windows
Workstation
The Fabric Manager 3.0 installation package includes the following items:
•
ReadMe.txt file, providing product name, version, and late-breaking news.
•
Java Plug-in
•
FabricManager.Jar file, containing the required Java classes.
•
FabricManager.properties file, containing configuration information.
To install Fabric Manager 3.0:
1. Insert the Fabric Manager CD-ROM in the CD drive of the computer workstation.
If Fabric Manager is already installed on the computer, a window displays at this point to
indicate this. If this window displays, you must exit the installer and uninstall the existing
version.
The installer searches the local system for the correct version of the Java Plug-in. If this
version is not installed, a window displays warning that the correct version of the Java Plug-in
is missing. If the installer warns that the Java Plug-in is missing, perform step 3 before
continuing. Otherwise, continue with step 4.
The Welcome window displays, providing product information and version.
2. Click Next.
3. If the installer warns that the Java Plug-in is missing:
a.
b.
c.
2-4
Select Internet Options from the View menu if using Internet Explorer 4.x, or from the
Tools menu if using 5.x.
Select the General tab and click Settings (under "Temporary Internet Files").
Under "Check for newer versions of stored pages", select "Every visit to the page".
Select View > Internet Options if using Internet Explorer 4.x, or Tools > Internet
Options if using Internet Explorer 5.x.
Select the Advanced tab and click to expand the Browsing category.
Under "Browsing", select "Browse in a new process" if using Internet Explorer 4.x, or
"Launch browser windows in a separate process" if using Internet Explorer 5.x.
Click Exit to close the Fabric Manager installer, and then click Exit Install in the warning
dialog that displays.
View the local drives, right-click the icon for the Fabric Manager CD-ROM, and select
Explore.
Click to open the JRE folder, and then click the file jre-1_2_2_007-win.exe.
Fabric Manager User's Guide
