6
Actions Menu
8. Select Activate to save, implement the policy to the selected switches and exit the security
dialog box.
Select Save to save changes without implementing policies. You can come back later to make
changes.
Adding Individual Switch Permissions
Follow the steps below to allow additional individual switch access to:
•
SES
•
MGT_SERVER
These policies have device port WWNs as members. Nodes with device ports that are members are
allowed access to this interface.
1. Highlight a secure switch in the SAN Elements tab.
2. Select Actions > Security.
3. Log into a secure switch.
For more information, refer to
4. Select the Management Access Controls tab.
5. Select the tab of interest from the bottom of the window.
For instance, select the SES tab to allow the chosen switch to access SES policies.
6. Select a device. Use Shift/Click to select multiple devices.
7. Select the Add Device button (or drag and drop the device).
The Enforce Policy box will be checked automatically when you have added a device.
Uncheck to remove policies.
8. Select Activate to save, implement the policy to the selected switches and exit the security
dialog box.
Select Save to save changes without implementing policies. You can come back later to make
changes.
Adding Individual Switch Permissions
Follow the steps below to allow additional individual switch access to the specific secure areas:
•
SERIAL
•
FRONTPANEL
Note:
These policies have switches as members. Member switches allows access to their SERIAL port
and FRONTPANEL.
6-10
or
Fabric Login
or
When the SERIAL, TELNET, HTTP and API are all enforced with empty member sets,
there is no remaining way of managing security.
on page 4-2.
Fabric Manager User's Guide
