Tool Bar

Following is a brief description of the icons available in the Fabric View Tools Bar. For more
information about the available in Fabric Manager, see
Address window
h
Fabric Login Icon
Open FM Log Icon
Print Table Icon
Download Firmware Icon
Sequenced Reboot Icon
Context Sensitive Help Icon
Help Icon
Fabric Manager User's Guide
Fabric Manager View
Tool Bar on page 9-1.
Enter the IP address, name, or WWN of the switch
that you want to manage or monitor. Once the
switch information has been entered, the address
can be chosen automatically from the pull-down
menu.
Select the switches that you want to login to. For
more information about this option, see
Login Icon on page 9-2.
Select to open the Fabric Manager Log. For more
information about this option, see
Log on page 4-12.
Select to print a table report. For more information,
see Print Table Icon on page 9-5
4-12.
Select to setup firmware downloads for multiple
switches at once. For more information about this
option, see Download Firmware
Select to set up switches to reboot in a chosen
order. For more information, refer to
Reboot on page 7-4 or Setup a Sequenced Reboot
on page 11-7.
Select to view Context Sensitive Help. For more
information about this options, refer to
Sensitive Help Icon on page
Select to view the Help section. For more
information, refer to Help Icon
Help Menu on page 8-1.
3
Fabric
Fabric Manager
or Print on page
on page 7-2.
Sequenced
Context
9-10.
on page 9-11 or
3-5
