Create A Reboot Group - HP StorageWorks 8B - FC Entry Switch User Manual

11
Administrative Task Examples
3. Select the status parameters to be propagated in the Fabric Events.
Note:
4. Select OK.
5. Select Actions > ISL > ISL Checking to turn on ISL checking.
A check mark will appear, showing that ISL checking is active.
6. Select Actions > Restamp any time you want to restamp the fabric topology.
Note:
7. Select Actions > Events to view changes to fabric topology.
Note:
Download Firmware
For information on Downloading Firmware, see
page 7-3.

Create a Reboot Group

Perform the following steps to create a reboot group:
1. Select Tools > Reboot.
2. Select Create Reboot Sequence.
The Create or Change Reboot Groups window appears.
3. Select a fabric from the drop-down menu at the top of the window.
4. Select the Create button.
The Create Reboot Group dialog box will appear.
5. Type in a name for the reboot group.
6. Enter Fabric Stabilization timeout information and select the action to take if timeout occurs.
7. Enter delay time after stabilization.
8. Enter Fabric Stabilization information and press OK.
The name of your group will appear in the navigation-tree.
9. Select OK.
10. Select switches from the table to be added to the reboot group. Use shift/click to select multiple
switches.
11-6
For more information about the ISL Status tab, see
For more information about Incorporate Add into Stamp, see
1-7.
There is a ten second time spacing in stamping. When ISL checking is turned on, the
stamp will be set to the results of the last poll, which is at most ten seconds behind.
For more information, see Events
ISL Status Tab
ISL Checking
on page 6-2.
Downloading Firmware to Multiple Switches
Fabric Manager User's Guide
on page 4-8.
on page
on
