The Pick a Baseline Target Switch window appears.
5.
Highlight a switch to use as a baseline configuration from the navigation-tree.
Note:
6.
Select the highlighted switch by clicking on the left-arrow button, or by dragging and dropping
selections from the navigation tree to the table.
7.
Select the Login button and log in to the switch (if you have not previously done so).
For information, see
8.
Set up File Transfer properties if you have not previously done so.
Note:
The Base Configuration Dialog box appears.
9.
Check the configuration properties that you would like to save to your template from the Base
Configuration Dialog box.
10. Select Save.
The Save Base Dialog box appears.
11. Enter a file name for your configuration template.
It is recommended that you name your file so that you can easily recognize selected
configuration parameters. Example:
12. Select Save.
Download and Apply a Baseline Configuration
Download and Apply a Baseline Configuration
from a File
1.
Create a Reboot Group if you intend to apply a Baseline Configuration to an entire fabric. This
is an optional step, however, it is recommended to maintain the stability of a fabric.
For more information, refer to
2.
Select Tools > Config.
3.
Select Compare/Download from File.
4.
Browse to select a baseline configuration file and select Open.
The Target Switches window appears.
5.
Highlight switches that you want to compare to the baseline configuration from the
navigation-tree.
Fabric Manager User's Guide
You must highlight one switch only, not a fabric.
Fabric Login
You can setup File Transfer properties anytime by selecting File > Options and
selecting the File Transfer tab. For detailed information about setting up File Transfer
properties, see
File Transfer Tab
SNMP_Baseline.txt
Create a Reboot Group
Administrative Task Examples
on
page
4-2.
on
page
4-7.
on
page
11
11-6.
11-3
