Admin
Telnet
Switch View field descriptions:
polled at:
(or unreachable since:)
Name:
Type:
Fabric OS version:
Domain ID:
Ethernet IP:
Ethernet Mask:
FCnet IP:
FCnet Mask:
Gateway IP:
WWN:
Fabric Manager User's Guide
Fabric Manager View
Click to open Switch Administration View.
Click to launch the Telnet Interface for the switch.
Displays the time of the last status check.
If the switch is unavailable, this shows the time of
the last successful status check.
Displays the name of the switch.
Displays the type of switch configuration.
Displays the version of Fabric OS installed on the
switch.
Displays a number that uniquely identifies the
switch within the fabric.
Displays the Ethernet IP address.
Displays the Ethernet subnetmask.
Displays the Fibre channel IP address.
Displays the Fibre channel subnetmask.
Displays the Gateway IP address.
Displays the unique numeric identifier for the
switch; assigned by manufacturer.
3
3-11
