Figure 8-3
Using Context Sensitive Help
To use Context Sensitive Help:
1.
Select the Context Sensitive Help icon.
A question mark appears on screen.
2.
Use your mouse to click an object of interest on screen.
A window appears with information about that object.
Status Legend
The Status Legend defines the meaning of colors visible in the background of the switch icons.
Each color indicates a different operational state:
Blue
Green
Yellow Marginal (mix of good and faulty readings)
Red
Fabric Manager User's Guide
Sample Context Sensitive Help Window
Unknown
Healthy
Down (more than two faulty readings)
8
Help Menu
8-3
