San Elements Tab Icons
Fabric Icon
ISL Checking
Clicking on the word "Fabrics" in the navigation tree will cause the following icons to appear in
the right-hand window:
Fabric Events
Zone Admin
Fabric Manager User's Guide
A. B. C. D.
Fabric Manager View
Select the Fabric Icon from the San Elements
column to view a fabric view of the entire fabric,
rather than individual switches. See
with the Fabric Icon Selected
Displays the status of ISL Checking.
A - Displays by default when ISL Checking is OFF
and Fabric Checking is OFF.
B - Displays when ISL Checking is ON, but Fabric
Checking is OFF.
C - Displays when ISL Checking is OFF, but
Fabric Checking is ON.
D - Displays when ISL Checking is On, and Fabric
Checking is ON.
For more information, see ISL
ISL Status Tab on page 4-8.
Click to open Fabric Events View. For information
about this view, see Events on
Click to open the Zone Admin View. For
information about this view, see
Connection Controls Tab of the Security Menu
page 6-5.
3
Fabric View
on page 3-2.
on page 6-14 and
page 6-2.
