Selector
No.
1
Not used.
2
Time length from CML ON
3
to start of pseudo ring
4
backtone transmission
5
| Not used.
8
Selectors 3 and 4: Time length from CML ON to start of pseudo ring backtone transmission
These selectors set the length of time from CML-ON up to the start of pseudo ring backtone
transmission.
In those versions which have an OGM facility, the settings made by these selectors also apply to
the length of time from CML-ON up to the start of OGM transmission.
Selector
No.
1
| Not used.
4
5
Pause between paging number
|
and PIN
7
8 Not used.
NOTE: Selectors 5 through 7 are applicable only to the U.S.A. versions.
Selectors 5 through 7:
These selectors set the pause time between a telephone number being paged and PIN (private
identification number) for the paging feature.
WSW24
Function
WSW25
Function
Pause between paging number and PIN
App. 4-26
(TAD setting 2)
Setting and Specifications
No. 3 4
0 0 :
0 1 :
1 0 :
1 1 :
(TAD setting 3)
Setting and Specifications
No. 5 6 7
0 0 0 :
0 0 1 :
0 1 0 :
0 1 1 :
1 0 0 :
1 0 1 :
1 1 0 :
1 1 1 :
4 sec.
3 sec.
2 sec.
1 sec.
2 sec.
4 sec.
6 sec.
8 sec.
10 sec.
12 sec.
14 sec.
16 sec.
