7.5.4 ADF Performance Test

Function
The equipment counts the documents fed by the automatic document feeder (ADF) and displays
the count on the LCD for checking the ADF performance.
Operating Procedure
(1) Set documents. (Allowable up to the ADF capacity.)
The "DOC. READY" will appear on the LCD.
(2) Press the 0 and 8 keys in this order.
While counting the documents, the equipment feeds them in and out, displaying the current
count on the LCD as shown below.
(3) After counting all documents, the equipment shows the final count. To return the equipment to
the initial stage of the maintenance mode, press the Stop key.
Current count (1st page in this example)
7 -1 0
