(7) Pull the scanner release lever towards you and open the scanner unit.
(8) At each of the right and left scanner links, fully push up the lock of the scanner link support (in
the direction of arrow
release its boss from the scanner link support.
(9) Open the scanner unit further and lift up its rear edge to disengage it from the main cover in
the direction of arrow
Panel harness
CCD flat cable
Harness (ADF motor/
document sensor/document cover
open sensor) & grounding wire,
covered with a cable sheath
Main cover
) and press the upper end of the scanner link inwards (arrow
.
Scanner unit
Scanner link support
Releasing the scanner link from
the scanner link support secured
to the underside of the scanner unit
Scanner link
6 -2 7
Scanner link
Be careful with
this boss (provided
for the scanner open
sensor actuator)
Scanner release lever
Scanner link
Boss
Lock
) to
