Selector
No.
1
Pause key setting and 2nd dial
|
tone detection
3
4
| Detection of international tone
6
No. of 2nd dial tone detection
7
times
2nd dial tone interrupt detecting
8
time
NOTE: Selectors 4 through 8 are not applicable in those countries where no dial tone detection is
supported, e.g., U.S.A.
WSW06
(Pause key setting and 2nd dial tone detection)
Function
App. 4-8
Setting and Specifications
No.1 2 3
0 0 0 : No pause
0 0 1 : 3.5 sec. WAIT
0 1 0 : 7 sec. WAIT
0 1 1 : 10.5 sec. WAIT
1 0 0 : 14 sec. WAIT
1 1 0 : 2nd dial tone detection
only in pulse dialing (DP)
system
1 0 1 : 2nd dial tone detection
1 1 1 : both in DP and push-button
(PB) dialing system
No.4 5 6
0 0 0 : 50 ms
0 0 1 : 210 ms
0 1 0 : 500 ms
0 1 1 : 800 ms
1 0 0 : 900 ms
1 0 1 : 1.5 sec.
1 1 0 : 2.0 sec.
1 1 1 : 2.5 sec.
0: Once
0: 30 ms
1: Twice
1: 50 ms
