No. Part name
1 ADF
2 ADF cover
3 ADF document support
4 Document guide base
5 Document tray
6 Scanner unit
7 Control panel
8 Main cover
9 Output paper support
10 Paper support
11 Paper tray
12 Rear cover
13 Manual feed slot
Outline of functions
Automatically feeds the document sheet by sheet to
the reading unit.
Open this cover when removing jammed documents
from the ADF.
Supports the documents fitted to the ADF so that they
do not bend.
Adjusts the document position to the center of ADF.
Stores the read documents.
Indicates the whole reading unit including the control
panel. Open this unit when changing the ink cartridge.
Displays the machine operation status and is used to
operate the machine.
Indicates the whole enclosure of the machine.
Stores the printed sheets of paper.
Supports the paper fitted to the paper tray so that they
do not bend.
Automatically feeds the paper sheet by sheet to the
printing unit.
Indicates the rear enclosure. Open this cover when
doing maintenance work.
Used to feed the paper sheet by sheet manually.
Open the slot cover when removing jammed paper
from the machine.
