Understanding How STPs Work

Understanding How STPs Work
This section describes the specific functions that are common to all spanning tree protocols. The Cisco
proprietary spanning tree protocols, PVST+ and MISTP, are based on the IEEE 802.1D STP. (See the
"Understanding How PVST+ and MISTP Modes Work" section on page 7-11
PVST+ and MISTP.) The 802.1D STP is a Layer 2 management protocol that provides path redundancy
in a network while preventing undesirable loops. All spanning tree protocols use an algorithm that
calculates the best loop-free path through the network.
STP uses a distributed algorithm that selects one bridge of a redundantly connected network as the root
of a spanning tree-connected active topology. STP assigns roles to each port depending on what the
port's function is in the active topology. Port roles are as follows:
•
•
•
•
Switches that have ports with these assigned roles are called root or designated switches. For more
information, see the
In Ethernet networks, only one active path may exist between any two stations. Multiple active paths
between stations can cause loops in the network. When loops occur, some switches recognize stations
on both sides of the switch. This situation causes the forwarding algorithm to malfunction allowing
duplicate frames to be forwarded.
Spanning tree algorithms provide path redundancy by defining a tree that spans all of the switches in an
extended network and then forces certain redundant data paths into a standby (blocked) state. At regular
intervals, the switches in the network send and receive spanning tree packets which they use to identify
the active path. If one network segment becomes unreachable, or if spanning tree costs change, the
spanning tree algorithm reconfigures the spanning tree topology and reestablishes the link by activating
a standby path.
Spanning tree operation is transparent to end stations, which do not detect whether they are connected
to a single LAN segment or a switched LAN of multiple segments.

Understanding How a Topology Is Created

All switches in an extended LAN participating in a spanning tree gather information about other
switches in the network through an exchange of data messages known as bridge protocol data units
(BPDUs). This exchange of messages results in the following actions:
•
•
•
Catalyst 4500 Series, Catalyst 2948G, Catalyst 2948G-GE-TX, and Catalyst 2980G Switches Software Configuration Guide—Release 8.2GLX
7-2
Root—A forwarding port that is elected for the spanning tree topology
Designated—A forwarding port that is elected for every switched LAN segment
Alternate—A blocked port providing an alternate path to the root port in the spanning tree
Backup—A blocked port in a loopback configuration
"Understanding How a Topology Is Created" section on page
A unique root switch is elected for the spanning tree network topology.
A designated switch is elected for every switched LAN segment.
Any loops in the switched network are eliminated by placing redundant switch ports in a backup
state; all paths that are not needed to reach the root switch from anywhere in the switched network
are placed in STP-blocked mode.
Chapter 7 Configuring Spanning Tree
for information about
7-2.
