Intel SC5650BCDP Technical Product Specification page 91

Intel Server Board S5500BC TPS
®
Setup Item
Clear System Event Enabled
Log
Disabled
FRB-2 Enable Enabled
Disabled
O/S Boot Watchdog Enabled
Timer
Disabled
O/S Boot Watchdog Power Off
Timer Policy
Reset
O/S Boot Watchdog 5 minutes
Timer Timeout
10 minutes
15 minutes
20 minutes
Plug & Play BMC Enabled
Detection
Disabled
ACPI 1.0 Support Enabled
Disabled
Console Redirection
System Information
5.3.2.4.1 Console Redirection Screen
The Console Redirection screen allows the user to enable or disable console redirection and to
configure the connection options for this feature.
To access this screen from the Main screen, select Server Management > Console
Redirection.
Revision 1.8
Options
If enabled, clears the System Event Log. All current
entries will be lost.
Note: This option is reset to [Disabled] after a reboot.
Fault Resilient Boot (FRB).
If enabled, the BIOS programs the BMC watchdog
timer for approximately 6 minutes. If the BIOS does
not complete POST before the timer expires, the BMC
resets the system.
If enabled, the BIOS programs the watchdog timer
with the timeout value selected. If the OS does not
complete booting before the timer expires, the BMC
resets the system and an error is logged.
Requires OS support or Intel Management Software.
If the OS boot watchdog timer is enabled, this is the
system action taken if the watchdog timer expires.
[Reset] - System performs a reset.
[Power Off] - System powers off.
If the OS watchdog timer is enabled, this is the
timeout value used by the BIOS to configure the
watchdog timer.
If enabled, the BMC is detectable by OSs that support
plug and play loading of an IPMI driver. Do not enable
if your OS does not support this driver.
[Enabled] - Publish ACPI 1.0 version of FADT in Root
System Description Table.
May be required for compatibility with OS versions
that only support ACPI 1.0.
View/Configure console redirection information and
settings.
View system information
Intel order number: E42249-009
Help Text
BIOS Setup Utility
Comments
Grayed out when O/S Boot
Watchdog Timer is
disabled.
Grayed out when O/S Boot
Watchdog Timer is
disabled.
Needs to be [Enabled] for
Windows 2000 support.
Takes the user to the
Console Redirection
screen.
Takes the user to the
System Information
screen.
77
