Intel Server Board S5500BC TPS
®
Setup Item
Size
Quiet Boot
Enabled
Disabled
POST Error Pause Enabled
Disabled
System Date [Day of week
MM/DD/YYYY]
System Time [HH:MM:SS]
5.3.2.2 Advanced Screen
The Advanced screen provides an access point to configure several options. On this screen, the
user selects the option they want to configure. Configurations are performed on the selected
screen, and not directly on the Advanced screen.
To access this screen from the Main screen, press the right arrow until the Advanced screen is
selected.
Revision 1.8
Options
[Enabled] – Display the logo screen
during POST.
[Disabled] – Display the diagnostic
screen during POST.
[Enabled] – Go to the Error
Manager for critical POST errors.
[Disabled] – Attempt to boot and do
not go to the Error Manager for
critical POST errors.
System Date has configurable
fields for Month, Day, and Year.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
System Time has configurable
fields for Hours, Minutes, and
Seconds.
Hours are in 24-hour format.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
Intel order number: E42249-009
Help Text
Information only. Displays the
total physical memory installed in
the system, in MB or GB. The term
physical memory indicates the total
memory discovered in the form of
installed DDR-3 DIMMs.
If enabled, the POST Error Pause
option takes the system to the error
manager to review the errors when
major errors occur. Minor and fatal
error displays are not affected by
this setting.
BIOS Setup Utility
Comments
