Intel SC5650BCDP Technical Product Specification page 54

Functional Architecture
Remote KVMS Features:

USB 2.0 interface for Keyboard, Mouse, and Remote storage, such as a CD/DVD-ROM
and floppy

USB 1.1 interface for PS/2 to USB bridging and remote Keyboard and Mouse

Hardware-based Video Compression and Redirection Logic

Supports both text and graphics redirection

Hardware-assisted video redirection using the Frame Processing Engine

Direct interface to the Integrated Graphics Controller registers and Frame buffer

Hardware-based encryption engine
Graphics Controller Subsystem Features:

Integrated Matrix Graphics Core

2D Hardware Graphics Acceleration

DDR2 memory interface supports up to 128 MB of memory

Supports all display resolutions up to 1600 x 1200 16bpp @ 75Hz

High-speed Integrated 24-bit RAMDAC

Single lane PCI-Express* host interface
40 Intel order number: E42249-009
Intel Server Board S5500BC TPS
®
Revision 1.8
