Intel SCB2ATA Quick Start Manual

A guide for technically qualified persons
Intel Server Board SCB2
®

Quick Start Guide

Before You Begin ............................................................................... 2
Installation Notes ................................................................................ 4
Common Problems ....................................................................... 4
Server Board Components............................................................ 5
Back Panel Connectors................................................................. 6
Jumpers ........................................................................................ 7
Installation Procedures ........................................................................ 8
Install the I/O Shield..................................................................... 8
Rearrange the Standoffs................................................................ 9
Server Board Bumpers................................................................. 10
Install the Server Board ............................................................... 11
Installing Processors.................................................................... 12
Install the Processor Terminator .................................................. 16
Memory ....................................................................................... 17
Connect Cables............................................................................ 18
Finish Setting up Your Chassis.................................................... 18
Getting Help....................................................................................... 19
Translations of this guide are available at:
Übersetzungen dieses Handbuchs sind erhältlich bei:
Versiones traducidas de esta guía se encuentran disponibles en:
Des traductions de ce guide sont disponibles à l'adresse:
Le versioni tradotte di questa Guida sono disponibili presso:
As traduções deste guia estão disponíveis em:
http://support.intel.com/support/motherboards/server/SCB2/manual.htm
Copyright © 2001 Intel Corporation. All rights reserved. No part of this document may be
copied, or reproduced in any form, or by any means without prior written consent of Intel.
Intel Corporation (Intel) makes no warranty of any kind with regard to this material, including,
but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
Intel assumes no responsibility for any errors that may appear in this document. Intel makes
no commitment to update nor to keep current the information contained in this document.
Intel and Pentium are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
†
Other names and brands may be claimed as the property of others.
Order Number: A55877-003
