Intel® Server Board S3420GP TPS
Setup Item
CDROM #1
CDROM #2
6.3.2.6.4 Floppy Order Screen
The Floppy Order screen allows the user to control the floppy drives.
To access this screen from the Main screen, choose Boot Options > Floppy Order.

Floppy Disk
#1
Floppy Disk
#2
Setup Item
Floppy Disk #1
Floppy Disk #2
6.3.2.6.5 Network Device Order Screen
The Network Device Order screen allows the user to control the network bootable devices.
To access this screen from the Main screen, select Boot Options > Network Device Order.

Network
Device #1
Network
Device #2
Figure 37. Setup Utility – Network Device Order Screen Display
Revision 2.4
Table 34. Setup Utility – CDROM Order Fields
Options
Available
Legacy devices
for this Device
group.
Available
Legacy devices
for this Device
group.
Figure 36. Setup Utility — Floppy Order Screen Display
Table 35. Setup Utility — Floppy Order Fields
Options
Available
Legacy devices
for this Device
group.
Available
Legacy devices
for this Device
group.
Intel order number E65697-010
Help Text
Set system boot order by selecting the boot
option for this position.
Set system boot order by selecting the boot
option for this position.
Boot Options
<Available Floppy Disk >
<Available Floppy Disk >
Help Text
Set system boot order by selecting the boot
option for this position.
Set system boot order by selecting the boot
option for this position.
Boot Options
<Available Network devices>
<Available Network devices>
BIOS User Interface


73
