Intel® Server Board S3420GP TPS
 Power unit management: Support for power unit sensor. The Integrated Baseboard
Management Controller (Integrated BMC) handles power-good dropout conditions.
 DIMM temperature monitoring: New sensors and improved acoustic management using
closed-loop fan control algorithm taking into account DIMM temperature readings.
 Address Resolution Protocol (ARP): The Integrated BMC sends and responds to ARPs
(supported on embedded NICs)
 Dynamic Host Configuration Protocol (DHCP): The Integrated BMC performs DHCP
(supported on embedded NICs).
Platform environment control interface (PECI) thermal management support.

 E-mail alerting
 Embedded web server
 Integrated KVM
Integrated Remote Media Redirection

 Lightweight Directory Authentication Protocol (LDAP) support
4.2

Optional Advanced Management Feature Support

This section explains the advanced management features supported by the Integrated
Baseboard Management Controller (Integrated BMC) firmware.
4.2.1

Enabling Advanced Management Features

The Integrated BMC enables the advanced management features only when it detects the
presence of the Intel
RMM3, the advanced features are dormant. Only the Intel
RMM3 module interface.
4.2.1.1 Intel
®
The Intel RMM3 provides the Integrated BMC with an additional dedicated network interface.
The dedicated interface consumes its own LAN channel. Additionally, the Intel
additional flash storage for advanced features like Web Services for Management (WS-MAN).
4.2.2

Keyboard, Video, Mouse (KVM) Redirection

The Integrated BMC firmware supports keyboard, video, and mouse redirection over LAN. This
feature is available remotely from the embedded web server as a Java applet. This feature is
enabled only when the Intel
Environment (JRE) version 5.0 or later to run the KVM or media redirection applets.
4.2.2.1 Keyboard and Mouse
The keyboard and mouse are emulated by the Integrated BMC as USB human interface devices.
4.2.2.2 Video
Video output from the KVM subsystem is equivalent to the video output on the local console.
Video redirection is available after video is initialized by the system BIOS. The KVM video
resolution and refresh rates will always match the values set in the operating system.
Revision 2.4
®
Remote Management Module 3 (Intel
®
RMM3
®
RMM3 is present. The client system must have a Java Runtime
Intel order number E65697-010
®
RMM3) card. Without the Intel
®
Server Board S3420GPLX has a
Platform Management
®
®
RMM3 provides
37
