Intel® Server Board S3420GP TPS
10. Design and Environmental Specifications
10.1 Intel
Server Board S3420GP Design Specifications
®
The operation of the server board at conditions beyond those shown in the following table may
cause permanent damage to the system. Exposure to absolute maximum rating conditions for
extended periods may affect system reliability.
Operating Temperature
Non-Operating Temperature
DC Voltage
Shock (Unpackaged)
Shock (Packaged)
<20 pounds
20 to <40 pounds
40 to <80 pounds
80 to <100 pounds
100 to <120 pounds
120 pounds
Vibration (Unpackaged)
1
Chassis design must provide proper airflow to avoid exceeding the Intel
temperature.
Disclaimer Note: Intel Corporation server boards contain a number of high-density VLSI and
power delivery components that need adequate airflow to cool. Intel ensures through its own
chassis development and testing that when Intel server building blocks are used together, the
fully integrated system will meet the intended thermal requirements of these components. It is
the responsibility of the system integrator who chooses not to use Intel developed server
building blocks to consult vendor datasheets and operating parameters to determine the amount
of airflow required for their specific application and environmental conditions. Intel Corporation
cannot be held responsible, if components fail or the server board does not operate correctly
when used outside any of their published operating or non-operating limits.
10.2 Board-level Calculated MTBF
This section provides results of MTBF (Mean Time Between Failures) testing done by a third
party testing facility. MTBF is a standard measure for the reliability and performance of the
board under extreme working conditions. The MTBF was measured at 20000 hours at 35
degrees Celsius.
The following table shows the MTBF for the server boards as configured from the factory;
Product Code
®
Intel
Server Board S3420GPLX
®
Intel
Server Board S3420GPLC
®
Intel
Server Board S3420GPV
Revision 2.4
Table 62. Server Board Design Specifications
Calculated MTBF
335000 hours
335000 hours
277139 hours
Intel order number E65697-010
Design and Environmental Specifications
1
0º C to 55º C
(32º F to 131º F)
-40º C to 70º C (-40º F to 158º F)
± 5% of all nominal voltages
Trapezoidal, 50 G, 170 inches/sec
36 inches
30 inches
24 inches
18 inches
12 inches
9 inches
5 Hz to 500 Hz 3.13 g RMS random
®
35 degrees C
35 degrees C
35 degrees C
®
Xeon
processor maximum case
Operating Temperature
97
