BIOS User Interface
Setup Item
Size
Quiet Boot
POST Error Pause
System Date
System Time
6.3.2.2

Advanced Screen

The Advanced screen provides an access point to configure several options. On this screen,
the user selects the option they want to configure. Configurations are performed on the selected
screen, and not directly on the Advanced screen.
To access this screen from the Main screen, press the right arrow until the Advanced screen is
chosen.
52
Options
Enabled [Enabled] – Display the logo screen
during POST.
Disabled
[Disabled] – Display the diagnostic
screen during POST.
Enabled [Enabled] – Go to the Error
Manager for critical POST errors.
Disabled
[Disabled] – Attempt to boot and do
not go to the Error Manager for
critical POST errors.
[Day of week System Date has configurable
MM/DD/YYYY] fields for Month, Day, and Year.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
[HH:MM:SS] System Time has configurable
fields for Hours, Minutes, and
Seconds.
Hours are in 24-hour format.
Use [Enter] or [Tab] key to select
the next field.
Use [+] or [-] key to modify the
selected field.
Intel order number E65697-010
Help Text
Information only. Displays the
total physical memory installed in
the system, in MB or GB. The term
physical memory indicates the total
memory discovered in the form of
installed DDR3 DIMMs.
If enabled, the POST Error Pause
option takes the system to the error
manager to review the errors when
major errors occur. Minor and fatal
error displays are not affected by
this setting.
Intel® Server Board S3420GP TPS
Comments
Revision 2.4
