Intel® Server Board S3420GP TPS
4.2.5

Local Directory Authentication Protocol (LDAP)

The Integrated BMC firmware supports the Local Directory Authentication Protocol (LDAP)
protocol for user authentication.
Note: IPMI users/passwords and sessions are not supported over LDAP.
4.2.6

Embedded Webserver

The Integrated BMC provides an embedded web server for out-of-band management. User
authentication is handled by IPMI user names and passwords. Base functionality for the
embedded web server includes:
 Power Control – Limited control based on IPMI user privilege.
 Sensor Reading – Limited access based on IPMI user privilege.
 SEL Reading – Limited access based on IPMI user privilege.
 KVM/Media Redirection – Limited access based on IPMI user privilege. Only available
when the Intel
 IPMI User Management – Limited access based on IPMI user privilege.
The web server is available on all enabled LAN channels.
See Appendix B for Integrated BMC core sensors.
4.3

Management Engine (ME)

Intel Management Engine is tied to essential platform functionality. This Management Engine
firmware includes the following applications:
 Platform Clocks – Tune PCH clock silicon to the parameters of a specific board,
configure clocks at run time, power management clocks.
 Thermal Report – ME FW reports thermal and power information available only on PECI
to host accessible registers/Embedded Controller via SMBus.
Revision 2.4
®
RMM3 is present.
Intel order number E65697-010
Platform Management
39
